Запчасти Komatsu FD30J-14 МАЧТА ТРУБЫ (ВОЗВРАТ. ЛИНИЯ) (СУХ. МУФТА И ГИДРОТРАНСФОРМАТОР СПЕЦ-Я.) МАЧТА И СТРЕЛА

1

07285-00130

CLAMP,(FOR 3.0M TO 4.3M MAST)

SN: 550001-UP

4шт.

|$23

07280-01620

CLAMP,(FOR 4.5M TO 6.0M MAST)

SN: 550001-UP

4шт.

2

37B-7AZ-2270

HOSE,(FOR 3.0M MAST)

SN: 550001-UP

2шт.

|$25

37B-7AZ-2300

HOSE,(FOR 3.3M MAST)

SN: 550001-UP

2шт.

|$26

37B-7AZ-2320

HOSE, 1600MM,(FOR 3.5M MAST)

SN: 550001-UP

2шт.

|$27

37B-7AZ-2340

HOSE,(FOR 3.7M MAST)

SN: 550001-UP

2шт.

|$28

37B-7AZ-2380

HOSE,(FOR 4.0M MAST)

SN: 550001-UP

2шт.

|$29

37B-7AZ-2410

HOSE,(FOR 4.3M MAST)

SN: 550001-UP

2шт.

|$30

37A-502-6220

HOSE,(FOR 4.5M MAST)

SN: 550001-UP

2шт.

|$31

07261-20923

HOSE,(FOR 4.7M MAST)

SN: 550001-UP

2шт.

|$32

37A-502-6250

HOSE,(FOR 5.0M MAST)

SN: 550001-UP

2шт.

|$33

37A-502-6290

HOSE,(FOR 5.5M MAST)

SN: 550001-UP

2шт.

|$34

07261-20931

HOSE,(FOR 6.0M MAST)

SN: 550001-UP

2шт.

3

3EB-71-38150

CLAMP,(FOR 3.0M TO 3.7M MAST)

SN: 550001-UP

2шт.

|$36

3EB-71-38150

CLAMP,(FOR 4.0M TO 6.0M MAST)

SN: 550001-UP

4шт.

4

3EB-71-38121

TEE,(FOR 3.0M TO 4.3M MAST)

SN: 550001-UP

1шт.

|$40

3EB-71-28120

PIPE,(FOR 4.5M TO 6.0M MAST)

SN: 550001-UP

1шт.

5

01010-80830

BOLT

SN: 550001-UP

1шт.

6

01602-20825

WASHER,SPRING

SN: 550001-UP

1шт.

7

01641-20812

WASHER

SN: 550001-UP

1шт.

8

37B-1PM-2130

HOSE,(FOR 3.0M TO 4.3M MAST)

SN: 550001-UP

1шт.

|$45

07261-21413

HOSE,(FOR 4.5M TO 6.0M MAST)

SN: 550001-UP

1шт.

9

07280-02023

CLAMP,(FOR 3.0M TO 4.3M MAST)

SN: 550001-UP

2шт.

|$47

07280-02523

CLAMP,(FOR 4.5M TO 6.0M MAST)

SN: 550001-UP

2шт.
