Запчасти Komatsu TB42-1D-F STARTOR МОТОР ДВИГАТЕЛЬ

1

23300-52H00

MOTOR ASS'Y,STARTOR (DRY)

SN: S05425-UP

1шт.

|$1

23300-K8461

MOTOR ASS'Y,STARTOR (WET)

SN: S05425-UP

1шт.

2

23310-V5300

ARMATURE ASS'Y

SN: S05425-UP

1шт.

3

23319-M4900

BEARING,GEAR CASE

SN: S05425-UP

1шт.

4

23338-M4900

BEARING,GEAR COVER

SN: S05425-UP

1шт.

5

23306-52H00

COIL ASS'Y,FIELD

SN: S05425-UP

1шт.

6

23305-09500

SCREW ASS'Y

SN: S05425-UP

4шт.

7

23380-07G00

BRUSH,PLUS

SN: S05425-UP

2шт.

8

23337-M4901

COVER ASS'Y,REAR

SN: S05425-UP

1шт.

9

23378-07G00

HOLDER ASS'Y,BRUSH

SN: S05425-UP

1шт.

10

23333-M4901

SPRING,BRUSH

SN: S05425-UP

4шт.

11

23379-07G00

BRUSH,MINUS

SN: S05425-UP

2шт.

12

23312-03J00

PINION ASS'Y,(DRY)

SN: S05425-UP

1шт.

|$13

23312-K8461

PINION ASS'Y,(WET)

SN: S05425-UP

1шт.

13

23357-W1700

SHAFT,PINION

SN: S05425-UP

1шт.

14

23354-07G00

CLUTCH ASS'Y

SN: S05425-UP

1шт.

15

23358-07G00

BEARING

SN: S05425-UP

1шт.

16

23363-07G00

BEARING

SN: S05425-UP

1шт.

17

23465-M4900

STOPPER SET,PINION

SN: S05425-UP

1шт.

18

23318-03J00

CASE SET,GEAR

SN: S05425-UP

1шт.

19

23322-H9100

LEVER SET,SHIFT

SN: S05425-UP

1шт.

20

23343-03J00

SWITCH ASS'Y,MAGNETIC

SN: S05425-UP

1шт.

21

23470-11M00

COVER SET,DUST

SN: S05425-UP

1шт.

22

23359-W2800

RETAINER

SN: S05425-UP

1шт.

23

23324-N5900

COVER,DUST

SN: S05425-UP

1шт.

24

23340-N5900

BOLT,THROUGH

SN: S05425-UP

2шт.

26

23348-D0300

COVER,TERMINAL

SN: S05425-UP

1шт.

27

23399-L1123

GASKET,MOTOR (WET)

SN: S05425-UP

1шт.
