Запчасти Komatsu FG35 FV МАЧТА ГИДРОЦИЛИНДР ПОДЪЕМА (ВНУТР. ЧАСТИ) МАЧТА КОМПОНЕНТЫ

Схема запчастей Komatsu FG35 - FV МАЧТА ГИДРОЦИЛИНДР ПОДЪЕМА (ВНУТР. ЧАСТИ) МАЧТА КОМПОНЕНТЫ
1
2
3
4
5
6
7
8
9
10
11
12

Артикул

Название

Примечание

Количество

|$26

37C-7AT-2253UE

CYLINDER ASS'Y,LIFT (FOR 2.5M MAST)

SN: 133001-UP

2шт.

|$27

37C-7AT-2273UE

CYLINDER ASS'Y,LIFT (FOR 2.7M MAST)

SN: 133001-UP

2шт.

|$28

37C-7AT-2303UE

CYLINDER ASS'Y,LIFT (FOR 3.0M MAST)

SN: 133001-UP

2шт.

|$29

37C-7AT-2333UE

CYLINDER ASS'Y,LIFT (FOR 3.3M MAST)

SN: 133001-UP

2шт.

|$30

37C-7AT-2353UE

CYLINDER ASS'Y,LIFT (FOR 3.5M MAST)

SN: 133001-UP

2шт.

|$31

37C-7AT-2373UE

CYLINDER ASS'Y,LIFT (FOR 3.7M MAST)

SN: 133001-UP

2шт.

|$32

37C-7AT-2403UE

CYLINDER ASS'Y,LIFT (FOR 4.0M MAST)

SN: 133001-UP

2шт.

|$33

37C-7AT-2433UE

CYLINDER ASS'Y,LIFT (FOR 4.3M MAST)

SN: 133001-UP

2шт.

|$34

37C-7AT-2453UE

CYLINDER ASS'Y,LIFT (FOR 4.5M MAST)

SN: 133001-UP

2шт.

|$35

37C-7AT-2473UE

CYLINDER ASS'Y,LIFT (FOR 4.7M MAST)

SN: 133001-UP

2шт.

|$36

37C-7AT-2503UE

CYLINDER ASS'Y,LIFT (FOR 5.0M MAST)

SN: 133001-UP

2шт.

|$37

37C-7AT-2553UE

CYLINDER ASS'Y,LIFT (FOR 5.5M MAST)

SN: 133001-UP

2шт.

|$38

37C-7AT-2603UE

CYLINDER ASS'Y,LIFT (FOR 6.0M MAST)

SN: 133001-UP

2шт.

1

37C-7AU-1252

CYLINDER,(FOR 2.5M MAST)

SN: 133001-UP

1шт.

|$40

37C-7AU-1272

CYLINDER,(FOR 2.7M MAST)

SN: 133001-UP

1шт.

|$41

37C-7AU-1302

CYLINDER,(FOR 3.0M MAST)

SN: 133001-UP

1шт.

|$42

37C-7AU-1332

CYLINDER,(FOR 3.3M MAST)

SN: 133001-UP

1шт.

|$43

37C-7AU-1352

CYLINDER,(FOR 3.5M MAST)

SN: 133001-UP

1шт.

|$44

37C-7AU-1372

CYLINDER,(FOR 3.7M MAST)

SN: 133001-UP

1шт.

|$45

37C-7AU-1402

CYLINDER,(FOR 4.0M MAST)

SN: 133001-UP

1шт.

|$46

37C-7AU-1432

CYLINDER,(FOR 4.3M MAST)

SN: 133001-UP

1шт.

|$47

37C-7AU-1452

CYLINDER,(FOR 4.5M MAST)

SN: 133001-UP

1шт.

|$48

37C-7AU-1472

CYLINDER,(FOR 4.7M MAST)

SN: 133001-UP

1шт.

|$49

37C-7AU-1502

CYLINDER,(FOR 5.0M MAST)

SN: 133001-UP

1шт.

|$50

37C-7AU-1552

CYLINDER,(FOR 5.5M MAST)

SN: 133001-UP

1шт.

|$51

37C-7AU-1602

CYLINDER,(FOR 6.0M MAST)

SN: 133001-UP

1шт.

2

37C-7AV-1253

ROD ASS'Y,(FOR 2.5M MAST)

SN: 133001-UP

1шт.

|$53

37C-7AV-1273

ROD ASS'Y,(FOR 2.7M MAST)

SN: 133001-UP

1шт.

|$54

37C-7AV-1303

ROD ASS'Y,(FOR 3.0M MAST)

SN: 133001-UP

1шт.

|$55

37C-7AV-1333

ROD ASS'Y,(FOR 3.3M MAST)

SN: 133001-UP

1шт.

|$56

37C-7AV-1353

ROD ASS'Y,(FOR 3.5M MAST)

SN: 133001-UP

1шт.

|$57

37C-7AV-1373

ROD ASS'Y,(FOR 3.7M MAST)

SN: 133001-UP

1шт.

|$58

37C-7AV-1403

ROD ASS'Y,(FOR 4.0M MAST)

SN: 133001-UP

1шт.

|$59

37C-7AV-1433

ROD ASS'Y,(FOR 4.3M MAST)

SN: 133001-UP

1шт.

|$60

37C-7AV-1453

ROD ASS'Y,(FOR 4.5M MAST)

SN: 133001-UP

1шт.

|$61

37C-7AV-1473

ROD ASS'Y,(FOR 4.7M MAST)

SN: 133001-UP

1шт.

|$62

37C-7AV-1503

ROD ASS'Y,(FOR 5.0M MAST)

SN: 133001-UP

1шт.

|$63

37C-7AV-1553

ROD ASS'Y,(FOR 5.5M MAST)

SN: 133001-UP

1шт.

|$64

37C-7AV-1603

ROD ASS'Y,(FOR 6.0M MAST)

SN: 133001-UP

1шт.

3

3EC-63-11111

HEAD,CYLINDER

SN: 133001-UP

1шт.

4

304-827-1710

BUSHING

SN: 133001-UP

1шт.

5

360-61-81250

U-RING (K21)

SN: 133001-UP

1шт.

6

34B-63-17890

WIPER (K21)

SN: 133001-UP

1шт.

7

34B-63-15220

O-RING (K21)

SN: 133001-UP

1шт.

8

34B-63-17571

U-RING (K21)

SN: 133001-UP

1шт.

9

3EB-63-16190

RING,BACK-UP (K21)

SN: 133001-UP

1шт.

10

3EB-63-16290

BUSHING

SN: 133001-UP

1шт.

11

3EC-63-11150

SPACER,(FOR 4.0M TO 4.5M MAST)

SN: 133001-UP

1шт.

|$74

3EC-63-11160

SPACER,(FOR 4.7M TO 6.0M MAST)

SN: 133001-UP

1шт.

12

34B-63-17680

O-RING

SN: 133001-UP

1шт.

|$$51

SERVICE KIT

-1шт.

K21

KB3065A-00077

REPAIR KIT

SN: 133001-UP

2шт.

Выбрано товаров: 52
