Запчасти Komatsu FD60-10-US ЦИЛИНДР ПЕРЕКОСА ГИДРАВЛИКА

|$3

37D-1AT-3010UE

TILT CYLINDER ASS'Y,(6Я/12Я)

SN: 55001-UP

2шт.

|$4

37D-1AT-3020UE

TILT CYLINDER ASS'Y,(6Я/6Я)

SN: 55001-UP

2шт.

|$5

37D-1AT-3030UE

TILT CYLINDER ASS'Y,(6Я/10Я)

SN: 55001-UP

2шт.

1

37D-1AU-3010

CYLINDER ASS'Y

SN: 55001-UP

1шт.

2

3ED-64-45130

BUSHING

SN: 55001-UP

2шт.

3

3ED-64-45331

HEAD,CYLINDER

SN: 55001-UP

1шт.

4

45B-1HF-1281

PACKING (KIT)

SN: 55001-UP

1шт.

5

3ED-64-45360

SEAL (KIT)

SN: 55001-UP

1шт.

6

3ED-64-45510

PACKING (KIT)

SN: 55001-UP

1шт.

7

07000-15090

O-RING (KIT)

SN: 55001-UP

1шт.

8

07000-02100

O-RING (KIT)

SN: 55001-UP

1шт.

9

37D-1AW-1110

ROD,(FOR TILT ANGLE 6Я/12Я)

SN: 55001-UP

1шт.

|$18

37D-1AW-1130

ROD,(FOR TILT ANGLE 6Я/6Я)

SN: 55001-UP

1шт.

|$19

37D-1AW-1270

ROD,(FOR TILT ANGLE 6Я/10Я)

SN: 55001-UP

1шт.

10

3ED-64-45341

PISTON

SN: 55001-UP

1шт.

11

3EC-64-13210

NUT

SN: 55001-UP

1шт.

|$22

3ED-64-45910UE

HEAD ASS'Y

SN: 55001-UP

1шт.

12

3ED-64-45380

HEAD,ROD

SN: 55001-UP

1шт.

13

3EC-64-13190

BUSHING

SN: 55001-UP

1шт.

14

01010-81480

BOLT

SN: 55001-UP

1шт.

15

01602-21442

WASHER,SPRING

SN: 55001-UP

1шт.

16

01580-11411

NUT

SN: 55001-UP

1шт.

17

3ED-64-45720

COLLAR,(FOR TILT ANGLE 6Я/6Я)

SN: 55001-UP

1шт.

|$29

3FD-64-21310

COLLAR,(FOR TILT ANGLE 6Я/10Я)

SN: 55001-UP

1шт.

|$$25

SERVICE KIT

-1шт.

KIT

3ED-64-05061

REPAIR KIT,TILT CYLINDER

SN: 55001-UP

2шт.
