Запчасти Komatsu FG30H-14-EC МАЧТА ТРУБЫ (ДЛЯ 4-Х СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН НАВЕСН. ОБОРУД) (/) (ТРОЙН. МАЧТА) РАБОЧЕЕ ОБОРУДОВАНИЕ

Схема запчастей Komatsu FG30H-14-EC - МАЧТА ТРУБЫ (ДЛЯ 4-Х СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН НАВЕСН. ОБОРУД) (/) (ТРОЙН. МАЧТА) РАБОЧЕЕ ОБОРУДОВАНИЕ
1
2
3
4
5
5
6
6
7
7
8
8
9
10
10
11
11
12
13
14
14

Артикул

Название

Примечание

Количество

1

37B-ZED-5101

PIPE,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$15

37B-ZED-5011

PIPE,(FOR 4.3M TO 4.7M MAST)

SN: 550001-UP

1шт.

|$16

37B-ZED-5021

PIPE,(FOR 5.0M AND 5.5M MAST)

SN: 550001-UP

1шт.

|$17

37B-ZED-5031

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

2

37B-ZEE-5100

PIPE,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$19

37B-ZEE-5010

PIPE,(FOR 4.3M TO 4.7M MAST)

SN: 550001-UP

1шт.

|$20

37B-ZEE-5020

PIPE,(FOR 5.0M AND 5.5M MAST)

SN: 550001-UP

1шт.

|$21

37B-ZEE-5030

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

3

37B-ZEF-5100

PIPE,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$23

37B-ZEF-5010

PIPE,(FOR 4.3M TO 4.7M MAST)

SN: 550001-UP

1шт.

|$24

37B-ZEF-5020

PIPE,(FOR 5.0M AND 5.5M MAST)

SN: 550001-UP

1шт.

|$25

37B-ZEF-5030

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

4

37B-ZEG-5100

PIPE,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$27

37B-ZEG-5010

PIPE,(FOR 4.3M TO 4.7M MAST)

SN: 550001-UP

1шт.

|$28

37B-ZEG-5020

PIPE,(FOR 5.0M AND 5.5M MAST)

SN: 550001-UP

1шт.

|$29

37B-ZEG-5030

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

5

37B-ZEH-5010

PIPE,(FOR 4.0M TO 5.0M MAST)

SN: 550001-UP

1шт.

|$31

37B-ZEH-5020

PIPE,(FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$32

37B-ZEH-5030

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

6

37B-ZEJ-5010

PIPE,(FOR 4.0M TO 5.0M MAST)

SN: 550001-UP

1шт.

|$34

37B-ZEJ-5020

PIPE,(FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$35

37B-ZEJ-5030

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

7

37B-ZEK-5010

PIPE,(FOR 4.0M TO 5.0M MAST)

SN: 550001-UP

1шт.

|$37

37B-ZEK-5020

PIPE,(FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$38

37B-ZEK-5030

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

8

37B-ZEL-5010

PIPE,(FOR 4.0M TO 5.0M MAST)

SN: 550001-UP

1шт.

|$40

37B-ZEL-5020

PIPE,(FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$41

37B-ZEL-5030

PIPE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

9

300-63-35160

CLIP

SN: 550001-UP

1шт.

10

01010-80820

BOLT

SN: 550001-UP

2шт.

11

01602-20825

WASHER,SPRING

SN: 550001-UP

2шт.

12

37B-ZRN-2430

HOSE,(FOR 4.0M AND 4.3M MAST)

SN: 550001-UP

1шт.

|$46

37B-ZRN-2460

HOSE,(FOR 4.5M MAST)

SN: 550001-UP

1шт.

|$47

37B-ZRN-2490

HOSE,(FOR 4.7M MAST)

SN: 550001-UP

1шт.

|$48

37B-ZRN-2480

HOSE,(FOR 5.0M MAST)

SN: 550001-UP

1шт.

|$49

37B-ZRN-2560

HOSE,(FOR 5.5M MAST)

SN: 550001-UP

1шт.

|$50

37B-ZRN-2600

HOSE,(FOR 6.0M MAST)

SN: 550001-UP

1шт.

13

37B-ZRN-2370

HOSE,(FOR 4.0M AND 4.3M MAST)

SN: 550001-UP

1шт.

|$52

37B-ZRN-2400

HOSE,(FOR 4.5M MAST)

SN: 550001-UP

1шт.

|$53

37B-ZRN-2430

HOSE,(FOR 4.7M MAST)

SN: 550001-UP

1шт.

|$54

37B-ZRN-2420

HOSE,(FOR 5.0M MAST)

SN: 550001-UP

1шт.

|$55

37B-ZRN-2500

HOSE,(FOR 5.5M AND 6.0M MAST)

SN: 550001-UP

1шт.

14

37B-ZRN-2340

HOSE,(FOR 4.0M MAST)

SN: 550001-UP

2шт.

|$57

37B-ZRN-2360

HOSE,(FOR 4.3M MAST)

SN: 550001-UP

2шт.

|$58

37B-ZRN-2370

HOSE,(FOR 4.5M MAST)

SN: 550001-UP

2шт.

|$59

37B-ZRN-2390

HOSE,(FOR 4.7M MAST)

SN: 550001-UP

2шт.

|$60

37B-ZRN-2410

HOSE,(FOR 5.0M MAST)

SN: 550001-UP

2шт.

|$61

37B-ZRN-2440

HOSE,(FOR 5.5M MAST)

SN: 550001-UP

2шт.

|$62

37B-ZRN-2400

HOSE,(FOR 6.0M MAST)

SN: 550001-UP

2шт.
