Запчасти Komatsu FD30H-16 5-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН И ЭЛЕМЕНТЫ КРЕПЛЕНИЯ ГИДРАВЛИКА

|$$1

PLEASE USE THE CONTROL VALVE FOR 3T WHEN THE TRUCKS ARE 2T AND 2.5T PROVIDED WITH FV MAST OF 5.5M OR MORE.

-1шт.

1

37B-1LA-5511

CONTROL VALVE ASS'Y,(FOR 2.0TON AND 2.5TON)

SN: 708772-UP

1шт.

|$8

37B-1LA-5510

CONTROL VALVE ASS'Y,(FOR 2.0TON AND 2.5TON)

SN: 700001-708771

1шт.

|$9

37B-1LA-5521

CONTROL VALVE ASS'Y,(FOR 3.0TON)

SN: 708772-UP

1шт.

|$10

37B-1LA-5520

CONTROL VALVE ASS'Y,(FOR 3.0TON)

SN: 700001-708771

1шт.

|$11

37B-1LA-5531

CONTROL VALVE ASS'Y,(FOR 3.5TON)

SN: 708772-UP

1шт.

|$12

37B-1LA-5530

CONTROL VALVE ASS'Y,(FOR 3.5TON)

SN: 700001-708771

1шт.

|$13

37B-1LC-5511

CONTROL VALVE ASS'Y

SN: 708772-UP

1шт.

|$14

37B-1LC-5510

CONTROL VALVE ASS'Y

SN: 700001-708771

1шт.

|$$10

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$16

37B-1LC-5521

CONTROL VALVE ASS'Y

SN: 708772-UP

1шт.

|$17

37B-1LC-5520

CONTROL VALVE ASS'Y

SN: 700001-708771

1шт.

|$$13

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$19

37B-1LC-5531

CONTROL VALVE ASS'Y

SN: 708772-UP

1шт.

|$20

37B-1LC-5530

CONTROL VALVE ASS'Y

SN: 700001-708771

1шт.

|$$16

(FOR 3.5T),(WITH PORT RELIEF VALVE)

-1шт.

2

01050-51025

BOLT

SN: 700001-UP

3шт.

3

3EB-61-42140

WASHER

SN: 700001-UP

3шт.

4

3EB-61-42120

CUSHION

SN: 700001-UP

8шт.

5

3EB-61-42130

COLLAR

SN: 700001-UP

4шт.

6

3EB-66-43890

NIPPLE

SN: 700001-UP

1шт.

7

3EF-04-11610

O-RING

SN: 722579-UP

1шт.

|$28

34A-69-11280

O-RING

SN: 700001-722578

1шт.

8

3EB-66-53820

HOSE

SN: 700001-UP

1шт.

9

07281-00359

CLAMP

SN: 700001-UP

1шт.

10

07281-00419

CLAMP

SN: 700001-UP

1шт.

11

01010-80825

BOLT

SN: 700001-UP

1шт.

12

3EB-61-44120

WASHER

SN: 700001-UP

1шт.

13

3EB-55-51980

CLIP

SN: 700001-UP

2шт.
