Запчасти Komatsu FB10 МАЧТА (FV МАЧТА¤MM FL И ГИДРОЦИЛИНДР ПОДЪЕМА) (ДЛЯ .M - .7M МАЧТА) (С ХОЛОДН.) (/) МАЧТА

1

37R-7JB-9300

MAST,OUTER (FOR 3.0M MAST) (1.0T)

SN: 140001-UP

1шт.

|$57

37R-7JB-9330

MAST,OUTER (FOR 3.3M MAST) (1.0T)

SN: 140001-UP

1шт.

|$58

37R-7JB-9350

MAST,OUTER (FOR 3.5M MAST) (1.0T)

SN: 140001-UP

1шт.

|$59

37R-7JB-9370

MAST,OUTER (FOR 3.7M MAST) (1.0T)

SN: 140001-UP

1шт.

|$60

37R-7DB-9300

MAST,OUTER (FOR 3.0M MAST) (1.5T)

SN: 140001-UP

1шт.

|$61

37R-7DB-9330

MAST,OUTER (FOR 3.3M MAST) (1.5T)

SN: 140001-UP

1шт.

|$62

37R-7DB-9350

MAST,OUTER (FOR 3.5M MAST) (1.5T)

SN: 140001-UP

1шт.

|$63

37R-7DB-9370

MAST,OUTER (FOR 3.7M MAST) (1.5T)

SN: 140001-UP

1шт.

2

04025-00308

PIN,SPRING

SN: 140001-UP

2шт.

3

37R-7DD-9300

MAST,INNER (FOR 3.0M MAST)

SN: 140001-UP

1шт.

|$66

37R-7DD-9330

MAST,INNER (FOR 3.3M MAST)

SN: 140001-UP

1шт.

|$67

37R-7DD-9350

MAST,INNER (FOR 3.5M MAST)

SN: 140001-UP

1шт.

|$68

37R-7DD-9370

MAST,INNER (FOR 3.7M MAST)

SN: 140001-UP

1шт.

|$69

37A-9CC-2550

CHAIN ASS'Y,(FOR 3.0M MAST)

SN: 140001-UP

2шт.

|$70

37A-9CC-2600

CHAIN ASS'Y,(FOR 3.3M MAST)

SN: 140001-UP

2шт.

|$71

37A-9CC-2630

CHAIN ASS'Y,(FOR 3.5M MAST)

SN: 140001-UP

2шт.

|$72

37A-9CC-2660

CHAIN ASS'Y,(FOR 3.7M MAST)

SN: 140001-UP

2шт.

4

37A-737-1291

CHAIN,(FOR 3.0M MAST)

SN: 140001-UP

1шт.

|$74

37A-737-1321

CHAIN,(FOR 3.3M MAST)

SN: 140001-UP

1шт.

|$75

37A-737-1341

CHAIN,(FOR 3.5M MAST)

SN: 140001-UP

1шт.

|$76

37A-737-1361

CHAIN,(FOR 3.7M MAST)

SN: 140001-UP

1шт.

5

34A-72-11820

BOLT

SN: 140001-UP

1шт.

6

3EA-73-11911

BOLT

SN: 140001-UP

1шт.

7

37A-7LT-5300UE

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST)

SN: 140001-UP

2шт.

|$80

37A-7LT-5330UE

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST)

SN: 140001-UP

2шт.

|$81

37A-7LT-5350UE

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST)

SN: 140001-UP

2шт.

|$82

37A-7LT-5370UE

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST)

SN: 140001-UP

2шт.

|$83

37A-7LT-5300UT

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST) (COLD)

SN: 140001-UP

2шт.

|$84

37A-7LT-5330UT

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST) (COLD)

SN: 140001-UP

2шт.

|$85

37A-7LT-5350UT

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST) (COLD)

SN: 140001-UP

2шт.

|$86

37A-7LT-5370UT

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST) (COLD)

SN: 140001-UP

2шт.

8

01016-52070

BOLT,(FOR 1.0 TON)

SN: 140001-UP

2шт.

|$88

01016-52090

BOLT,(FOR 1.5 TON)

SN: 140001-UP

2шт.

9

01580-12016

NUT

SN: 140001-UP

2шт.

10

3LA-L1-32210UE

BEAM

SN: 140001-UP

1шт.

|$93

3LA-L1-32210UT

BEAM

SN: 140001-UP

1шт.

11

3LA-L1-32460

RUBBER

SN: 140001-UP

1шт.

12

3LA-71-13361

PIN

SN: 140001-UP

1шт.

13

3LA-71-13270

PIN

SN: 140001-UP

1шт.

14

34A-71-15550

COLLAR

SN: 140001-UP

3шт.

15

34A-72-11150

WHEEL

SN: 140001-UP

2шт.

16

3LA-71-13280

SPACER

SN: 140001-UP

1шт.

17

3LA-71-18230

PULLEY

SN: 140001-UP

1шт.

18

01024-81016

BOLT

SN: 140001-UP

2шт.

19

3LA-71-13290

SPACER

SN: 140001-UP

1шт.

20

3LA-71-12250

BUSHING

SN: 140001-UP

2шт.

21

01016-51030

BOLT

SN: 140001-UP

2шт.

22

01580-11008

NUT

SN: 140001-UP

2шт.

23

3EA-71-00020

SHIM ASS'Y

SN: 140001-UP

1шт.

|$108

0

SHIM, 2.0MM

SN: 140001-UP

-2шт.

|$109

0

SHIM, 1.0MM

SN: 140001-UP

-2шт.

|$110

0

SHIM, 0.5MM

SN: 140001-UP

-2шт.

24

3EA-71-51410

CLAMP

SN: 140001-UP

2шт.

25

3EB-71-61420

CLAMP

SN: 140001-UP

2шт.

26

3EB-71-31510

PLATE

SN: 140001-UP

4шт.

27

3EB-71-61460

PIPE

SN: 140001-UP

4шт.

28

01024-81045

BOLT

SN: 140001-UP

4шт.

29

3EB-71-00100

SHIM ASS'Y

SN: 140001-UP

1шт.

|$117

0

SHIM, 3.2MM

SN: 140001-UP

-2шт.

|$118

0

SHIM, 1.0MM

SN: 140001-UP

-2шт.
