Запчасти Komatsu TB42-1C-F ПОРШЕНЬ¤ КОЛЕНВАЛ И МАХОВИК ДВИГАТЕЛЬ

1

12032-03J00

RING,SNAP

SN: S05425-UP

12шт.

2

12010-03J61

PISTON,1

SN: S05425-UP

6шт.

|$2

12010-03J62

PISTON,2

SN: S05425-UP

6шт.

|$3

12010-03J63

PISTON,3

SN: S05425-UP

6шт.

|$4

12010-03J64

PISTON,4

SN: S05425-UP

6шт.

|$5

12010-03J65

PISTON,5

SN: S05425-UP

6шт.

|$6

12010-03J10

PISTON,0.50MM (OS)

SN: S05425-UP

6шт.

|$7

12010-03J11

PISTON,1.00MM (OS)

SN: S05425-UP

6шт.

3

12033-03J00

RING SET

SN: S05425-UP

1шт.

|$9

12036-03J00

RING SET,0.50MM (OS)

SN: S05425-UP

1шт.

|$10

12038-03J00

RING SET,1.00MM (OS)

SN: S05425-UP

1шт.

4

12100-VB000

ROD COMPL,CONNECTING

SN: S05710-UP

6шт.

|$12

12100-03J00

ROD,CONNECTING

SN: S05425-S05709

6шт.

5

12030-03J01

BUSHING,PISTON

SN: S05425-UP

1шт.

6

12109-VB000

BOLT,ROD

SN: S05710-UP

2шт.

|$15

12109-03J00

BOLT,ROD

SN: S05425-S05709

2шт.

7

12112-03J00

NUT,ROD

SN: S05425-UP

2шт.

8

12111-03J00

BEARING,ROD

SN: S05425-UP

12шт.

|$18

12117-03J00

BEARING, 0.25MM,ROD, 0.25MM (US)

SN: S05425-UP

12шт.

|$19

12118-03J00

BEARING, 0.50MM,ROD, 0.50MM (US)

SN: S05425-UP

12шт.

|$20

12119-03J00

BEARING, 0.75MM,ROD, 0.75MM (US)

SN: S05425-UP

12шт.

|$21

12120-03J00

BEARING, 1.00MM,ROD, 1.00MM (US)

SN: S05425-UP

12шт.

9

12200-VB000

CRANKSHAFT ASS'Y

SN: S05770-UP

1шт.

|$23

12200-03J01

CRANKSHAFT ASS'Y

SN: S05425-S05769

1шт.

10

11024-03200

PLUG

SN: S05425-UP

6шт.

11

13021-WK200

SPROCKET

SN: S11307-UP

1шт.

|$26

0

SPROCKET

SN: S05770-S11306

1шт.

|$27

13021-03J00

SPROCKET

SN: S05425-S05769

1шт.

12

15043-VB500

GEAR

SN: S05770-UP

1шт.

|$29

15043-03J00

GEAR

SN: S05425-S05769

1шт.

13

12303-FZ000

PULLEY

SN: S05770-UP

1шт.

|$31

12303-52H01

PULLEY

SN: S05425-S05769

1шт.

14

12307-FZ000

WEDGE

SN: S05770-UP

1шт.

|$33

12307-52H00

WEDGE

SN: S05425-S05769

1шт.

15

13022-52H00

KEY

SN: S05425-UP

1шт.

16

12309-03J00

BOLT

SN: S05425-UP

1шт.

17

12308-03J01

WASHER

SN: S05425-UP

1шт.

18

12207-VB000

BEARING SET

SN: S05770-UP

1шт.

|$38

12207-03J00

BEARING SET

SN: S05425-S05769

1шт.

|$39

12209-VB000

BEARING SET,0.25MM (US)

SN: S05770-UP

1шт.

|$40

12209-03J00

BEARING SET,0.25MM (US)

SN: S05425-S05769

1шт.

|$41

12210-VB000

BEARING SET,0.50MM (US)

SN: S05770-UP

1шт.

|$42

12210-03J00

BEARING SET,0.50MM (US)

SN: S05425-S05769

1шт.

|$43

12211-VB000

BEARING SET,0.75MM (US)

SN: S05770-UP

1шт.

|$44

12211-03J00

BEARING SET,0.75MM (US)

SN: S05425-S05769

1шт.

|$45

12212-VB000

BEARING SET,1.00MM (US)

SN: S05770-UP

1шт.

|$46

12212-03J00

BEARING SET,1.00MM (US)

SN: S05425-S05769

1шт.

19

12310-FZ060

FLYWHEEL ASS'Y,(DRY)

SN: S11122-UP

1шт.

|$48

0

FLYWHEEL ASS'Y,(DRY)

SN: S05425-S11121

1шт.

|$49

12310-FZ061

FLYWHEEL ASS'Y,(WET)

SN: S11298-UP

1шт.

|$50

0

FLYWHEEL ASS'Y,(WET)

SN: S05425-S11297

1шт.

20

12312-03J00

GEAR,RING

SN: S05425-UP

1шт.

21

12316-L2001

BOLT,FLYWHEEL

SN: S05425-UP

6шт.

22

12370-K8400

ADAPTER,FLYWHEEL

SN: S05425-UP

1шт.

23

32202-K8460

BEARING,BALL

SN: S05425-UP

1шт.

24

NJ08120-8251E

BOLT

SN: S05425-UP

4шт.

27

23399-79610

O-RING,SEAL (WET)

SN: S05425-UP

1шт.
