Запчасти Komatsu FB20HB УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) (ДЛЯ ПРОПОРЦИОНАЛЬН. СОЛЕНОИДНЫЙ КЛАПАН) ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
|$7
3BA-61-51212
CONTROL VALVE ASS'Y,(FOR 2CV)
SN: 814001-UP
1шт.
|$8
3BA-61-51312
CONTROL VALVE ASS'Y,(FOR 3CV)
SN: 814001-UP
1шт.
|$9
3BA-61-51412
CONTROL VALVE ASS'Y,(FOR 4CV)
SN: 814001-UP
1шт.
|$10
3BA-61-51512
CONTROL VALVE ASS'Y,(FOR 5CV)
SN: 814001-UP
1шт.
|$11
3BA-61-51612
CONTROL VALVE ASS'Y,FOR 3CV WITH PORT RELEF VALVE
SN: 814001-UP
1шт.
|$12
3BA-61-51712
CONTROL VALVE ASS'Y,F0R 4CV WITH PORT RELEF VALVE
SN: 814001-UP
1шт.
|$13
3BA-61-51812
CONTROL VALVE ASS'Y,FOR 5CV WITH PORT RELEF VALVE
SN: 814001-UP
1шт.
1
KHOBP14
PLUG
SN: 814001-UP
8шт.
|$15
KHV981263781
RELIEF VALVE ASS'Y,FOR 3CV WITH PORT RELEF VALVE
SN: 814001-UP
2шт.
|$16
KHV981263781
RELIEF VALVE ASS'Y,F0R 4CV WITH PORT RELEF VALVE
SN: 814001-UP
6шт.
|$17
KHV981263781
RELIEF VALVE ASS'Y,FOR 5CV WITH PORT RELEF VALVE
SN: 814001-UP
8шт.
2
KHPBP116U-2403
PLUG
SN: 814001-UP
8шт.
3
KHOROH14
PLUG
SN: 814001-UP
1шт.
4
KHOORBBP11
O-RING
SN: 814001-UP
8шт.
5
KHV233140-0457
COVER,(FOR 2CV)
SN: 814001-UP
4шт.
|$22
KHV233140-0457
COVER,(FOR 3CV)
SN: 814001-UP
6шт.
|$23
KHV233140-0457
COVER,(FOR 4CV)
SN: 814001-UP
8шт.
|$24
KHV233140-0457
COVER,(FOR 5CV)
SN: 814001-UP
10шт.
6
KHV233140-0357
COVER,(FOR 2CV)
SN: 814001-UP
4шт.
|$26
KHV233140-0357
COVER,(FOR 3CV)
SN: 814001-UP
6шт.
|$27
KHV233140-0357
COVER,(FOR 4CV)
SN: 814001-UP
8шт.
|$28
KHV233140-0357
COVER,(FOR 5CV)
SN: 814001-UP
10шт.
7
KHV0201250672
VALVE
SN: 814001-UP
1шт.
8
KHOSSSM66
SCREW,(FOR 2CV)
SN: 814001-UP
4шт.
|$31
KHOSSSM66
SCREW,(FOR 3CV)
SN: 814001-UP
6шт.
|$32
KHOSSSM66
SCREW,(FOR 4CV)
SN: 814001-UP
8шт.
|$33
KHOSSSM66
SCREW,(FOR 5CV)
SN: 814001-UP
10шт.
9
KHODW532
BALL,(FOR 2CV)
SN: 814001-UP
4шт.
|$35
KHODW532
BALL,(FOR 3CV)
SN: 814001-UP
6шт.
|$36
KHODW532
BALL,(FOR 4CV)
SN: 814001-UP
8шт.
|$37
KHODW532
BALL,(FOR 5CV)
SN: 814001-UP
10шт.
11
KHOSBM516
BOLT,(FOR 2CV)
SN: 814001-UP
8шт.
|$43
KHOSBM516
BOLT,(FOR 3CV)
SN: 814001-UP
12шт.
|$44
KHOSBM516
BOLT,(FOR 4CV)
SN: 814001-UP
16шт.
|$45
KHOSBM516
BOLT,(FOR 5CV)
SN: 814001-UP
20шт.
12
KHOSBM58
BOLT,(FOR 2CV)
SN: 814001-UP
8шт.
|$47
KHOSBM58
BOLT,(FOR 3CV)
SN: 814001-UP
12шт.
|$48
KHOSBM58
BOLT,(FOR 4CV)
SN: 814001-UP
16шт.
|$49
KHOSBM58
BOLT,(FOR 5CV)
SN: 814001-UP
20шт.
13
KHVZ50107146
PLUG,(FOR 2CV)
SN: 814001-UP
2шт.
|$51
KHVZ50107146
PLUG,(FOR 3CV)
SN: 814001-UP
3шт.
|$52
KHVZ50107146
PLUG,(FOR 4CV)
SN: 814001-UP
4шт.
|$53
KHVZ50107146
PLUG,(FOR 5CV)
SN: 814001-UP
5шт.
14
KHVZ5014401
SPRING,(FOR 2CV)
SN: 814001-UP
2шт.
|$55
KHVZ5014401
SPRING,(FOR 3CV)
SN: 814001-UP
3шт.
|$56
KHVZ5014401
SPRING,(FOR 4CV)
SN: 814001-UP
4шт.
|$57
KHVZ5014401
SPRING,(FOR 5CV)
SN: 814001-UP
5шт.
15
KH203340-1258
SPRING
SN: 814001-UP
1шт.
16
KH203340-1257
SPRING
SN: 814001-UP
1шт.
17
KHVZ50107145
PLUG,(FOR 2CV)
SN: 814001-UP
2шт.
|$61
KHVZ50107145
PLUG,(FOR 3CV)
SN: 814001-UP
3шт.
|$62
KHVZ50107145
PLUG,(FOR 4CV)
SN: 814001-UP
4шт.
|$63
KHVZ50107145
PLUG,(FOR 5CV)
SN: 814001-UP
5шт.
18
KH03560-0549
PLUG
SN: 814001-UP
2шт.
19
KHOORBP16
O-RING,(FOR 2CV)
SN: 814001-UP
2шт.
|$66
KHOORBP16
O-RING,(FOR 3CV)
SN: 814001-UP
3шт.
|$67
KHOORBP16
O-RING,(FOR 4CV)
SN: 814001-UP
4шт.
|$68
KHOORBP16
O-RING,(FOR 5CV)
SN: 814001-UP
5шт.
20
KHOORBP14
O-RING
SN: 814001-UP
2шт.
21
KHV9903294588
RELEF VALVE ASS'Y
SN: 814001-UP
1шт.
22
KHVZ03340-0054
SPRING
SN: 814001-UP
1шт.
23
KHVZ03340-1858
SPRING
SN: 814001-UP
1шт.
24
KHVZ33420-0300
ROD
SN: 814001-UP
1шт.
25
KHOROH38
PLUG
SN: 814001-UP
4шт.
26
KHOORBP14
O-RING
SN: 814001-UP
4шт.
27
KHVZ03560-0545
PLUG
SN: 814001-UP
1шт.
28
KHOORBP16
O-RING
SN: 814001-UP
1шт.
30
KHVZ37220-0006
PLATE
SN: 814001-UP
2шт.
31
KHVZ37220-0009
HOUSING
SN: 814001-UP
2шт.
32
KHVZ37220-0010
PLATE
SN: 814001-UP
2шт.
Выбрано товаров: 75
