Запчасти Komatsu FG20L ДЛЯ FV МАЧТА ГИДРОЦИЛИНДР ПОДЪЕМА (ДЛЯ .M - .M МАЧТА) МАЧТА И СТРЕЛА
№
Артикул
Название
Примечание
Количество
|$20
37B-7QT-3300YK
LIFT CYLINDER ASS'Y,(FOR 3.0M MAST)
SN: 570001-UP
1шт.
|$21
37B-7QT-3330YK
LIFT CYLINDER ASS'Y,(FOR 3.3M MAST)
SN: 570001-UP
2шт.
|$22
37B-7QT-3350YK
LIFT CYLINDER ASS'Y,(FOR 3.5M MAST)
SN: 570001-UP
2шт.
|$23
37B-7QT-3370YK
LIFT CYLINDER ASS'Y,(FOR 3.7M MAST)
SN: 570001-UP
2шт.
|$24
37B-7QT-3400YK
LIFT CYLINDER ASS'Y,(FOR 4.0M MAST)
SN: 570001-UP
2шт.
|$25
37B-7QT-3430YK
LIFT CYLINDER ASS'Y,(FOR 4.3M MAST)
SN: 570001-UP
2шт.
|$26
37B-7QT-3450YK
LIFT CYLINDER ASS'Y,(FOR 4.5M MAST)
SN: 570001-UP
2шт.
|$27
37B-7QT-3470YK
LIFT CYLINDER ASS'Y,(FOR 4.7M MAST)
SN: 570001-UP
2шт.
|$28
37B-7QT-3500YK
LIFT CYLINDER ASS'Y,(FOR 5.0M MAST)
SN: 570001-UP
2шт.
|$29
37B-7RT-3550YK
LIFT CYLINDER ASS'Y,(FOR 5.5M MAST)
SN: 570001-UP
2шт.
1
KBB6527-16001
CYLINDER TUBE ASS'Y,(FOR 3.0M MAST)
SN: 570001-UP
1шт.
|$31
KBB6527-16301
CYLINDER TUBE ASS'Y,(FOR 3.3M MAST)
SN: 570001-UP
1шт.
|$32
KBB6527-16501
CYLINDER TUBE ASS'Y,(FOR 3.5M MAST)
SN: 570001-UP
1шт.
|$33
KBB6527-16701
CYLINDER TUBE ASS'Y,(FOR 3.7M MAST)
SN: 570001-UP
1шт.
|$34
KBB6527-17001
CYLINDER TUBE ASS'Y,(FOR 4.0M MAST)
SN: 570001-UP
1шт.
|$35
KBB6527-17301
CYLINDER TUBE ASS'Y,(FOR 4.3M MAST)
SN: 570001-UP
1шт.
|$36
KBB6527-17501
CYLINDER TUBE ASS'Y,(FOR 4.5M MAST)
SN: 570001-UP
1шт.
|$37
KBB6527-17701
CYLINDER TUBE ASS'Y,(FOR 4.7M MAST)
SN: 570001-UP
1шт.
|$38
KBB6527-18001
CYLINDER TUBE ASS'Y,(FOR 5.0M MAST)
SN: 570001-UP
1шт.
|$39
KBB6527-26501
CYLINDER TUBE ASS'Y,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
2
KBB6527-16002
PISTON ROD ASS'Y,(FOR 3.0M MAST)
SN: 570001-UP
1шт.
|$41
KBB6527-16302
PISTON ROD ASS'Y,(FOR 3.3M MAST)
SN: 570001-UP
1шт.
|$42
KBB6527-16502
PISTON ROD ASS'Y,(FOR 3.5M MAST)
SN: 570001-UP
1шт.
|$43
KBB6527-16702
PISTON ROD ASS'Y,(FOR 3.7M MAST)
SN: 570001-UP
1шт.
|$44
KBB6527-17002
PISTON ROD ASS'Y,(FOR 4.0M MAST)
SN: 570001-UP
1шт.
|$45
KBB6527-17302
PISTON ROD ASS'Y,(FOR 4.3M MAST)
SN: 570001-UP
1шт.
|$46
KBB6527-17502
PISTON ROD ASS'Y,(FOR 4.5M MAST)
SN: 570001-UP
1шт.
|$47
KBB6527-17702
PISTON ROD ASS'Y,(FOR 4.7M MAST)
SN: 570001-UP
1шт.
|$48
KBB6527-18002
PISTON ROD ASS'Y,(FOR 5.0M MAST)
SN: 570001-UP
1шт.
|$49
KBB6527-26502
PISTON ROD ASS'Y,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
3
KB30121-50102
HEAD,(FOR 3.0M TO 5.0M MAST)
SN: 570001-UP
1шт.
|$51
KB30121-55043
HEAD,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
4
KB30131-40017
BUSHING,(FOR 3.0M TO 5.0M MAST)
SN: 570001-UP
1шт.
|$53
KB30131-45017
BUSHING,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
5
KB30961-04012
U-RING,(FOR 3.0M TO 5.0M MAST) (K22)
SN: 570001-UP
1шт.
|$55
KB30961-04512
U-RING,(FOR 5.5M MAST) (K23)
SN: 570001-UP
1шт.
6
KB30191-40025
RING,WIPER (FOR 3.0M TO 5.0M MAST) (K22)
SN: 570001-UP
1шт.
|$57
KB30191-45025
RING,WIPER (FOR 5.5M MAST) (K23)
SN: 570001-UP
1шт.
7
KB30161-91774
O-RING,(FOR 3.0M TO 5.0M MAST) (K22)
SN: 570001-UP
1шт.
|$59
KB30161-91775
O-RING,(FOR 5.5M MAST) (K23)
SN: 570001-UP
1шт.
8
KB30161-50046
U-RING,(FOR 3.0M TO 5.0M MAST) (K22)
SN: 570001-UP
1шт.
|$61
KB30161-55046
U-RING,(FOR 5.5M MAST) (K23)
SN: 570001-UP
1шт.
9
KB30461-50039
RING,BACK UP(FOR 3.0M TO 5.0M MAST) (K22)
SN: 570001-UP
1шт.
|$63
KB30461-55039
RING,BACK UP(FOR 5.5M MAST) (K23)
SN: 570001-UP
1шт.
10
KB30131-50018
BUSHING,(FOR 3.0M TO 5.0M MAST)
SN: 570001-UP
1шт.
|$65
KB30131-55018
BUSHING,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
11
KB30551-91003
BEARING,(FOR 3.0M TO 5.0M MAST)
SN: 570001-UP
1шт.
|$67
KB30551-91001
RING,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
12
KB30141-91049
RING,(FOR 3.0M TO 5.0M MAST)
SN: 570001-UP
1шт.
|$69
KB30141-91048
SNAP RING,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
13
34A-63-17170
SPACER,(FOR 4.0M TO 4.5M MAST)
SN: 570001-UP
1шт.
|$71
34A-63-17190
SPACER,(FOR 4.7M TO 5.0M MAST)
SN: 570001-UP
1шт.
|$72
34B-63-16390
SPACER,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
14
KB95123-03500
O-RING,(FOR 3.0M TO 5.0M MAST)
SN: 570001-UP
1шт.
15
KB97124-01111
PLUG,(FOR 5.5M MAST)
SN: 570001-UP
1шт.
|$$57
SERVICE KIT
-1шт.
Выбрано товаров: 59
