Запчасти Komatsu RC40D-1 ROLL КРЕПЛЕНИЕ (ТРУБЫ) ROLL КРЕПЛЕНИЕ (ДЛЯ FREE VIEW МАЧТА) (CASCADE)

1

45B-1BS-6210

PIPE

SN: 1001-UP

1шт.

2

45B-1BS-6220

PIPE

SN: 1001-UP

1шт.

3

45B-1BS-6230

PIPE

SN: 1001-UP

1шт.

4

45B-1BS-6240

PIPE

SN: 1001-UP

1шт.

5

45A-271-1370

CLAMP

SN: 1001-UP

4шт.

6

37A-402-1890

PLATE

SN: 1001-UP

2шт.

7

01010-50835

BOLT

SN: 1001-UP

4шт.

8

01602-20825

WASHER,SPRING

SN: 1001-UP

4шт.

9

45B-1BS-5560

PIPE

SN: 1001-UP

2шт.

10

300-957-1280

ELBOW

SN: 1001-UP

1шт.

11

300-868-2680

NIPPLE

SN: 1001-UP

4шт.

12

300-868-2690

COUPLER

SN: 1001-UP

4шт.

13

3EA-66-26220

ELBOW

SN: 1001-UP

3шт.

14

45B-1BS-3910

ADAPTER

SN: 1001-UP

3шт.

15

3EA-66-14160

HOSE

SN: 1001-UP

2шт.

16

3EA-66-14170

HOSE,(FOR 2.0TON TO 2.5TON)

SN: 1001-UP

1шт.

|$16

07123-00307

HOSE,(FOR 2.8TON AND 3.0TON)

SN: 1001-UP

1шт.

17

3BA-66-22230

HOSE,(FOR 2.0TON TO 2.5TON)

SN: 1001-UP

1шт.

|$18

0123-00308

HOSE,(FOR 2.8TON AND 3.0TON)

SN: 1001-UP

1шт.

18

37B-1AE-6010

BAND

SN: 1001-UP

4шт.

19

45B-1RF-6041

PLATE, NAME

SN: 1001-UP

1шт.

20

45B-1CM-2691

PLATE, NAME

SN: 1001-UP

1шт.

21

45A-5RS-1010

PLATE, CAUTION,(JAPANESE)

SN: 1001-UP

1шт.

|$23

300-827-1990

PLATE, CAUTION,(ENGLISH)

SN: 1001-UP

1шт.

|$24

46A-255-1970

PLATE, CAUTION,(CHINESE)

SN: 1001-UP

1шт.

|$25

46A-255-1980

PLATE, CAUTION,(SPANISH)

SN: 1001-UP

1шт.

|$26

46C-255-1910

PLATE, CAUTION,(FRENCH)

SN: 1001-UP

1шт.

|$27

46B-1RS-6010

PLATE, CAUTION,(RUSSIAN)

SN: 1001-UP

1шт.
