Запчасти Komatsu FD35Y 3-Х СЕКЦИОНН. КОНТРОЛЬН. КЛАПАН TFV МАЧТА ТРУБЫ (С ЦИЛИНДР) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

45C-1MG-3130SG

PIPE

SN: 133001-UP

1шт.

2

45C-1MG-3140SG

PIPE

SN: 133001-UP

1шт.

3

01010-80820

BOLT

SN: 133001-UP

2шт.

4

01602-20825

WASHER,SPRING

SN: 133001-UP

2шт.

5

45C-1MG-3160SG

BRACKET

SN: 133001-UP

1шт.

6

01010-80825

BOLT

SN: 133001-UP

2шт.

7

01602-20825

WASHER,SPRING

SN: 133001-UP

2шт.

8

45C-1MG-3190SG

BRACKET

SN: 133001-UP

2шт.

9

01010-80825

BOLT

SN: 133001-UP

4шт.

10

01643-50823

WASHER

SN: 133001-UP

4шт.

11

45A-271-1370SG

CLAMP

SN: 133001-UP

2шт.

12

01010-80830

BOLT

SN: 133001-UP

2шт.

13

01602-20825

WASHER,SPRING

SN: 133001-UP

2шт.

14

46B-5MG-1010SF

CLAMP

SN: 133001-UP

1шт.

15

01010-80825

BOLT

SN: 133001-UP

1шт.

16

01602-20825

WASHER,SPRING

SN: 133001-UP

1шт.

17

300-62-31820

CLIP

SN: 133001-UP

4шт.

18

01010-80820

BOLT

SN: 133001-UP

4шт.

19

01602-20825

WASHER,SPRING

SN: 133001-UP

4шт.

20

01642-20810

WASHER

SN: 133001-UP

4шт.

21

46B-1MT-3090SG

PULLEY

SN: 133001-UP

4шт.

22

46B-1MT-3080

SHAFT

SN: 133001-UP

4шт.

23

3MA-73-13180

BUSHING

SN: 133001-UP

8шт.

24

34A-43-11471

SHIM, 1.0MM

SN: 133001-UP

4шт.

|$34

34A-43-11461

SHIM, 0.5MM

SN: 133001-UP

4шт.

25

04064-01210

RING,SNAP

SN: 133001-UP

4шт.

26

45C-1MG-3181UE

BRACKET

SN: 133001-UP

1шт.

27

01010-81025

BOLT

SN: 133001-UP

2шт.

28

01580-11008

NUT

SN: 133001-UP

2шт.

29

45C-1MG-3210UE

COVER

SN: 133001-UP

1шт.

30

37A-ZDP-1180SG

PIPE

SN: 133001-UP

3шт.

31

01010-81075

BOLT

SN: 133001-UP

2шт.

32

01580-11008

NUT

SN: 133001-UP

2шт.

33

01602-21030

WASHER,SPRING

SN: 133001-UP

2шт.

34

37A-232-1050

SHAFT

SN: 133001-UP

1шт.

35

04064-01010

RING,SNAP

SN: 133001-UP

1шт.

36

300-01-31380

SHIM, 0.5MM

SN: 133001-UP

2шт.

37

01010-81025

BOLT

SN: 133001-UP

2шт.

38

45C-1MG-3110SG

BRACKET

SN: 133001-UP

2шт.

39

46C-1MG-5120SG

PULLEY

SN: 133001-UP

2шт.

40

45C-1MG-3120

WASHER

SN: 133001-UP

2шт.

41

06002-06205

BEARING

SN: 133001-UP

4шт.

42

04064-02512

RING

SN: 133001-UP

2шт.

43

04065-05220

RING

SN: 133001-UP

2шт.

44

01602-21030

WASHER,SPRING

SN: 133001-UP

2шт.

45

37C-ZET-3020SG

PIPE,(FOR 3.7M AND 4.0M MAST)

SN: 133001-UP

1шт.

|$64

37C-ZET-3010SG

PIPE,(FOR 4.3M TO 5.0M MAST)

SN: 133001-UP

1шт.

|$65

37C-ZET-3030SG

PIPE,(FOR 5.5M AND 6.0M MAST)

SN: 133001-UP

1шт.

46

37C-ZEU-3020SG

PIPE,(FOR 3.7M AND 4.0M MAST)

SN: 133001-UP

1шт.

|$67

37C-ZEU-3010SG

PIPE,(FOR 4.3M TO 5.0M MAST)

SN: 133001-UP

1шт.

|$68

37C-ZEU-3030SG

PIPE,(FOR 5.5M AND 6.0M MAST)

SN: 133001-UP

1шт.

47

37C-ZEX-3010SG

PIPE,(FOR 3.7M TO 4.3M MAST)

SN: 133001-UP

1шт.

|$70

37C-ZEX-3020SG

PIPE,(FOR 4.5M TO 5.0M MAST)

SN: 133001-UP

1шт.

|$71

37C-ZEX-3030SG

PIPE,(FOR 5.5M AND 6.0M MAST)

SN: 133001-UP

1шт.

48

37C-ZEY-3010SG

PIPE,(FOR 3.7M TO 4.3M MAST)

SN: 133001-UP

1шт.

|$73

37C-ZEY-3020SG

PIPE,(FOR 4.5M TO 5.0M MAST)

SN: 133001-UP

1шт.

|$74

37C-ZEY-3030SG

PIPE,(FOR 5.5M AND 6.0M MAST)

SN: 133001-UP

1шт.

49

37A-684-4340

HOSE,(FOR 3.7M MAST)

SN: 133001-UP

2шт.

|$76

37A-684-4380

HOSE,(FOR 4.0M AND 4.3M MAST)

SN: 133001-UP

2шт.

|$77

37A-684-4420

HOSE,(FOR 4.5M MAST)

SN: 133001-UP

2шт.

|$78

37A-684-4460

HOSE,(FOR 4.7M MAST)

SN: 133001-UP

2шт.

|$79

37A-684-4500

HOSE,(FOR 5.0M MAST)

SN: 133001-UP

2шт.

|$80

37A-684-4490

HOSE,(FOR 5.5M MAST)

SN: 133001-UP

2шт.

|$81

37A-684-4570

HOSE,(FOR 6.0M MAST)

SN: 133001-UP

2шт.

50

37R-TEX-6250

HOSE,(FOR 3.7M MAST)

SN: 133001-UP

1шт.

|$83

37R-TEX-6270

HOSE,(FOR 4.0M MAST)

SN: 133001-UP

1шт.

|$84

37R-TEX-6290

HOSE,(FOR 4.3M AND 4.5M MAST)

SN: 133001-UP

1шт.

|$85

37R-TEX-6300

HOSE,(FOR 4.7M MAST)

SN: 133001-UP

1шт.

|$86

37R-TEX-6320

HOSE,(FOR 5.0M MAST)

SN: 133001-UP

1шт.

|$87

37R-TEX-6340

HOSE,(FOR 5.5M MAST)

SN: 133001-UP

1шт.

|$88

37R-TEX-6380

HOSE,(FOR 6.0M MAST)

SN: 133001-UP

1шт.
