Запчасти Komatsu FG30H-14 OUTER МАЧТА (VT .8T-.T) МАЧТА И СТРЕЛА

1

37B-TBB-3372

MAST,OUTER, (FOR 3.7M MAST)

SN: 550001-UP

1шт.

|$41

37B-TBB-3402

MAST,OUTER, (FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$42

37B-TBB-3432

MAST,OUTER, (FOR 4.3M MAST)

SN: 550001-UP

1шт.

|$43

37B-TBB-3452

MAST,OUTER, (FOR 4.5M MAST)

SN: 550001-UP

1шт.

|$44

37B-TBB-3472

MAST,OUTER, (FOR 4.7M MAST)

SN: 550001-UP

1шт.

|$45

37B-TBB-3502

MAST,OUTER, (FOR 5.0M MAST)

SN: 550001-UP

1шт.

|$46

37B-TBB-3552

MAST,OUTER, (FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$47

37B-TBB-3602

MAST,OUTER, (FOR 6.0M MAST)

SN: 550001-UP

1шт.

|$48

37B-TBB-3652

MAST,OUTER, (FOR 6.5M MAST)

SN: 550001-UP

1шт.

|$49

37B-TBB-3702

MAST,OUTER, (FOR 7.0M MAST)

SN: 550001-UP

1шт.

2

04022-08025

PIN,DOWEL

SN: 550001-UP

2шт.

3

3BB-71-11242

CAP

SN: 550001-UP

2шт.

4

3EB-71-31290

BUSHING

SN: 550001-UP

2шт.

5

01010-51685

BOLT

SN: 550001-UP

4шт.

6

01643-51645

WASHER

SN: 550001-UP

4шт.

7

07020-00000

FITTING,GREASE

SN: 550001-UP

2шт.

8

37B-9AA-1511

ROLLER,(S)

SN: 550001-UP

2шт.

|$57

37B-9AA-1521

ROLLER,(M)

SN: 550001-UP

2шт.

|$58

37B-9AA-1531

ROLLER

SN: 550001-UP

2шт.

9

3EB-71-00060

SHIM ASS'Y

SN: 550001-UP

2шт.

|$60

0

SHIM, 0.2MM

SN: 550001-UP

-2шт.

|$61

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$62

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

|$63

0

SHIM, 2.3MM

SN: 550001-UP

-2шт.

10

3EB-71-31640

STRIP

SN: 550001-UP

2шт.

11

3EB-71-00090

SHIM ASS'Y

SN: 550001-UP

2шт.

|$66

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$67

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

12

3EB-41-31860

PIN

SN: 550001-UP

2шт.

13

01010-81025

BOLT

SN: 550001-UP

2шт.

14

01602-21030

WASHER,SPRING

SN: 550001-UP

2шт.

15

3EB-T2-31420

BRACKET,(L.H.)

SN: 550001-UP

1шт.

16

3EB-T2-31410

BRACKET,(R.H.)

SN: 550001-UP

1шт.

17

01010-80820

BOLT

SN: 550001-UP

4шт.

18

01643-30823

WASHER

SN: 550001-UP

4шт.
