Запчасти Komatsu FD35Y ЦИЛИНДР ПЕРЕКОСА ГИДРАВЛИКА

|$2

37C-1AT-5010XC

TILT CYLINDER ASS'Y,(6Я/12Я)

SN: 133001-UP

2шт.

|$3

37C-1AT-5020XC

TILT CYLINDER ASS'Y,(8Я/5Я)

SN: 133001-UP

2шт.

1

30C-63-11110

CYLINDER SUB ASS'Y

SN: 133001-UP

1шт.

2

37C-1AW-3010

ROD,(6Я/12Я)

SN: 133001-UP

1шт.

|$6

37C-1AW-3040

ROD ASS'Y,(8Я/5Я)

SN: 133001-UP

1шт.

3

30C-63-11120

PISTON

SN: 133001-UP

1шт.

4

01580-13326

NUT

SN: 133001-UP

1шт.

5

30C-63-11130

HEAD

SN: 133001-UP

1шт.

6

3EC-64-32280

BUSHING

SN: 133001-UP

1шт.

7

30C-63-11140

PACKING (KIT)

SN: 133001-UP

2шт.

8

30C-63-11150

RING,BACK UP (KIT)

SN: 133001-UP

1шт.

9

30C-63-11160

PACKING (KIT)

SN: 133001-UP

1шт.

10

30C-63-11170

RING,BACK UP (KIT)

SN: 133001-UP

1шт.

11

30C-63-11180

SEAL,DUST (KIT)

SN: 133001-UP

1шт.

12

30C-63-11190

O-RING (KIT)

SN: 133001-UP

1шт.

13

30C-63-11210

RING,BACK UP (KIT)

SN: 133001-UP

1шт.

14

07000-12090

O-RING (KIT)

SN: 133001-UP

1шт.

15

30C-63-11220

HEAD

SN: 133001-UP

1шт.

16

30C-63-11230

BUSHING

SN: 133001-UP

1шт.

17

07145-00035

SEAL,DUST

SN: 133001-UP

2шт.

18

01010-81475

BOLT

SN: 133001-UP

1шт.

19

01580-11411

NUT

SN: 133001-UP

1шт.

20

01602-21442

WASHER

SN: 133001-UP

1шт.

21

07020-00001

FITTING,GREASE

SN: 133001-UP

1шт.

22

3EC-64-32260

BUSHING

SN: 133001-UP

2шт.

|$$26

SERVICE KIT

-1шт.

KIT

30C-63-11240

SEAL KIT,TILT CYLINDER

SN: 133001-UP

2шт.
