Запчасти Komatsu FD50A-7 УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) (/) (ВХОДН. SECTION И LIFT СЕКЦ. БЛОК) ГИДРАВЛИКА

|$16

3EC-61-35210

CONTROL VALVE ASS'Y,2-SPOOL

SN: 100001-UP

1шт.

|$17

3EC-61-35310

CONTROL VALVE ASS'Y,3-SPOOL

SN: 100001-UP

1шт.

|$18

3EC-61-35610

CONTROL VALVE ASS'Y,3-SPOOL

SN: 100001-UP

1шт.

|$19

3EC-61-35410

CONTROL VALVE ASS'Y,4-SPOOL

SN: 100001-UP

1шт.

|$20

3EC-61-35710

CONTROL VALVE ASS'Y,4-SPOOL

SN: 100001-UP

1шт.

|$21

3EC-61-35910

CONTROL VALVE ASS'Y,4-SPOOL

SN: 100001-UP

1шт.

|$22

3EC-61-35510

CONTROL VALVE ASS'Y,5-SPOOL

SN: 100001-UP

1шт.

|$23

3EC-61-35810

CONTROL VALVE ASS'Y,5-SPOOL

SN: 100001-UP

1шт.

|$24

3EC-61-35220

CONTROL VALVE ASS'Y,2-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$25

3EC-61-35320

CONTROL VALVE ASS'Y,3-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$26

3EC-61-35620

CONTROL VALVE ASS'Y,3-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$27

3EC-61-35420

CONTROL VALVE ASS'Y,4-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$28

3EC-61-35720

CONTROL VALVE ASS'Y,4-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$29

3EC-61-35920

CONTROL VALVE ASS'Y,4-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$30

3EC-61-35520

CONTROL VALVE ASS'Y,5-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$31

3EC-61-35820

CONTROL VALVE ASS'Y,5-SPOOL (FOR FG50A)

SN: 100001-UP

1шт.

|$$17

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.R4140-51A0 TO R4140-54A0.

-1шт.

|$33

KBC0013-40001

INLET SECTION ASS'Y

SN: 100001-UP

1шт.

1

KBC0011-40001

HOUSING

SN: 100001-UP

1шт.

2

3BD-61-11160

O-RING

SN: 100001-UP

1шт.

3

0

PLATE, NAME

SN: 100001-UP

1шт.

4

0

SCREW

SN: 100001-UP

4шт.

5

0

SPOOL

SN: 100001-UP

1шт.

6

3ED-61-41120

SPRING

SN: 100001-UP

1шт.

7

3ED-61-41130

PLUG

SN: 100001-UP

1шт.

8

3ED-61-41140

PLUG

SN: 100001-UP

1шт.

9

3BD-61-11950

O-RING

SN: 100001-UP

2шт.

10

0

ORIFICE

SN: 100001-UP

1шт.

11

KB21001-01174

SEAT

SN: 100001-UP

2шт.

12

3ED-61-41060

VALVE ASS'Y,RELIEF

SN: 100001-UP

1шт.

13

3BD-61-11950

O-RING

SN: 100001-UP

1шт.

14

3ED-61-41070

VALVE ASS'Y

SN: 100001-UP

1шт.

|$48

3ED-61-41240

SEAL KIT

SN: 100001-UP

1шт.

15

3ED-61-41190

O-RING

SN: 100001-UP

1шт.

16

3BD-61-11940

O-RING

SN: 100001-UP

1шт.

|$51

KB21003-00383

PLUG ASS'Y

SN: 100001-UP

2шт.

17

KB97161-03121

PLUG

SN: 100001-UP

1шт.

18

3EE-61-22560

O-RING

SN: 100001-UP

1шт.

|$54

KBC0013-41002

SPOOL SECTION ASS'Y,LIFT

SN: 100001-UP

1шт.

19

0

HOUSING

SN: 100001-UP

1шт.

20

0

SPOOL

SN: 100001-UP

1шт.

21

3ED-61-41160

HEAD

SN: 100001-UP

1шт.

22

3BD-61-11140

POPPET

SN: 100001-UP

1шт.

23

3BD-61-11150

SPRING

SN: 100001-UP

1шт.

24

3BD-61-11160

O-RING

SN: 100001-UP

1шт.

25

3ED-61-41170

WASHER,SPRING

SN: 100001-UP

1шт.

26

3BD-61-11170

O-RING

SN: 100001-UP

2шт.

27

3BD-61-11180

WIPER

SN: 100001-UP

2шт.

28

3BD-61-11190

SCREW

SN: 100001-UP

2шт.

29

3BD-61-11230

PLATE

SN: 100001-UP

2шт.

30

3BD-61-11350

SCREW,CAP

SN: 100001-UP

1шт.

31

3BD-61-11360

SEAT,SPRING

SN: 100001-UP

2шт.

32

3BD-61-11240

SPRING

SN: 100001-UP

1шт.

33

3BD-61-11250

CAP

SN: 100001-UP

1шт.

34

3BD-61-11480

BOLT

SN: 100001-UP

2шт.

35

3BD-61-11950

O-RING

SN: 100001-UP

1шт.

36

3ED-61-41140

PLUG

SN: 100001-UP

1шт.
