Запчасти Komatsu FD35Y TFV МАЧТА (/) (LIFT ТРУБЫ) МАЧТА КОМПОНЕНТЫ

1

3EC-71-56510UE

BLOCK

SN: 133001-UP

1шт.

2

02896-11015

O-RING

SN: 133001-UP

1шт.

3

01024-81025

BOLT

SN: 133001-UP

2шт.

4

3EC-T1-57210SG

PIPE

SN: 133001-UP

1шт.

5

01010-80825

BOLT

SN: 133001-UP

2шт.

6

01602-20825

WASHER,SPRING

SN: 133001-UP

2шт.

7

07086-00605

HOSE

SN: 133001-UP

1шт.

8

3EC-T1-57260

HOSE

SN: 133001-UP

1шт.

9

3EC-72-56710

HOSE

SN: 133001-UP

1шт.

10

3EC-T1-57250

TEE

SN: 133001-UP

1шт.

11

07000-12018

O-RING

SN: 133001-UP

1шт.

12

3EC-T1-37310

VALVE ASS'Y,DOWN SAFETY

SN: 133001-UP

1шт.

13

3EC-T1-57110

TEE

SN: 133001-UP

1шт.

14

07002-12434

O-RING

SN: 133001-UP

1шт.

15

3EC-T1-37150

CLAMP

SN: 133001-UP

2шт.

16

01010-80825

BOLT

SN: 133001-UP

2шт.

17

01602-20825

WASHER,SPRING

SN: 133001-UP

2шт.

18

01580-10806

NUT

SN: 133001-UP

2шт.

19

37B-UAX-1130

HOSE,(FOR 3.7M MAST)

SN: 133001-UP

2шт.

|$31

37B-UAX-1150

HOSE,(FOR 4.0M MAST)

SN: 133001-UP

2шт.

|$32

37B-UAX-1170

HOSE,(FOR 4.3M MAST)

SN: 133001-UP

2шт.

|$33

37B-UAX-1190

HOSE,(FOR 4.5M MAST)

SN: 133001-UP

2шт.

|$34

37B-UAX-1210

HOSE,(FOR 4.7M MAST)

SN: 133001-UP

2шт.

|$35

37B-UAX-1230

HOSE,(FOR 5.0M MAST)

SN: 133001-UP

2шт.

|$36

37B-UAX-1260

HOSE,(FOR 5.5M MAST)

SN: 133001-UP

2шт.

|$37

37B-UAX-1300

HOSE,(FOR 6.0M MAST)

SN: 133001-UP

2шт.

|$38

37B-UAX-1350

HOSE,(FOR 6.5M MAST)

SN: 133001-UP

2шт.

|$39

37B-UAX-1390

HOSE,(FOR 7.0M MAST)

SN: 133001-UP

2шт.

20

37C-TAX-5370SG

PIPE,R.H. (FOR 3.7M MAST)

SN: 133001-UP

1шт.

|$41

37C-TAX-5400SG

PIPE,R.H. (FOR 4.0M MAST)

SN: 133001-UP

1шт.

|$42

37C-TAX-5430SG

PIPE,R.H. (FOR 4.3M MAST)

SN: 133001-UP

1шт.

|$43

37C-TAX-5450SG

PIPE,R.H. (FOR 4.5M MAST)

SN: 133001-UP

1шт.

|$44

37C-TAX-5470SG

PIPE,R.H. (FOR 4.7M MAST)

SN: 133001-UP

1шт.

|$45

37C-TAX-5500SG

PIPE,R.H. (FOR 5.0M MAST)

SN: 133001-UP

1шт.

|$46

37C-TAX-5550SG

PIPE,R.H. (FOR 5.5M MAST)

SN: 133001-UP

1шт.

|$47

37C-TAX-5600SG

PIPE,R.H. (FOR 6.0M MAST)

SN: 133001-UP

1шт.

|$48

37C-TAX-5650SG

PIPE,R.H. (FOR 6.5M MAST)

SN: 133001-UP

1шт.

|$49

37C-TAX-5700SG

PIPE,R.H. (FOR 7.0M MAST)

SN: 133001-UP

1шт.

21

37C-TAY-5370SG

PIPE,L.H. (FOR 3.7M MAST)

SN: 133001-UP

1шт.

|$51

37C-TAY-5400SG

PIPE,L.H. (FOR 4.0M MAST)

SN: 133001-UP

1шт.

|$52

37C-TAY-5430SG

PIPE,L.H. (FOR 4.3M MAST)

SN: 133001-UP

1шт.

|$53

37C-TAY-5450SG

PIPE,L.H. (FOR 4.5M MAST)

SN: 133001-UP

1шт.

|$54

37C-TAY-5470SG

PIPE,L.H. (FOR 4.7M MAST)

SN: 133001-UP

1шт.

|$55

37C-TAY-5500SG

PIPE,L.H. (FOR 5.0M MAST)

SN: 133001-UP

1шт.

|$56

37C-TAY-5550SG

PIPE,L.H. (FOR 5.5M MAST)

SN: 133001-UP

1шт.

|$57

37C-TAY-5600SG

PIPE,L.H. (FOR 6.0M MAST)

SN: 133001-UP

1шт.

|$58

37C-TAY-5650SG

PIPE,L.H. (FOR 6.5M MAST)

SN: 133001-UP

1шт.

|$59

37C-TAY-5700SG

PIPE,L.H. (FOR 7.0M MAST)

SN: 133001-UP

1шт.

22

01010-81235

BOLT

SN: 133001-UP

2шт.

23

01602-21236

WASHER,SPRING

SN: 133001-UP

2шт.

24

01643-31232

WASHER

SN: 133001-UP

2шт.
