Запчасти Komatsu FB10 УПРАВЛЯЮЩ. КЛАПАН (ВНУТР. ЧАСТИ) (/) (LIFT СЕКЦ. БЛОК) ГИДРАВЛИКА

|$5

3BA-61-68111

CONTROL VALVE ASS'Y,2-SPOOL

SN: 807001-UP

1шт.

|$6

3BA-61-68210

CONTROL VALVE ASS'Y,3-SPOOL

SN: 807001-UP

1шт.

|$7

3BA-61-69210

CONTROL VALVE ASS'Y,3-SPOOL,WITH PORT RELIEF VALVE

SN: 807001-UP

1шт.

|$8

3BA-61-68310

CONTROL VALVE ASS'Y,4-SPOOL

SN: 807001-UP

1шт.

|$9

3BA-61-69410

CONTROL VALVE ASS'Y,4-SPOOL,WITH PORT RELIEF VALVE

SN: 807001-UP

1шт.

|$$6

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.R4140-61A0 TO R4140-64A1.

-1шт.

|$11

KBC0213-31004

SPOOL SECTION ASS'Y

SN: 807001-UP

1шт.

1

0

HOUSING

SN: 807001-UP

1шт.

2

0

SPOOL

SN: 807001-UP

1шт.

3

KB21011-31702

PLATE

SN: 807001-UP

2шт.

4

KB21001-00689

O-RING

SN: 807001-UP

2шт.

5

KB21011-32801

WIPER

SN: 807001-UP

2шт.

6

KB21011-31024

CAP

SN: 807001-UP

1шт.

7

KB21011-30702

SEAT

SN: 807001-UP

2шт.

8

KB21011-30507

SCREW,CAP

SN: 807001-UP

1шт.

9

KB21011-30630

SPRING

SN: 807001-UP

1шт.

10

KB91111-60102

SCREW

SN: 807001-UP

2шт.

11

KB92703-06181

BOLT

SN: 807001-UP

2шт.

12

KBT1411-17003

POPPET

SN: 807001-UP

1шт.

13

KBT1461-10014

SPRING

SN: 807001-UP

1шт.

14

KB21001-90435

PLUG

SN: 807001-UP

1шт.

15

KB95113-01800

O-RING

SN: 807001-UP

1шт.

16

KBC0853-00003

VALVE,SOLENOID

SN: 807001-UP

1шт.

17

KB21001-00035

O-RING

SN: 807001-UP

1шт.

18

KBC0851-00003

FILTER

SN: 807001-UP

1шт.

19

KB95131-00700

O-RING

SN: 807001-UP

1шт.

20

KB21001-00093

RING,BACK UP

SN: 807001-UP

1шт.

21

KB97161-03121

PLUG

SN: 807001-UP

2шт.

22

KB95113-01400

O-RING

SN: 807001-UP

2шт.

23

KB21111-33114

POPPET

SN: 807001-UP

1шт.

24

KB21111-30515

SPRING

SN: 807001-UP

1шт.

25

KBT1152-21302

PLUG

SN: 807001-UP

1шт.

26

KB21001-00036

O-RING

SN: 807001-UP

1шт.

27

0

PLATE, NAME

SN: 807001-UP

1шт.

28

KB91911-01489

SCREW

SN: 807001-UP

2шт.

29

KBC0003-30301

VALVE ASS'Y,SHUT OFF

SN: 807001-UP

1шт.

30

KB21001-00036

O-RING

SN: 807001-UP

1шт.

31

KB95111-01090

O-RING

SN: 807001-UP

1шт.

32

KB21013-30678

RELIEF VALVE ASS'Y

SN: 807001-UP

1шт.

33

KB21001-00035

O-RING

SN: 807001-UP

1шт.
