Запчасти Komatsu 25C-RC-03A-1 ROLL КРЕПЛЕНИЕ (RATATOR ПРИВОД МОТОР) ROLL КРЕПЛЕНИЕ (ДЛЯ FREE VIEW МАЧТА) (CASCADE)

|$4

45A-1BS-6110

CLAMP ASS'Y,(MOVAL ARM TYPE)

SN: 1001-UP

1шт.

|$5

45A-1BS-6210

CLAMP ASS'Y,(FIXED ARM TYPE)

SN: 1001-UP

1шт.

|$$3

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.T4020-22A0 TO T4020-32A1.

-1шт.

|$7

CC646211

DRIVE ASS'Y

SN: 1001-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.T4020-23A0 AND T4020-24A0.

-1шт.

|$9

CC646212

MOTOR,(MOTOR NO.2M012)

SN: 1001-UP

1шт.

|$10

CC15016

MOTOR,(MOTOR NO.2M019)

SN: 1001-UP

1шт.

|$11

CC655968

MOTOR,(MOTOR NO.2M023)

SN: 1001-UP

1шт.

|$12

CC14322

MOTOR,(MOTOR NO.2M028)

SN: 1001-UP

1шт.

1

CC660020

ADAPTER

SN: 1001-UP

1шт.

2

0

O-RING (KIT)

SN: 1001-UP

2шт.

3

0

SEAL (KIT)

SN: 1001-UP

1шт.

4

0

SEAL (KIT)

SN: 1001-UP

1шт.

5

CC659999

COVER

SN: 1001-UP

1шт.

|$$15

SERVICE KIT

-1шт.

KIT

CC660024

SEAL KIT,DRIVE MOTOR

SN: 1001-UP

1шт.
