Запчасти Komatsu FD30H-15 УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) (/) (LIFT СЕКЦ. БЛОК) ГИДРАВЛИКА

|$$1

PLEASE USE THE CONTROL VALVE FOR 3T WHEN THE TRUCKS ARE 2T AND 2.5T PROVIDED WITH FV MAST OF 5.5M OR MORE.

-1шт.

|$15

37B-1LA-4210

CONTROL VALVE ASS'Y,2-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$16

37B-1LA-4220

CONTROL VALVE ASS'Y,2-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$17

37B-1LA-4310

CONTROL VALVE ASS'Y,3-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$18

37B-1LA-4320

CONTROL VALVE ASS'Y,3-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$19

37B-1LB-4310

CONTROL VALVE ASS'Y,3-SPOOL

SN: 570001-UP

1шт.

|$$7

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$21

37B-1LB-4320

CONTROL VALVE ASS'Y,3-SPOOL

SN: 570001-UP

1шт.

|$$9

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$23

37B-1LA-4410

CONTROL VALVE ASS'Y,4-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$24

37B-1LA-4420

CONTROL VALVE ASS'Y,4-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$25

37B-1LC-4410

CONTROL VALVE ASS'Y,4-SPOOL

SN: 570001-UP

1шт.

|$$13

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$27

37B-1LC-4420

CONTROL VALVE ASS'Y,4-SPOOL

SN: 570001-UP

1шт.

|$$15

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$29

37B-1LA-4510

CONTROL VALVE ASS'Y,5-SPOOL (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$30

37B-1LA-4520

CONTROL VALVE ASS'Y,5-SPOOL (FOR 3.0T)

SN: 570001-UP

1шт.

|$31

37B-1LC-4510

CONTROL VALVE ASS'Y,5-SPOOL

SN: 570001-UP

1шт.

|$$19

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$33

37B-1LC-4520

CONTROL VALVE ASS'Y,5-SPOOL

SN: 570001-UP

1шт.

|$$21

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$$22

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.R4140-51A0 TO R4140-54A1.

-1шт.

|$36

KBC0213-31001

SPOOL SECTION ASS'Y,LIFT (FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$37

KBC0213-31002

SPOOL SECTION ASS'Y,LIFT (FOR 3.0T)

SN: 570001-UP

1шт.

1

0

HOUSING

SN: 570001-UP

1шт.

2

0

SPOOL

SN: 570001-UP

1шт.

3

KB21011-31702

PLATE

SN: 570001-UP

2шт.

4

KB21001-00689

O-RING

SN: 570001-UP

2шт.

5

KB21011-32801

WIPER

SN: 570001-UP

2шт.

6

KB21011-31024

CAP

SN: 570001-UP

1шт.

7

KB21011-30702

SEAT

SN: 570001-UP

2шт.

8

KB21011-30507

SCREW,CAP

SN: 570001-UP

1шт.

9

KB21011-30603

SPRING

SN: 570001-UP

1шт.

10

KB91111-60102

SCREW

SN: 570001-UP

2шт.

11

KB92703-06181

BOLT

SN: 570001-UP

2шт.

12

KB97161-04161

PLUG

SN: 570001-UP

1шт.

13

KB95113-01800

O-RING

SN: 570001-UP

1шт.

14

KB97161-03121

PLUG

SN: 570001-UP

3шт.

15

KB95113-01400

O-RING

SN: 570001-UP

3шт.

16

KB21111-33114

POPPET

SN: 570001-UP

1шт.

17

KB21111-30515

SPRING

SN: 570001-UP

1шт.

18

KBT1461-15008

SPRING

SN: 570001-UP

1шт.

19

0

SPOOL,(FOR 2.0T - 2.5T)

SN: 570001-UP

1шт.

|$57

0

SPOOL,(FOR 3.0T)

SN: 570001-UP

1шт.

20

KB96321-07140

BALL,STEEL

SN: 570001-UP

1шт.

21

KBT1461-05003

SPRING

SN: 570001-UP

1шт.

22

KBT1152-09503

PLUG

SN: 570001-UP

1шт.

23

KB21001-90218

PLUG

SN: 570001-UP

1шт.

24

KB21001-00036

O-RING

SN: 570001-UP

1шт.

25

0

PLATE, NAME,NAME

SN: 570001-UP

1шт.

26

KB91911-01489

SCREW

SN: 570001-UP

2шт.

27

KB21013-30678

RELIEF VALVE ASS'Y

SN: 570001-UP

1шт.

28

KB21001-00035

O-RING

SN: 570001-UP

1шт.
