Запчасти Komatsu FB20M-12 ¤ СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН FV МАЧТА ТРУБЫ (.-.M) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

45B-1MA-5170

CLAMP

SN: 825001-UP

2шт.

2

01024-80830

BOLT

SN: 825001-UP

4шт.

3

45A-1MA-5110YK

BRACKET

SN: 825001-UP

2шт.

|$21

45A-1MA-5110WK

BRACKET,(COLD)

SN: 825001-UP

2шт.

4

01024-80820

BOLT

SN: 825001-UP

4шт.

5

45B-1MA-5180

CLAMP

SN: 825001-UP

2шт.

6

01024-80830

BOLT

SN: 825001-UP

4шт.

7

45B-1MA-5130

CLAMP

SN: 825001-UP

2шт.

8

304-868-2250

RUBBER

SN: 825001-UP

4шт.

9

01024-80845

BOLT

SN: 825001-UP

4шт.

10

45C-2MA-1200

PULLEY

SN: 825001-UP

2шт.

11

45A-1MH-5110YK

BRACKET,(L.H.)

SN: 825001-UP

1шт.

|$32

45A-1MH-5110WK

BRACKET,(L.H.)(COLD)

SN: 825001-UP

1шт.

12

45A-1MA-3110YK

BRACKET,(R.H.)

SN: 825001-UP

1шт.

|$34

45A-1MA-3110WK

BRACKET,(R.H.)(COLD)

SN: 825001-UP

1шт.

13

01580-11210

NUT

SN: 825001-UP

2шт.

14

01643-31232

WASHER

SN: 825001-UP

2шт.

15

01024-81030

BOLT

SN: 825001-UP

4шт.

16

37A-ZDP-1100YK

PIPE

SN: 825001-UP

4шт.

|$39

45B-5MA-1190WK

PIPE,(COLD)

SN: 825001-UP

4шт.

17

01010-81090

BOLT

SN: 825001-UP

4шт.

18

01580-11008

NUT

SN: 825001-UP

4шт.

19

07627-00326

HOSE,(3.0M)

SN: 825001-UP

4шт.

|$51

37A-UAX-4170

HOSE,(3.3M)

SN: 825001-UP

4шт.

|$52

07627-00328

HOSE,(3.5M)

SN: 825001-UP

4шт.

|$53

07627-00329

HOSE,(3.7M)

SN: 825001-UP

4шт.

20

37A-ZBN-6020YK

PIPE,(3.0M)

SN: 825001-UP

1шт.

|$55

37A-ZBN-6030YK

PIPE,(3.3-3.5M)

SN: 825001-UP

1шт.

|$56

37A-ZBN-6040YK

PIPE,(3.7M)

SN: 825001-UP

1шт.

|$57

37A-ZBN-6020WK

PIPE,(3.0M) (COLD)

SN: 825001-UP

1шт.

|$58

37A-ZBN-6030WK

PIPE,(3.3-3.5M) (COLD)

SN: 825001-UP

1шт.

|$59

37A-ZBN-6040WK

PIPE,(3.7M) (COLD)

SN: 825001-UP

1шт.

21

37A-ZBN-6120YK

PIPE,(3.0M)

SN: 825001-UP

1шт.

|$61

37A-ZBN-6130YK

PIPE,(3.3-3.5M)

SN: 825001-UP

1шт.

|$62

37A-ZBN-6140YK

PIPE,(3.7M)

SN: 825001-UP

1шт.

|$63

37A-ZBN-6120WK

PIPE,(3.0M) (COLD)

SN: 825001-UP

1шт.

|$64

37A-ZBN-6130WK

PIPE,(3.3-3.5M) (COLD)

SN: 825001-UP

1шт.

|$65

37A-ZBN-6140WK

PIPE,(3.7M) (COLD)

SN: 825001-UP

1шт.

22

37A-ZBR-6120YK

PIPE,(3.0M)

SN: 825001-UP

1шт.

|$67

37A-ZBR-6130YK

PIPE,(3.3-3.5M)

SN: 825001-UP

1шт.

|$68

37A-ZBR-6140YK

PIPE,(3.7M)

SN: 825001-UP

1шт.

|$69

37A-ZBR-6120WK

PIPE,(3.0M) (COLD)

SN: 825001-UP

1шт.

|$70

37A-ZBR-6130WK

PIPE,(3.3-3.5M) (COLD)

SN: 825001-UP

1шт.

|$71

37A-ZBR-6140WK

PIPE,(3.7M) (COLD)

SN: 825001-UP

1шт.

23

37A-ZBR-6020YK

PIPE,(3.0M)

SN: 825001-UP

1шт.

|$73

37A-ZBR-6030YK

PIPE,(3.3-3.5M)

SN: 825001-UP

1шт.

|$74

37A-ZBR-6040YK

PIPE,(3.7M)

SN: 825001-UP

1шт.

|$75

37A-ZBR-6020WK

PIPE,(3.0M) (COLD)

SN: 825001-UP

1шт.

|$76

37A-ZBR-6030WK

PIPE,(3.3-3.5M) (COLD)

SN: 825001-UP

1шт.

|$77

37A-ZBR-6040WK

PIPE,(3.7M) (COLD)

SN: 825001-UP

1шт.

24

45A-1PA-8120YK

BRACKET,(R.H.)

SN: 825001-UP

1шт.

|$79

45A-1PA-8120WK

BRACKET,(R.H.)(COLD)

SN: 825001-UP

1шт.

25

01024-80820

BOLT

SN: 825001-UP

2шт.

26

45A-1PA-8130YK

BRACKET,(L.H.)

SN: 825001-UP

1шт.

|$82

45A-1PA-8130WK

BRACKET,(L.H.)(COLD)

SN: 825001-UP

1шт.

27

01024-80820

BOLT

SN: 825001-UP

2шт.
