Запчасти Komatsu FD50 МАРКИРОВКА МАРКИРОВКА

1

0

CAPACITY CHART,(FOR LOAD CAPACITY 5 TON)

SN: 46001-UP

1шт.

|$5

0

CAPACITY CHART,(FOR LOAD CAPACITY 6 TON)

SN: 46001-UP

1шт.

|$6

0

CAPACITY CHART,(FOR LOAD CAPACITY 7 TON)

SN: 46001-UP

1шт.

|$7

0

CAPACITY CHART,(FOR LOAD CAPACITY 8 TON)

SN: 46001-UP

1шт.

2

0

CHART, CAPACITY,(WHEN ATTACHMENT EQUIPED)

SN: 46001-UP

1шт.

3

01370-00508

SCREW

SN: 46001-UP

4шт.

4

09690-C0400

PLATE, MARK,KOMATSU

SN: 46001-UP

2шт.

5

3EB-96-25131

PLATE, CAUTION,FORK

SN: 46001-UP

2шт.

6

3EB-96-25121

PLATE, CAUTION,FORK CARRIAGE

SN: 46001-UP

1шт.

7

3EC-96-32110

MARK,KOMATSU

SN: 46001-UP

1шт.

8

0

PLATE, NAME,VEHICLE NO. AND SPEC.

SN: 46001-UP

1шт.

9

01370-00508

SCREW

SN: 46001-UP

4шт.

10

3EB-96-31520

CHART, MAINTENANCE

SN: 46001-UP

1шт.

11

37B-1QB-3010

PLATE, NAME,FUEL (FOR FD ALL)

SN: 46001-UP

1шт.

12

37B-1QD-3010

PLATE, NAME,HYDRAULIC OIL

SN: 46001-UP

1шт.

13

34A-96-16710

PLATE, NAME,ANTIFREEZE SOLUTION (-20ЯC)

SN: 46001-UP

1шт.

|$22

34A-96-16720

PLATE, NAME,ANTIFREEZE SOLUTION (-30ЯC)

SN: 46001-UP

1шт.

|$23

34A-96-16730

PLATE, NAME,ANTIFREEZE SOLUTION (-40ЯC)

SN: 46001-UP

1шт.

|$24

34A-96-16740

PLATE, NAME,ANTIFREEZE SOLUTION (-50ЯC)

SN: 46001-UP

1шт.

14

3EB-96-25770

PLATE, SAFETY,RADIATOR FAN

SN: 46001-UP

1шт.

15

3EB-96-32520

PLATE, MARK,DIMMER SWITCH

SN: 46001-UP

1шт.

16

34C-96-12210

PLATE, NAME,STARTER (FOR FD ALL)

SN: 46001-UP

1шт.

17

3EB-50-12150

MAT,NONSKID

SN: 46001-UP

4шт.

18

37D-1KC-1511

PLATE, CAUTION,ENGINE STOP

SN: 46001-UP

1шт.

19

3EC-96-31910

PLATE,ARROW

SN: 46001-UP

1шт.

20

3FD-96-21120

PLATE,ARROW

SN: 46001-UP

1шт.

21

3EB-96-31710

PLATE

SN: 46001-UP

1шт.

22

3BA-96-59140

PLATE,LIFTING

SN: 46001-UP

4шт.

23

0

PLATE, NAME,VEHICLE NO.

SN: 46001-UP

1шт.

24

04418-13060

SCREW

SN: 46001-UP

4шт.

25

3EB-96-25721

PLATE, CAUTION

SN: 46001-UP

1шт.

26

3EF-96-12122

PLATE, CAUTION,(FOR LOAD CAPACITY 8 TON)

SN: 46001-UP

1шт.

27

37C-1QN-3010

PLATE, CAUTION

SN: 46001-UP

1шт.

28

37C-1QK-3050

PLATE, MARK,5.0 TON

SN: 46001-UP

2шт.

|$46

37D-1QL-2020

PLATE, MARK,6.0 TON

SN: 46001-UP

2шт.

|$47

37D-1QL-2030

PLATE, MARK,7.0 TON

SN: 46001-UP

2шт.

|$48

37D-1QL-2040

PLATE, MARK,8.0 TON

SN: 46001-UP

2шт.

29

37A-2BK-2081

PLATE, CAUTION,AIR PRESSURE OF TIRES (5 TON)

SN: 46001-UP

1шт.

|$50

37A-2BK-2021

PLATE, CAUTION,AIR PRESSURE OF TIRES (6 TON)

SN: 46001-UP

1шт.

|$51

37A-2BK-2031

PLATE, CAUTION,AIR PRESSURE OF TIRES (7 TON)

SN: 46001-UP

1шт.

|$52

37A-2BK-2101

PLATE, CAUTION,AIR PRESSURE OF TIRES (8 TON)

SN: 46001-UP

1шт.
