Запчасти Komatsu FB10 МАЧТА (ПОЛН. FREE МАЧТА И ГИДРОЦИЛИНДР ПОДЪЕМА) (ДЛЯ .M - .M МАЧТА) (С ХОЛОДН.) (EXCEPT FB/8RJW)(/) МАЧТА

1

37R-MBB-8301

MAST,OUTER (FOR 3.0M MAST) (1.0T)

SN: 83205-UP

1шт.

|$41

37R-MBB-8300

MAST,OUTER (FOR 3.0M MAST) (1.0T)

SN: 80001-83204

1шт.

|$42

37R-MBB-8331

MAST,OUTER (FOR 3.3M MAST) (1.0T)

SN: 83205-UP

1шт.

|$43

37R-MBB-8330

MAST,OUTER (FOR 3.3M MAST) (1.0T)

SN: 80001-83204

1шт.

|$44

37R-MBB-8351

MAST,OUTER (FOR 3.5M MAST) (1.0T)

SN: 83205-UP

1шт.

|$45

37R-MBB-8350

MAST,OUTER (FOR 3.5M MAST) (1.0T)

SN: 80001-83204

1шт.

|$46

37R-MBB-8371

MAST,OUTER (FOR 3.7M MAST) (1.0T)

SN: 83205-UP

1шт.

|$47

37R-MBB-8370

MAST,OUTER (FOR 3.7M MAST) (1.0T)

SN: 80001-83204

1шт.

|$48

37R-MBB-8401

MAST,OUTER (FOR 4.0M MAST) (1.0T)

SN: 83205-UP

1шт.

|$49

37R-MBB-8400

MAST,OUTER (FOR 4.0M MAST) (1.0T)

SN: 80001-83204

1шт.

|$50

37R-MAB-8301

MAST,OUTER (FOR 3.0M MAST) (1.5T)

SN: 83205-UP

1шт.

|$51

37R-MAB-8300

MAST,OUTER (FOR 3.0M MAST) (1.5T)

SN: 80001-83204

1шт.

|$52

37R-MAB-8331

MAST,OUTER (FOR 3.3M MAST) (1.5T)

SN: 83205-UP

1шт.

|$53

37R-MAB-8330

MAST,OUTER (FOR 3.3M MAST) (1.5T)

SN: 80001-83204

1шт.

|$54

37R-MAB-8351

MAST,OUTER (FOR 3.5M MAST) (1.5T)

SN: 83205-UP

1шт.

|$55

37R-MAB-8350

MAST,OUTER (FOR 3.5M MAST) (1.5T)

SN: 80001-83204

1шт.

|$56

37R-MAB-8371

MAST,OUTER (FOR 3.7M MAST) (1.5T)

SN: 83205-UP

1шт.

|$57

37R-MAB-8370

MAST,OUTER (FOR 3.7M MAST) (1.5T)

SN: 80001-83204

1шт.

|$58

37R-MAB-8401

MAST,OUTER (FOR 4.0M MAST) (1.5T)

SN: 83205-UP

1шт.

|$59

37R-MAB-8400

MAST,OUTER (FOR 4.0M MAST) (1.5T)

SN: 80001-83204

1шт.

2

37R-MAD-8300

MAST,INNER (FOR 3.0M MAST)

SN: 80001-UP

1шт.

|$61

37R-MAD-8330

MAST,INNER (FOR 3.3M MAST)

SN: 80001-UP

1шт.

|$62

37R-MAD-8350

MAST,INNER (FOR 3.5M MAST)

SN: 80001-UP

1шт.

|$63

37R-MAD-8370

MAST,INNER (FOR 3.7M MAST)

SN: 80001-UP

1шт.

|$64

37R-MAD-8400

MAST,INNER (FOR 4.0M MAST)

SN: 80001-UP

1шт.

|$65

37R-9CA-8300

CHAIN ASS'Y,(FOR 3.0M MAST)

SN: 80001-UP

2шт.

|$66

37R-9CA-8340

CHAIN ASS'Y,(FOR 3.3M MAST)

SN: 80001-UP

2шт.

|$67

37R-9CA-8380

CHAIN ASS'Y,(FOR 3.5M MAST)

SN: 80001-UP

2шт.

|$68

37R-9CA-8410

CHAIN ASS'Y,(FOR 3.7M MAST)

SN: 80001-UP

2шт.

|$69

37R-9CA-8450

CHAIN ASS'Y,(FOR 4.0M MAST)

SN: 80001-UP

2шт.

3

37A-737-1310

CHAIN,(FOR 3.0M MAST)

SN: 80001-UP

1шт.

|$71

37A-737-1340

CHAIN,(FOR 3.3M MAST)

SN: 80001-UP

1шт.

|$72

37A-787-1160

CHAIN,(FOR 3.5M MAST)

SN: 80001-UP

1шт.

|$73

37A-737-1770

CHAIN,(FOR 3.7M MAST)

SN: 80001-UP

1шт.

|$74

37A-737-1400

CHAIN,(FOR 4.0M MAST)

SN: 80001-UP

1шт.

4

34A-71-11610

BOLT

SN: 80001-UP

1шт.

5

3EA-73-11911

BOLT

SN: 80001-UP

1шт.

6

37A-MDT-1301YD

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST)

SN: 80001-UP

1шт.

|$78

37A-MDT-1331YD

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST)

SN: 80001-UP

1шт.

|$79

37A-MDT-1351YD

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST)

SN: 80001-UP

1шт.

|$80

37A-MDT-1371YD

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST)

SN: 80001-UP

1шт.

|$81

37A-MDT-1011YD

LIFT CYLINDER ASS'Y,(FOR 4.0M MAST)

SN: 80001-UP

1шт.

|$82

37A-MDT-1301WD

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST) (COLD)

SN: 80001-UP

1шт.

|$83

37A-MDT-1331WD

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST) (COLD)

SN: 80001-UP

1шт.

|$84

37A-MDT-1351WD

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST) (COLD)

SN: 80001-UP

1шт.

|$85

37A-MDT-1371WD

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST) (COLD)

SN: 80001-UP

1шт.

|$86

37A-MDT-1011WD

LIFT CYLINDER ASS'Y,(FOR 4.0M MAST) (COLD)

SN: 80001-UP

1шт.

7

37A-MDW-1301YD

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST)

SN: 80001-UP

1шт.

|$88

37A-MDW-1331YD

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST)

SN: 80001-UP

1шт.

|$89

37A-MDW-1351YD

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST)

SN: 80001-UP

1шт.

|$90

37A-MDW-1371YD

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST)

SN: 80001-UP

1шт.

|$91

37A-MDW-1011YD

LIFT CYLINDER ASS'Y,(FOR 4.0M MAST)

SN: 80001-UP

1шт.

|$92

37A-MDW-1301WD

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST) (COLD)

SN: 80001-UP

1шт.

|$93

37A-MDW-1331WD

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST) (COLD)

SN: 80001-UP

1шт.

|$94

37A-MDW-1351WD

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST) (COLD)

SN: 80001-UP

1шт.

|$95

37A-MDW-1371WD

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST) (COLD)

SN: 80001-UP

1шт.

|$96

37A-MDW-1011WD

LIFT CYLINDER ASS'Y,(FOR 4.0M MAST) (COLD)

SN: 80001-UP

1шт.

8

37R-TDT-8300YD

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST)

SN: 80001-UP

1шт.

|$98

37R-TDT-8330YD

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST)

SN: 80001-UP

1шт.

|$99

37R-TDT-8350YD

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST)

SN: 80001-UP

1шт.

|$100

37R-TDT-8370YD

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST)

SN: 80001-UP

1шт.

|$101

37R-TDT-8390YD

LIFT CYLINDER ASS'Y,(FOR 4.0M MAST)

SN: 80001-UP

1шт.

|$102

37R-TDT-8300WD

LIFT CYLINDER ASS'Y,(FOR 3.0M MAST) (COLD)

SN: 80001-UP

1шт.

|$103

37R-TDT-8330WD

LIFT CYLINDER ASS'Y,(FOR 3.3M MAST) (COLD)

SN: 80001-UP

1шт.

|$104

37R-TDT-8350WD

LIFT CYLINDER ASS'Y,(FOR 3.5M MAST) (COLD)

SN: 80001-UP

1шт.

|$105

37R-TDT-8370WD

LIFT CYLINDER ASS'Y,(FOR 3.7M MAST) (COLD)

SN: 80001-UP

1шт.

|$106

37R-TDT-8390WD

LIFT CYLINDER ASS'Y,(FOR 4.0M MAST) (COLD)

SN: 80001-UP

1шт.

9

01016-52070

BOLT,(1.0 TON)

SN: 80001-UP

2шт.

|$108

01016-52090

BOLT,(1.5 TON)

SN: 80001-UP

2шт.

10

01580-12016

NUT

SN: 80001-UP

2шт.
