Запчасти Komatsu FD30N-16 УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) (/) (LIFT СЕКЦ. БЛОК) ГИДРАВЛИКА

|$$1

PLEASE USE THE CONTROL VALVE FOR 3T WHEN THE TRUCKS ARE 2T AND 2.5T PROVIDED WITH FV MAST OF 5.5M OR MORE.

-1шт.

|$22

37B-1LA-5211

CONTROL VALVE ASS'Y,2-SPOOL (FOR 2.0T - 2.5T)

SN: 708772-UP

1шт.

|$23

37B-1LA-5210

CONTROL VALVE ASS'Y,2-SPOOL (FOR 2.0T - 2.5T)

SN: 700001-708771

1шт.

|$24

37B-1LA-5221

CONTROL VALVE ASS'Y,2-SPOOL (FOR 3.0T)

SN: 708772-UP

1шт.

|$25

37B-1LA-5220

CONTROL VALVE ASS'Y,2-SPOOL (FOR 3.0T)

SN: 700001-708771

1шт.

|$26

37B-1LA-5231

CONTROL VALVE ASS'Y,2-SPOOL (FOR 3.5T)

SN: 708772-UP

1шт.

|$27

37B-1LA-5230

CONTROL VALVE ASS'Y,2-SPOOL (FOR 3.5T)

SN: 700001-708771

1шт.

|$28

37B-1LA-5311

CONTROL VALVE ASS'Y,3-SPOOL (FOR 2.0T - 2.5T)

SN: 708772-UP

1шт.

|$29

37B-1LA-5310

CONTROL VALVE ASS'Y,3-SPOOL (FOR 2.0T - 2.5T)

SN: 700001-708771

1шт.

|$30

37B-1LA-5321

CONTROL VALVE ASS'Y,3-SPOOL (FOR 3.0T)

SN: 708772-UP

1шт.

|$31

37B-1LA-5320

CONTROL VALVE ASS'Y,3-SPOOL (FOR 3.0T)

SN: 700001-708771

1шт.

|$32

37B-1LA-5331

CONTROL VALVE ASS'Y,3-SPOOL (FOR 3.5T)

SN: 708772-UP

1шт.

|$33

37B-1LA-5330

CONTROL VALVE ASS'Y,3-SPOOL (FOR 3.5T)

SN: 700001-708771

1шт.

|$34

37B-1LB-5311

CONTROL VALVE ASS'Y,3-SPOOL

SN: 708772-UP

1шт.

|$35

37B-1LB-5310

CONTROL VALVE ASS'Y,3-SPOOL

SN: 700001-708771

1шт.

|$$16

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$37

37B-1LB-5321

CONTROL VALVE ASS'Y,3-SPOOL

SN: 708772-UP

1шт.

|$38

37B-1LB-5320

CONTROL VALVE ASS'Y,3-SPOOL

SN: 700001-708771

1шт.

|$$19

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$40

37B-1LB-5331

CONTROL VALVE ASS'Y,3-SPOOL

SN: 708772-UP

1шт.

|$41

37B-1LB-5330

CONTROL VALVE ASS'Y,3-SPOOL

SN: 700001-708771

1шт.

|$$22

(FOR 3.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$43

37B-1LA-5411

CONTROL VALVE ASS'Y,4-SPOOL (FOR 2.0T - 2.5T)

SN: 708772-UP

1шт.

|$44

37B-1LA-5410

CONTROL VALVE ASS'Y,4-SPOOL (FOR 2.0T - 2.5T)

SN: 700001-708771

1шт.

|$45

37B-1LA-5421

CONTROL VALVE ASS'Y,4-SPOOL (FOR 3.0T)

SN: 708772-UP

1шт.

|$46

37B-1LA-5420

CONTROL VALVE ASS'Y,4-SPOOL (FOR 3.0T)

SN: 700001-708771

1шт.

|$47

37B-1LA-5431

CONTROL VALVE ASS'Y,4-SPOOL (FOR 3.5T)

SN: 708772-UP

1шт.

|$48

37B-1LA-5430

CONTROL VALVE ASS'Y,4-SPOOL (FOR 3.5T)

SN: 700001-708771

1шт.

|$49

37B-1LC-5411

CONTROL VALVE ASS'Y,4-SPOOL

SN: 708772-UP

1шт.

|$50

37B-1LC-5410

CONTROL VALVE ASS'Y,4-SPOOL

SN: 700001-708771

1шт.

|$$31

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$52

37B-1LC-5421

CONTROL VALVE ASS'Y,4-SPOOL

SN: 708772-UP

1шт.

|$53

37B-1LC-5420

CONTROL VALVE ASS'Y,4-SPOOL

SN: 700001-708771

1шт.

|$$34

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$55

37B-1LC-5431

CONTROL VALVE ASS'Y,4-SPOOL

SN: 708772-UP

1шт.

|$56

37B-1LC-5430

CONTROL VALVE ASS'Y,4-SPOOL

SN: 700001-708771

1шт.

|$$37

(FOR 3.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$58

37B-1LA-5511

CONTROL VALVE ASS'Y,5-SPOOL (FOR 2.0T - 2.5T)

SN: 708772-UP

1шт.

|$59

37B-1LA-5510

CONTROL VALVE ASS'Y,5-SPOOL (FOR 2.0T - 2.5T)

SN: 700001-708771

1шт.

|$60

37B-1LA-5521

CONTROL VALVE ASS'Y,5-SPOOL (FOR 3.0T)

SN: 708772-UP

1шт.

|$61

37B-1LA-5520

CONTROL VALVE ASS'Y,5-SPOOL (FOR 3.0T)

SN: 700001-708771

1шт.

|$62

37B-1LA-5531

CONTROL VALVE ASS'Y,5-SPOOL (FOR 3.5T)

SN: 708772-UP

1шт.

|$63

37B-1LA-5530

CONTROL VALVE ASS'Y,5-SPOOL (FOR 3.5T)

SN: 700001-708771

1шт.

|$64

37B-1LC-5511

CONTROL VALVE ASS'Y,5-SPOOL

SN: 708772-UP

1шт.

|$65

37B-1LC-5510

CONTROL VALVE ASS'Y,5-SPOOL

SN: 700001-708771

1шт.

|$$46

(FOR 2.0T - 2.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$67

37B-1LC-5521

CONTROL VALVE ASS'Y,5-SPOOL

SN: 708772-UP

1шт.

|$68

37B-1LC-5520

CONTROL VALVE ASS'Y,5-SPOOL

SN: 700001-708771

1шт.

|$$49

(FOR 3.0T),(WITH PORT RELIEF VALVE)

-1шт.

|$70

37B-1LC-5531

CONTROL VALVE ASS'Y,5-SPOOL

SN: 708772-UP

1шт.

|$71

37B-1LC-5530

CONTROL VALVE ASS'Y,5-SPOOL

SN: 700001-708771

1шт.

|$$52

(FOR 3.5T),(WITH PORT RELIEF VALVE)

-1шт.

|$$53

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.R4140-51A0 TO R4140-54A1.

-1шт.

|$74

30B-61-11110

SPOOL SECTION ASS'Y,LIFT (FOR 2.0T - 2.5T)

SN: 700001-UP

1шт.

|$75

30B-61-11120

SPOOL SECTION ASS'Y,LIFT (FOR 3.0T)

SN: 700001-UP

1шт.

|$76

30B-61-11340

SPOOL SECTION ASS'Y,LIFT (FOR 3.5T)

SN: 700001-UP

1шт.

1

0

HOUSING

SN: 700001-UP

1шт.

2

0

SPOOL

SN: 700001-UP

1шт.

3

30A-61-11140

PLATE

SN: 700001-UP

2шт.

4

30A-61-11150

O-RING

SN: 700001-UP

2шт.

5

30A-61-11160

WIPER

SN: 700001-UP

2шт.

6

30A-61-11170

CAP

SN: 700001-UP

1шт.

7

30A-61-11180

SEAT

SN: 700001-UP

2шт.

8

30A-61-11190

SCREW,CAP

SN: 700001-UP

1шт.

9

30A-61-11210

SPRING

SN: 700001-UP

1шт.

10

30A-61-11220

SCREW

SN: 700001-UP

2шт.

11

30A-61-11230

BOLT

SN: 700001-UP

2шт.

12

30A-61-11590

POPPET

SN: 700001-UP

1шт.

13

30A-61-11610

SPRING

SN: 700001-UP

1шт.

14

30A-61-11250

PLUG

SN: 700001-UP

2шт.

15

30A-61-11260

O-RING

SN: 700001-UP

1шт.

16

30A-61-11240

SOLENOID VALVE

SN: 700001-UP

1шт.

17

30A-61-11270

PLUG

SN: 700001-UP

2шт.

18

30A-61-11280

O-RING

SN: 700001-UP

2шт.

19

30A-61-11290

POPPET

SN: 700001-UP

1шт.

20

30A-61-11310

SPRING

SN: 708772-UP

1шт.

|$97

30A-61-11310

SPRING

SN: 700001-708771

2шт.

20A

30A-61-11311

SPRING

SN: 708772-UP

1шт.

21

30A-61-11320

SPRING

SN: 700001-UP

1шт.

22

0

SPOOL,(FOR 2.0T - 2.5T)

SN: 700001-UP

1шт.

|$101

0

SPOOL,(FOR 3.0T)

SN: 700001-UP

1шт.

|$102

0

SPOOL,(FOR 3.5T)

SN: 700001-UP

1шт.

23

30A-61-11340

BALL,STEEL

SN: 700001-UP

1шт.

24

30A-61-11350

SPRING

SN: 700001-UP

1шт.

25

30A-61-11370

PLUG

SN: 700001-UP

1шт.

26

30A-61-11380

O-RING

SN: 700001-UP

1шт.

27

0

PLATE, NAME,NAME

SN: 700001-UP

1шт.

28

30A-61-11580

SCREW

SN: 700001-UP

2шт.

29

30A-61-11470

VALVE ASS'Y,SHUT OFF

SN: 700001-UP

1шт.

30

30A-61-12050

O-RING

SN: 700001-UP

1шт.

31

30A-61-12060

O-RING

SN: 700001-UP

1шт.

32

30A-61-11631

POPPET

SN: 708772-UP

1шт.

|$113

30A-61-11630

POPPET

SN: 700001-708771

1шт.

33

30A-61-11620

PLUG

SN: 700001-UP

1шт.

34

30A-61-11360

SOLENOID VALVE

SN: 700001-UP

1шт.

35

30A-61-11640

PLUG

SN: 700001-UP

1шт.

36

30A-61-11650

O-RING

SN: 700001-UP

1шт.

37

30B-61-11330

RELIEF VALVE ASS'Y

SN: 700001-UP

1шт.

38

30A-61-11650

O-RING

SN: 700001-UP

1шт.
