Запчасти Komatsu FD30J-14 МАЧТА (/) (МАЧТА ATTACHING ЧАСТИ) МАЧТА И СТРЕЛА

1

3EB-71-31290

BUSHING

SN: 550001-UP

2шт.

2

07020-00000

FITTING,GREASE

SN: 550001-UP

2шт.

3

3EB-71-00090

SHIM ASS'Y

SN: 550001-UP

1шт.

|$16

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$17

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

4

37B-9AA-1512

ROLLER,S

SN: 550001-UP

2шт.

|$19

37B-9AA-1522

ROLLER,M

SN: 550001-UP

2шт.

|$20

37B-9AA-1532

ROLLER,L

SN: 550001-UP

2шт.

5

3EB-71-00060

SHIM ASS'Y

SN: 550001-UP

1шт.

|$22

0

SHIM, 0.2MM

SN: 550001-UP

-2шт.

|$23

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$24

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

|$25

0

SHIM, 2.3MM

SN: 550001-UP

-2шт.

6

3EB-71-31640

STRIP

SN: 550001-UP

2шт.

7

3EB-72-31410

CLAMP,(FOR 3.0M TO 5.0M MAST)

SN: 550001-UP

2шт.

|$28

3EB-72-31410

CLAMP,(FOR 5.5M AND 6.0M MAST)

SN: 550001-UP

4шт.

8

3EB-71-31510

PLATE,(FOR 3.0M TO 5.0M MAST)

SN: 550001-UP

2шт.

|$30

3EB-71-31510

PLATE,(FOR 5.5M AND 6.0M MAST)

SN: 550001-UP

4шт.

9

3EB-72-31430

RUBBER,(FOR 3.0M TO 5.0M MAST)

SN: 550001-UP

2шт.

|$32

3EB-72-31430

RUBBER,(FOR 5.5M AND 6.0M MAST)

SN: 550001-UP

4шт.

10

3EB-71-31460

PIPE,(FOR 3.0M TO 5.0M MAST)

SN: 550001-UP

4шт.

|$34

3EB-71-31460

PIPE,(FOR 5.5M AND 6.0M MAST)

SN: 550001-UP

8шт.

11

01010-81025

BOLT,(FOR 3.0M TO 5.0M MAST)

SN: 550001-UP

4шт.

|$36

01010-81025

BOLT,(FOR 5.5M AND 6.0M MAST)

SN: 550001-UP

8шт.

12

01643-31032

WASHER,(FOR 3.0M TO 5.0M MAST)

SN: 550001-UP

4шт.

|$38

01643-31032

WASHER,(FOR 5.5M AND 6.0M MAST)

SN: 550001-UP

8шт.

13

3EB-71-00070

SHIM ASS'Y

SN: 550001-UP

1шт.

|$40

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$41

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

|$42

0

SHIM, 2.3MM

SN: 550001-UP

-2шт.

14

01016-81030

BOLT

SN: 550001-UP

2шт.

15

01580-11008

NUT

SN: 550001-UP

2шт.

16

34B-72-51150

SHEAVE

SN: 550001-UP

2шт.

17

01582-11613

NUT

SN: 550001-UP

6шт.

18

303-70-11471

NUT

SN: 550001-UP

2шт.

19

37B-9AC-2030

SHIM, 1.0MM

SN: 550001-UP

4шт.

|$49

37B-9AC-2040

SHIM, 2.3MM

SN: 550001-UP

2шт.

20

04064-04018

RING,SNAP

SN: 550001-UP

2шт.

21

37B-9AA-1312

ROLLER,S

SN: 550001-UP

2шт.

|$52

37B-9AA-1322

ROLLER,M

SN: 550001-UP

2шт.

|$53

37B-9AA-1332

ROLLER,L

SN: 550001-UP

2шт.

22

3EB-71-00080

SHIM ASS'Y

SN: 550001-UP

1шт.

|$55

0

SHIM, 0.2MM

SN: 550001-UP

-2шт.

|$56

0

SHIM, 0.5MM

SN: 550001-UP

-2шт.

|$57

0

SHIM, 1.0MM

SN: 550001-UP

-2шт.

|$58

0

SHIM, 2.3MM

SN: 550001-UP

-2шт.

23

04064-04518

RING,SNAP

SN: 550001-UP

2шт.

24

01010-80820

BOLT

SN: 550001-UP

4шт.

25

01643-30823

WASHER

SN: 550001-UP

4шт.

26

3EB-71-31380YD

BRACKET,R.H.

SN: 550001-UP

1шт.

27

3EB-71-31390YD

BRACKET,L.H.

SN: 550001-UP

1шт.

28

3EB-71-11242

CAP

SN: 550001-UP

2шт.

29

01643-51645

WASHER

SN: 550001-UP

4шт.

30

01010-81685

BOLT

SN: 550001-UP

4шт.

31

3EB-41-31860

PIN

SN: 550001-UP

2шт.

32

01010-81025

BOLT

SN: 550001-UP

2шт.

33

01602-21030

WASHER,SPRING

SN: 550001-UP

2шт.
