Запчасти Komatsu FD80-7-US МАЧТА (/) (МАЧТА И ГИДРОЦИЛИНДР ПОДЪЕМА) (ДЛЯ .M - .M МАЧТА) МАЧТА
№
Артикул
Название
Примечание
Количество
1
37D-7DB-6400
MAST,OUTER (FOR 4.0M MAST)
SN: 40001-UP
1шт.
|$25
37D-7DB-6430
MAST,OUTER (FOR 4.3M MAST)
SN: 40001-UP
1шт.
|$26
37D-7DB-6450
MAST,OUTER (FOR 4.5M MAST)
SN: 40001-UP
1шт.
|$27
37D-7DB-6500
MAST,OUTER (FOR 5.0M MAST)
SN: 40001-UP
1шт.
|$28
37D-7DB-6550
MAST,OUTER (FOR 5.5M MAST)
SN: 40001-UP
1шт.
|$29
37D-7DB-6600
MAST,OUTER (FOR 6.0M MAST)
SN: 40001-UP
1шт.
2
37D-7DD-6400
MAST,INNER (FOR 4.0M MAST)
SN: 40001-UP
1шт.
|$31
37D-7DD-6430
MAST,INNER (FOR 4.3M MAST)
SN: 40001-UP
1шт.
|$32
37D-7DD-6450
MAST,INNER (FOR 4.5M MAST)
SN: 40001-UP
1шт.
|$33
37D-7DD-6500
MAST,INNER (FOR 5.0M MAST)
SN: 40001-UP
1шт.
|$34
37D-7DD-6550
MAST,INNER (FOR 5.5M MAST)
SN: 40001-UP
1шт.
|$35
37D-7DD-6600
MAST,INNER (FOR 6.0M MAST)
SN: 40001-UP
1шт.
3
37E-739-1180
CHAIN,(FOR 4.0M MAST)
SN: 40001-UP
2шт.
|$37
37E-739-1200
CHAIN,(FOR 4.3M MAST)
SN: 40001-UP
2шт.
|$38
37E-739-1230
CHAIN,(FOR 4.5M MAST)
SN: 40001-UP
2шт.
|$39
37E-739-1270
CHAIN,(FOR 5.0M MAST)
SN: 40001-UP
2шт.
|$40
37E-739-1320
CHAIN,(FOR 5.5M MAST)
SN: 40001-UP
2шт.
|$41
37E-739-1350
CHAIN,(FOR 6.0M MAST)
SN: 40001-UP
2шт.
4
3EE-72-11760
STOPPER
SN: 40001-UP
4шт.
5
37D-7CT-3400YD
CYLINDER ASS'Y,LIFT (FOR 4.0M MAST)
SN: 40001-UP
2шт.
|$44
37D-7CT-3430YD
CYLINDER ASS'Y,LIFT (FOR 4.3M MAST)
SN: 40001-UP
2шт.
|$45
37D-7CT-3450YD
CYLINDER ASS'Y,LIFT (FOR 4.5M MAST)
SN: 40001-UP
2шт.
|$46
37D-7CT-3500YD
CYLINDER ASS'Y,LIFT (FOR 5.0M MAST)
SN: 40001-UP
2шт.
|$47
37D-7CT-3550YD
CYLINDER ASS'Y,LIFT (FOR 5.5M MAST)
SN: 40001-UP
2шт.
|$48
37D-7CT-3600YD
CYLINDER ASS'Y,LIFT (FOR 6.0M MAST)
SN: 40001-UP
2шт.
6
3FD-71-67110SA
PIPE
SN: 40001-UP
1шт.
8
3FD-73-67210
VALVE ASS'Y,DOWN CONTROL
SN: 40001-UP
1шт.
12
3FD-71-67150
HOSE
SN: 40001-UP
2шт.
13
3ED-66-54150
VALVE ASS'Y,SAFETY
SN: 40001-UP
1шт.
14
3FD-71-67970
NIPPLE
SN: 40001-UP
1шт.
Выбрано товаров: 35
