Запчасти Komatsu FB09HF-14F-12 FV МАЧТА ГИДРОЦИЛИНДР ПОДЪЕМА ВНУТР. ЧАСТИ (.-.7M) МАЧТА

|$28

37A-7LT-5300YK

LIFT CYLINDER ASS'Y,(3.0M)

SN: 830001-UP

2шт.

|$29

37A-7LT-5330YK

LIFT CYLINDER ASS'Y,(3.3M)

SN: 830001-UP

2шт.

|$30

37A-7LT-5350YK

LIFT CYLINDER ASS'Y,(3.5M)

SN: 830001-UP

2шт.

|$31

37A-7LT-5370YK

LIFT CYLINDER ASS'Y,(3.7M)

SN: 830001-UP

2шт.

|$32

37A-7LT-5300WK

LIFT CYLINDER ASS'Y,(3.0M) (COLD)

SN: 830001-UP

2шт.

|$33

37A-7LT-5330WK

LIFT CYLINDER ASS'Y,(3.3M) (COLD)

SN: 830001-UP

2шт.

|$34

37A-7LT-5350WK

LIFT CYLINDER ASS'Y,(3.5M) (COLD)

SN: 830001-UP

2шт.

|$35

37A-7LT-5370WK

LIFT CYLINDER ASS'Y,(3.7M) (COLD)

SN: 830001-UP

2шт.

1

30A-63-11270

CYLINDER,(3.0M)

SN: 830001-UP

1шт.

|$37

30A-63-11280

CYLINDER,(3.3M)

SN: 830001-UP

1шт.

|$38

30A-63-11290

CYLINDER,(3.5M)

SN: 830001-UP

1шт.

|$39

30A-63-11310

CYLINDER,(3.7M)

SN: 830001-UP

1шт.

2

30A-63-11560

ROD,(3.0M)

SN: 830001-UP

1шт.

|$41

30A-63-11520

ROD,(3.3M)

SN: 830001-UP

1шт.

|$42

30A-63-11570

ROD,(3.5M)

SN: 830001-UP

1шт.

|$43

30A-63-11580

ROD,(3.7M)

SN: 830001-UP

1шт.

3

30A-63-11190

HEAD,CYLINDER

SN: 830001-UP

1шт.

4

369-61-12151

BUSHING

SN: 830001-UP

1шт.

5

30A-63-11210

X-RING (KIT)

SN: 830001-UP

1шт.

6

3EP-63-14120

SEAL,WIPER (KIT)

SN: 830001-UP

1шт.

7

30A-63-11150

O-RING (KIT)

SN: 830001-UP

1шт.

8

30A-63-11660

U-RING (KIT)

SN: 830001-UP

1шт.

9

30A-63-11130

RING,BACK-UP (KIT)

SN: 830001-UP

1шт.

10

3EA-63-11590

BUSHING

SN: 830001-UP

1шт.

11

30A-63-11410

BEARING

SN: 830001-UP

1шт.

12

30A-63-11110

RING,SNAP

SN: 830001-UP

1шт.

13

30A-63-11250

VALVE,CHECK

SN: 830001-UP

1шт.

14

30A-63-11260

PLUG

SN: 830001-UP

1шт.

15

30A-63-11220

GASKET

SN: 830001-UP

1шт.

|$$30

SERVICE KIT

-1шт.

K18

30A-63-05020

REPAIR KIT,LIFT CYLINDER

SN: 830001-UP

2шт.
