Запчасти Komatsu FG30N-15 УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) (/) (НАКЛОН. СЕКЦ. БЛОК) ГИДРАВЛИКА

|$$1

PLEASE USE THE CONTROL VALVE FOR 3T WHEN THE TRUCKS ARE 2T AND 2.5T PROVIDED WITH FV MAST OF 5.5M OR MORE.

-1шт.

|$15

37B-1LA-4210

CONTROL VALVE ASS'Y,2-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$16

37B-1LA-4220

CONTROL VALVE ASS'Y,2-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$17

37B-1LA-4310

CONTROL VALVE ASS'Y,3-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$18

37B-1LA-4320

CONTROL VALVE ASS'Y,3-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$19

37B-1LB-4310

CONTROL VALVE ASS'Y,3-SPOOL

SN: 570001-UP

1шт.

|$$7

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$21

37B-1LB-4320

CONTROL VALVE ASS'Y,3-SPOOL

SN: 570001-UP

1шт.

|$$9

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$23

37B-1LA-4410

CONTROL VALVE ASS'Y,4-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$24

37B-1LA-4420

CONTROL VALVE ASS'Y,4-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$25

37B-1LC-4410

CONTROL VALVE ASS'Y,4-SPOOL

SN: 570001-UP

1шт.

|$$13

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$27

37B-1LC-4420

CONTROL VALVE ASS'Y,4-SPOOL

SN: 570001-UP

1шт.

|$$15

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$29

37B-1LA-4510

CONTROL VALVE ASS'Y,5-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$30

37B-1LA-4520

CONTROL VALVE ASS'Y,5-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$31

37B-1LC-4510

CONTROL VALVE ASS'Y,5-SPOOL

SN: 570001-UP

1шт.

|$$19

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$33

37B-1LC-4520

CONTROL VALVE ASS'Y,5-SPOOL

SN: 570001-UP

1шт.

|$$21

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$$22

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.R4140-51A0 TO R4140-54A1.

-1шт.

|$36

KBC0213-31201

SPOOL SECTION ASS'Y,TILT,2-SPOOL(FOR 2.0T-2.5T)

SN: 570001-UP

1шт.

|$37

KBC0213-31202

SPOOL SECTION ASS'Y,TILT,2-SPOOL(FOR 3.0T)

SN: 570001-UP

1шт.

|$38

KBC0213-31203

SPOOL SECTION ASS'Y,TILT,3 TO 5-SPOOL

SN: 570001-UP

1шт.

|$$26

(FOR 2.0T - 2.5T)

-1шт.

|$40

KBC0213-31204

SPOOL SECTION ASS'Y,TILT,3 TO 5-SPOOL(FOR 3.0T)

SN: 570001-UP

1шт.

1

0

HOUSING,(FOR 2-SPOOL)

SN: 570001-UP

1шт.

|$42

0

HOUSING,(FOR 3 TO 5-SPOOL)

SN: 570001-UP

1шт.

2

0

SPOOL,(FOR 2.0 TON-2.5TON)

SN: 570001-UP

1шт.

|$44

0

SPOOL,(FOR 3.0 TON)

SN: 570001-UP

1шт.

3

KB21011-31702

PLATE

SN: 570001-UP

2шт.

4

KB21001-00689

O-RING

SN: 570001-UP

2шт.

5

KB21011-32801

WIPER

SN: 570001-UP

2шт.

6

KB21011-31024

CAP,SPOOL

SN: 570001-UP

1шт.

7

KB21011-30702

SEAT

SN: 570001-UP

2шт.

8

KB21011-30528

SCREW,CAP

SN: 570001-UP

1шт.

9

KB21011-30603

SPRING,SPOOL

SN: 570001-UP

1шт.

10

KB21011-32404

POPPET,CHECK VALVE

SN: 570001-UP

1шт.

11

KB21011-30604

SPRING,CHECK VALVE

SN: 570001-UP

1шт.

12

KB21001-00106

O-RING

SN: 570001-UP

1шт.

13

KB91111-60102

SCREW

SN: 570001-UP

2шт.

14

KB92703-06181

BOLT

SN: 570001-UP

2шт.

15

0

VALVE

SN: 570001-UP

1шт.

16

KB21011-30618

SPRING

SN: 570001-UP

1шт.

17

KB95133-00500

O-RING

SN: 570001-UP

1шт.
