Запчасти Komatsu TB45-197-A ПОРШЕНЬ¤ КОЛЕНВАЛ И МАХОВИК ДВИГАТЕЛЬ

1

A2010-VB08B

PISTON,0.50MM (OS)

SN: 099706-UP

6шт.

|$1

A2010-VB00A

PISTON,GRADE 1 (STD)

SN: 099706-UP

6шт.

|$2

A2010-VB01A

PISTON,GRADE 2 (STD)

SN: 099706-UP

6шт.

|$3

A2010-VB02A

PISTON,GRADE 3 (STD)

SN: 099706-UP

6шт.

|$4

A2010-VB03A

PISTON,GRADE 4 (STD)

SN: 099706-UP

6шт.

|$5

A2010-VB04A

PISTON,GRADE 5 (STD)

SN: 099706-UP

6шт.

2

12032-03J00

RING,SNAP

SN: 099706-UP

12шт.

3

12033-VC200

RING SET,PISTON (STD)

SN: 099706-UP

1шт.

|$8

12036-VC200

RING SET, 0.50MM,PISTON (OS)

SN: 099706-UP

1шт.

|$9

12038-VC200

RING SET, 1.00MM,PISTON (OS)

SN: 099706-UP

1шт.

4

12100-VB000

ROD COMPL,CONNECTING

SN: 099706-UP

6шт.

5

12030-03J01

BUSHING,PISTON PIN

SN: 099706-UP

6шт.

6

12109-VB000

BOLT,CONNECTING ROD

SN: 099706-UP

12шт.

7

12112-03J00

NUT,CONNECTING ROD

SN: 099706-UP

12шт.

8

12111-03J00

BEARING,CONNECTING ROD (STD)

SN: 099706-UP

12шт.

|$15

12117-03J00

BEARING, 0.25MM,CONNECTING ROD (US)

SN: 099706-UP

12шт.

|$16

12118-03J00

BEARING, 0.50MM,CONNECTING ROD (US)

SN: 099706-UP

12шт.

|$17

12119-03J00

BEARING, 0.75MM,CONNECTING ROD (US)

SN: 099706-UP

12шт.

|$18

12120-03J00

BEARING, 1.00MM,CONNECTING ROD (US)

SN: 099706-UP

12шт.

9

12200-VB000

CRANKSHAFT ASS'Y

SN: 099706-UP

1шт.

10

11024-0320A

PLUG,CRANKSHAFT OIL HOLE

SN: 099706-UP

6шт.

11

13021-WK200

SPROCKET,CRANKSHAFT

SN: 099706-UP

1шт.

12

15041-VB001

SPACER,OIL PUMP DRIVE

SN: 099706-UP

1шт.

13

12303-GU60A

PULLEY,CRANKSHAFT

SN: 099706-UP

1шт.

14

12307-GY000

WEDGE,CRANK PULLEY

SN: 099706-UP

1шт.

15

13022-GY000

KEY

SN: 099706-UP

1шт.

16

12308-GY000

WASHER,PULLEY, CRANKSHAFT

SN: 099706-UP

1шт.

17

21725-90002

O-RING

SN: 099706-UP

1шт.

18

12309-03J01

BOLT,PULLEY, CRANKSHAFT

SN: 099706-UP

1шт.

19

12207-VB000

BEARING SET (STD)

SN: 099706-UP

1шт.

|$30

12209-VB000

BEARING SET,0.25MM (US)

SN: 099706-UP

1шт.

|$31

12210-VB000

BEARING SET,0.50MM (US)

SN: 099706-UP

1шт.

|$32

12211-VB000

BEARING SET,0.75MM (US)

SN: 099706-UP

1шт.

|$33

12212-VB000

BEARING SET,1.00MM (US)

SN: 099706-UP

1шт.

20

12310-FZ060

FLYWHEEL ASS'Y

SN: 099706-UP

1шт.

21

12312-VB000

GEAR,RING

SN: 099706-UP

1шт.

22

32202-K8460

BEARING,BALL

SN: 099706-UP

1шт.

23

12316-L2001

BOLT,FLYWHEEL

SN: 099706-UP

6шт.

24

12370-K8400

ADAPTER

SN: 099706-UP

1шт.

25

NJ00926-51600

KEY

SN: 099706-UP

1шт.

26

NJ08120-8251E

BOLT

SN: 099706-UP

4шт.
