Запчасти Komatsu FD30-14 ГИДРОЦИЛИНДР ПОДЪЕМА (ЗАДН.¤ ПРАВ.) (VF .8T-.T) МАЧТА И СТРЕЛА

|$20

37B-MBW-2300

CYLINDER ASS'Y,(FOR 3.0M MAST)

SN: 550001-UP

1шт.

|$21

37B-MBW-2330

CYLINDER ASS'Y,(FOR 3.3M MAST)

SN: 550001-UP

1шт.

|$22

37B-MBW-2350

CYLINDER ASS'Y,(FOR 3.5M MAST)

SN: 550001-UP

1шт.

|$23

37B-MBW-2400

CYLINDER ASS'Y,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$24

37B-MBW-2450

CYLINDER ASS'Y,(FOR 4.5M MAST)

SN: 550001-UP

1шт.

1

37B-MBV-2300

CYLINDER,(FOR 3.0M MAST)

SN: 550001-UP

1шт.

|$26

37B-MBV-2330

CYLINDER,(FOR 3.3M MAST)

SN: 550001-UP

1шт.

|$27

37B-MBV-2350

CYLINDER,(FOR 3.5M MAST)

SN: 550001-UP

1шт.

|$28

37B-MBV-2400

CYLINDER,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$29

37B-MBV-2450

CYLINDER,(FOR 4.5M MAST)

SN: 550001-UP

1шт.

2

37B-MBY-2300

ROD,(FOR 3.0M MAST)

SN: 550001-UP

1шт.

|$31

37B-MBY-2330

ROD,(FOR 3.3M MAST)

SN: 550001-UP

1шт.

|$32

37B-MBY-2350

ROD,(FOR 3.5M MAST)

SN: 550001-UP

1шт.

|$33

37B-MBY-2400

ROD,(FOR 4.0M MAST)

SN: 550001-UP

1шт.

|$34

37B-MBY-2450

ROD,(FOR 4.5M MAST)

SN: 550001-UP

1шт.

3

3EB-M2-21570

SPACER,(FOR 4.0M OR 4.5M MAST)

SN: 550001-UP

1шт.

4

3EB-M2-21680

O-RING,(FOR 4.0M OR 4.5M MAST)

SN: 550001-UP

1шт.

5

3EA-63-16110

HEAD

SN: 550001-UP

1шт.

6

307-61-15240

BUSHING

SN: 550001-UP

1шт.

7

3EB-M2-21550

HOLDER

SN: 550001-UP

1шт.

8

34B-64-12151

U-RING

SN: 550001-UP

1шт.

9

3EB-M2-21560

RING

SN: 550001-UP

1шт.

10

34B-63-26150

RING

SN: 550001-UP

1шт.

11

3EB-63-16160

O-RING

SN: 550001-UP

1шт.

12

3EB-M2-21650

PISTON

SN: 550001-UP

1шт.

13

3EB-M2-21660

RING,PISTON

SN: 550001-UP

1шт.

14

3EB-M2-21670

SCREW

SN: 550001-UP

1шт.

15

3EB-M2-21750

SPOOL

SN: 550001-UP

1шт.

16

3EB-M2-21760

SPRING

SN: 550001-UP

1шт.

17

3EB-M2-21770

RING,SNAP

SN: 550001-UP

1шт.

18

3EB-M2-21780

VALVE

SN: 550001-UP

1шт.

19

540-61-13190

BALL

SN: 550001-UP

1шт.

20

4610-64-1160

SCREW

SN: 550001-UP

1шт.
