Запчасти Komatsu FG30H-14 ГТР ПОТОК ПРИВОД ТРАНСМИССИЯ (/) СИЛОВАЯ ПЕРЕДАЧА И ПЕРЕДНИЙ МОСТ

|$11

3EB-15-32310

SHAFT ASS'Y,(FOR FGD20L, 25L)

SN: 550001-UP

1шт.

|$12

3EB-15-32410

SHAFT ASS'Y,(FOR FGD20H-30H AND FD20-30)

SN: 550001-UP

1шт.

|$13

3EB-15-32210

SHAFT ASS'Y,(FOR FG20-30)

SN: 550001-UP

1шт.

|$14

3EB-15-32810

SHAFT ASS'Y,(FOR FGD25H, 30H AND FD25, 30) (HI SPEED)

SN: 550001-UP

1шт.

1

3EB-15-32320

SHAFT, 15 TEETH,(FOR FGD20L, 25L)

SN: 550001-UP

1шт.

|$16

3EB-15-32420

SHAFT, 20 TEETH,(FOR FGD20H-30H AND FD20-30)

SN: 550001-UP

1шт.

|$17

3EB-15-32220

SHAFT, 19 TEETH,(FOR FG20-30)

SN: 550001-UP

1шт.

|$18

3EB-15-32820

SHAFT, 22 TEETH,(FOR FGD25H, 30H AND FD25, 30) (HI SPEED)

SN: 550001-UP

1шт.

2

3EB-15-31220

GEAR, 35 TEETH

SN: 550001-UP

1шт.

3

06000-06206

BEARING

SN: 550001-UP

1шт.

4

06000-06306

BEARING

SN: 550001-UP

1шт.

5

3EB-15-32341

GEAR, 61 TEETH,(FOR FGD20L, 25L)

SN: 550001-UP

1шт.

|$23

3EB-15-32440

GEAR, 57 TEETH,(FOR FGD20H-30H AND FD20-30)

SN: 550001-UP

1шт.

|$24

3EB-15-32240

GEAR, 58 TEETH,(FOR FG20-30)

SN: 550001-UP

1шт.

|$25

3EB-15-32840

GEAR, 54 TEETH,(FOR FGD25H, 30H AND FD25, 30) (HI SPEED)

SN: 550001-UP

1шт.

|$26

3EB-15-32032

PACK SUB ASS'Y,(FOR FGD20L, 25L)

SN: 550001-UP

1шт.

|$27

3EB-15-32042

PACK SUB ASS'Y,(FOR FGD20H-30H AND FD20-30)

SN: 550001-UP

1шт.

|$28

3EB-15-32022

PACK SUB ASS'Y,(FOR FG20-30)

SN: 550001-UP

1шт.

|$29

3EB-15-32082

PACK SUB ASS'Y,(FOR FGD25H, 30H AND FD25, 30) (HI SPEED)

SN: 550001-UP

1шт.

6

3EB-15-31132

SHAFT ASS'Y

SN: 550001-UP

1шт.

7

3EB-15-21230

PISTON

SN: 550001-UP

2шт.

8

3EA-15-11290

SEAL

SN: 550001-UP

2шт.

9

3EB-15-21240

SEAL

SN: 550001-UP

2шт.

10

3EB-15-11250

SPRING

SN: 550001-UP

2шт.

11

3EB-15-21260

WASHER

SN: 550001-UP

2шт.

12

04064-04018

RING,SNAP

SN: 550001-UP

2шт.

13

3EA-15-11173

DISC

SN: 550001-UP

12шт.

14

3EA-15-11180

PLATE

SN: 550001-UP

14шт.

15

3EA-15-21240

PLATE

SN: 550001-UP

2шт.

16

34B-15-11360

RING

SN: 550001-UP

2шт.

17

3EB-15-21482

SPACER

SN: 550001-UP

1шт.

18

3EB-15-31210

GEAR, 41 TEETH

SN: 550001-UP

1шт.

19

3EB-15-21320

BEARING

SN: 550001-UP

1шт.

20

3EB-15-21340

WASHER

SN: 550001-UP

1шт.

21

3EB-15-31190

SPACER

SN: 550001-UP

1шт.

22

04260-00317

BALL,STEEL

SN: 550001-UP

2шт.

23

06000-06207

BEARING

SN: 550001-UP

1шт.

24

3EB-15-21390

SPACER

SN: 550001-UP

1шт.

25

04064-03515

RING,SNAP

SN: 550001-UP

1шт.

26

3EB-15-21330

BEARING

SN: 550001-UP

1шт.

27

3EB-15-21350

WASHER

SN: 550001-UP

2шт.

28

04066-00030

RING,SNAP

SN: 550001-UP

1шт.

29

3EB-15-32330

GEAR, 15 TEETH,(FOR FGD20L, 25L)

SN: 550001-UP

1шт.

|$54

3EB-15-32430

GEAR, 20 TEETH,(FOR FGD20H-30H AND FD20-30)

SN: 550001-UP

1шт.

|$55

3EB-15-32230

GEAR, 19 TEETH,(FOR FG20-30)

SN: 550001-UP

1шт.

|$56

3EB-15-32830

GEAR, 22 TEETH,(FOR FGD25H, 30H AND FD25, 30) (HI SPEED)

SN: 550001-UP

1шт.
