Запчасти Komatsu FB20MF-12 УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) (ДЛЯ ПРОПОРЦИОНАЛЬН. СОЛЕНОИДНЫЙ КЛАПАН) ГИДРАВЛИКА

|$8

3BA-61-71210

CONTROL VALVE ASS'Y,(FOR 2CV)

SN: 825001-UP

1шт.

|$9

3BA-61-71310

CONTROL VALVE ASS'Y,(FOR 3CV)

SN: 825001-UP

1шт.

|$10

3BA-61-71410

CONTROL VALVE ASS'Y,(FOR 4CV)

SN: 825001-UP

1шт.

|$12

3BA-61-71610

CONTROL VALVE ASS'Y,FOR 3CV WITH PORT RELEF VALVE

SN: 825001-UP

1шт.

|$13

3BA-61-71710

CONTROL VALVE ASS'Y,F0R 4CV WITH PORT RELEF VALVE

SN: 825001-UP

1шт.

1

KHOBP14

PLUG,(FOR 3CV)

SN: 825001-UP

2шт.

|$16

KHOBP14

PLUG,(FOR 4CV)

SN: 825001-UP

4шт.

|$18

KHV981263781

RELIEF VALVE ASS'Y,FOR 3CV WITH PORT RELEF VALVE

SN: 825001-UP

2шт.

|$19

KHV981263781

RELIEF VALVE ASS'Y,F0R 4CV WITH PORT RELEF VALVE

SN: 825001-UP

4шт.

2

KHOBP14

PLUG

SN: 825001-UP

2шт.

3

KHPBP116U-2403

PLUG

SN: 825001-UP

6шт.

4

KHOROH14

PLUG

SN: 825001-UP

1шт.

5

KHOORBBP11

O-RING

SN: 825001-UP

1шт.

6

KHV233140-1044

COVER,(FOR 2CV)

SN: 825001-UP

4шт.

|$26

KHV233140-1044

COVER,(FOR 3CV)

SN: 825001-UP

6шт.

|$27

KHV233140-1044

COVER,(FOR 4CV)

SN: 825001-UP

8шт.

7

KHV233140-0357

COVER,(FOR 2CV)

SN: 825001-UP

4шт.

|$30

KHV233140-0357

COVER,(FOR 3CV)

SN: 825001-UP

6шт.

|$31

KHV233140-0357

COVER,(FOR 4CV)

SN: 825001-UP

8шт.

8

KHOSSSM66

SCREW,(FOR 2CV)

SN: 825001-UP

4шт.

|$34

KHOSSSM66

SCREW,(FOR 3CV)

SN: 825001-UP

6шт.

|$35

KHOSSSM66

SCREW,(FOR 4CV)

SN: 825001-UP

8шт.

9

KHODW532

BALL,(FOR 2CV)

SN: 825001-UP

4шт.

|$38

KHODW532

BALL,(FOR 3CV)

SN: 825001-UP

6шт.

|$39

KHODW532

BALL,(FOR 4CV)

SN: 825001-UP

8шт.

10

KH250102761S28

O-RING,(FOR 2CV)

SN: 825001-UP

4шт.

|$42

KH250102761S28

O-RING,(FOR 3CV)

SN: 825001-UP

6шт.

|$43

KH250102761S28

O-RING,(FOR 4CV)

SN: 825001-UP

8шт.

11

KHOSBM516

BOLT,(FOR 2CV)

SN: 825001-UP

8шт.

|$46

KHOSBM516

BOLT,(FOR 3CV)

SN: 825001-UP

12шт.

|$47

KHOSBM516

BOLT,(FOR 4CV)

SN: 825001-UP

16шт.

12

KHOSBM58

BOLT,(FOR 2CV)

SN: 825001-UP

8шт.

|$50

KHOSBM58

BOLT,(FOR 3CV)

SN: 825001-UP

12шт.

|$51

KHOSBM58

BOLT,(FOR 4CV)

SN: 825001-UP

16шт.

13

KHVZ50107146

PLUG,(FOR 2CV)

SN: 825001-UP

2шт.

|$54

KHVZ50107146

PLUG,(FOR 3CV)

SN: 825001-UP

3шт.

|$55

KHVZ50107146

PLUG,(FOR 4CV)

SN: 825001-UP

4шт.

14

KHVZ5014401

SPRING,(FOR 2CV)

SN: 825001-UP

2шт.

|$58

KHVZ5014401

SPRING,(FOR 3CV)

SN: 825001-UP

3шт.

|$59

KHVZ5014401

SPRING,(FOR 4CV)

SN: 825001-UP

4шт.

15

KH203340-1258

SPRING

SN: 825001-UP

1шт.

16

KH203340-1257

SPRING

SN: 825001-UP

1шт.

17

KHVZ50107145

PLUG,(FOR 2CV)

SN: 825001-UP

2шт.

|$64

KHVZ50107145

PLUG,(FOR 3CV)

SN: 825001-UP

3шт.

|$65

KHVZ50107145

PLUG,(FOR 4CV)

SN: 825001-UP

5шт.

18

KH03560-0549

PLUG

SN: 825001-UP

1шт.

19

KHOORBP16

O-RING,(FOR 2CV)

SN: 825001-UP

2шт.

|$69

KHOORBP16

O-RING,(FOR 3CV)

SN: 825001-UP

3шт.

|$70

KHOORBP16

O-RING,(FOR 4CV)

SN: 825001-UP

4шт.

20

KHOORBP14

O-RING

SN: 825001-UP

1шт.

21

KHV9903294588

RELEF VALVE ASS'Y

SN: 825001-UP

1шт.

22

KHVZ03340-0054

SPRING

SN: 825001-UP

1шт.

23

KHVZ03340-1858

SPRING

SN: 825001-UP

1шт.

24

KHVZ33420-0300

ROD

SN: 825001-UP

1шт.

25

KHOROH38

PLUG

SN: 825001-UP

6шт.

26

KHOORBP14

O-RING

SN: 825001-UP

6шт.

27

KHVZ03560-0545

PLUG

SN: 825001-UP

1шт.

28

KHOORBP16

O-RING

SN: 825001-UP

1шт.

29

KHVZ33140-1291

COVER

SN: 825001-UP

1шт.

30

KHVZ33140-1294

COVER

SN: 825001-UP

1шт.

31

KHOSBM616

BOLT

SN: 825001-UP

12шт.

32

KHVOORBP5

O-RING

SN: 825001-UP

1шт.

33

KHOORBP16

O-RING

SN: 825001-UP

1шт.

34

KHVZ03340-2965

SPRING

SN: 825001-UP

1шт.
