Запчасти Komatsu TB42-1D-F ГЕНЕРАТОР(№S-) ДВИГАТЕЛЬ

1

23100-K8470

ALTERNATOR ASS'Y

SN: S05644-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.231F AND 232-71.

-1шт.

2

23102-K8470

STATOR ASS'Y

SN: S05644-UP

1шт.

3

23108-K8470

ROTOR ASS'Y

SN: S05644-UP

1шт.

4

23120-0T060

BEARING,BALL

SN: S05644-UP

1шт.

5

23127-K8470

BRACKET ASS'Y,REAR

SN: S05644-UP

1шт.

6

23124-K8470

RECTIFIER

SN: S05644-UP

1шт.

7

23156-0B000

NUT,SET

SN: S05644-UP

1шт.

8

23215-K8470

REGULATOR ASS'Y

SN: S05644-UP

1шт.

9

23142-0P610

BRUSH

SN: S05644-UP

2шт.

10

23118-K8470

BRACKET ASS'Y,FRONT

SN: S05644-UP

1шт.

11

23120-22J20

BEARING,BALL

SN: S05644-UP

1шт.

12

23115-20P10

SCREW

SN: S05644-UP

1шт.

13

23131-20P10

BOLT,THROUGH

SN: S05644-UP

1шт.

14

23150-G5110

PULLEY

SN: S05644-UP

1шт.

15

23153-70T12

NUT ASS'Y

SN: S05644-UP

1шт.

16

23200-K8470

SCREW KIT

SN: S05644-UP

1шт.

17

14658-K8470

SEAL,OIL

SN: S05644-UP

1шт.
