Запчасти Komatsu TB42-1D-F CARBURETOR(№S-) ДВИГАТЕЛЬ

1

16010-K8470

CARBURETOR ASS'Y

SN: S05766-UP

1шт.

|$1

16010-K8410

CARBURETOR ASS'Y

SN: S05644-S05765

1шт.

|$2

16266-52H11

CHAMBER ASS'Y,CHOKE

SN: S05644-UP

1шт.

3

16199-52H11

PISTON,CHOKE

SN: S05644-UP

1шт.

4

16101-03J05

VALVE,NEEDLE

SN: S05644-UP

1шт.

5

16061-03J05

FLOAT

SN: S05644-UP

1шт.

6

16827-0201P

PIN,FLOAT

SN: S05644-UP

1шт.

7

16149-03J00

ROD,CONNECTING

SN: S05644-UP

1шт.

8

16098-52H01

FILTER

SN: S05644-UP

1шт.

9

16111-52H01

NIPPLE,FUEL

SN: S05644-UP

1шт.

10

16108-52H01

SCREW

SN: S05644-UP

1шт.

11

16137-52H01

PLATE

SN: S05644-UP

1шт.

12

16267-52H11

PIPE,RUBBER

SN: S05644-UP

1шт.

13

16217-C8410

COLLAR

SN: S05644-UP

1шт.

14

16452-V6500

SPRING,PUMP

SN: S05644-UP

1шт.

15

16302-03J05

LEVER,PUMP

SN: S05644-UP

1шт.

16

16187-02J00

HOLDER ASS'Y,CARD

SN: S05644-UP

1шт.

17

16008-03J05

CONNECTOR,AIR

SN: S05644-UP

1шт.

18

16125-03J05

GAUGE,LEVEL

SN: S05644-UP

1шт.

19

16125-62S05

COVER,GAUGE LEVER

SN: S05644-UP

1шт.

20

16071-03J05

WEIGHT,PUMP

SN: S05644-UP

1шт.

21

16030-03J05

PLUG

SN: S05644-UP

1шт.

22

16245-35000

STRAINER,PUMP

SN: S05644-UP

1шт.

23

16394-0202P

CLIP

SN: S05644-UP

1шт.

24

16148-03J05

SPRING,RETURN

SN: S05644-UP

1шт.

25

16151-03J05

PLUNGER,PUMP

SN: S05644-UP

1шт.

26

16196-52H02

VALVE,SOLENOID

SN: S05644-UP

1шт.

27

24341-79982

COUPLER

SN: S05644-UP

1шт.

28

16466-52H01

COVER

SN: S05644-UP

1шт.

29

16033-52H11

JET,MAIN

SN: S05644-UP

1шт.

30

16033-52H01

JET,MAIN

SN: S05644-UP

1шт.

31

16036-03J05

BLEED,MAIN AIR

SN: S05644-UP

1шт.

32

16036-52H11

BLEED,MAIN AIR

SN: S05644-UP

1шт.

33

16054-03J05

JET,SLOW

SN: S05644-UP

1шт.

34

16055-V6501

JET,STEP

SN: S05644-UP

1шт.

35

16204-60A00

BLEED,SLOW AIR

SN: S05644-UP

1шт.

36

16059-V6500

JET,POWER VALVE

SN: S05644-UP

1шт.

37

16030-52H01

PLUG

SN: S05644-UP

1шт.

38

16028-C8500

PLUG

SN: S05644-UP

1шт.

39

16286-A8601

PLUG

SN: S05644-UP

1шт.

40

16116-52H01

SLEEVE-A

SN: S05644-UP

1шт.

41

16313-52H02

DIAPHRAGM ASS'Y

SN: S05644-UP

1шт.

42

16140-52H01

SPRING,DIAPHRAGM

SN: S05644-UP

1шт.

43

16093-D0100

DIAPHRAGM

SN: S05644-UP

1шт.

44

16187-03J05

HOLDER ASS'Y,CARD

SN: S05644-UP

1шт.

|$45

16110-52H11

CHAMBER ASS'Y,THROTTLE

SN: S05644-UP

1шт.

46

16144-V6500

SCREW,ADJUST

SN: S05644-UP

1шт.

47

16145-31301

SPRING,SCREW

SN: S05644-UP

1шт.

48

16114-21C00

SCREW,ADJUST

SN: S05644-UP

1шт.

49

16193-B8500

SPRING,SCREW

SN: S05644-UP

1шт.

50

16152-52H01

WASHER

SN: S05644-UP

1шт.

51

16152-52H02

WASHER

SN: S05644-UP

1шт.

52

16365-52H01

ARM,AUXILIARY SHAFT

SN: S05644-UP

1шт.

53

16134-03J05

LEVER,THROTTLE

SN: S05644-UP

1шт.

54

16116-03J05

SLEEVE-B

SN: S05644-UP

1шт.

55

16127-52H01

PLATE,RETURN

SN: S05644-UP

1шт.

56

16063-03J05

LEVER,CONNECTING

SN: S05644-UP

1шт.

57

16134-52H01

LEVER,THROTTLE

SN: S05644-UP

1шт.

58

16132-C8410

NUT

SN: S05644-UP

1шт.

59

16143-03J05

ROD,PUMP

SN: S05644-UP

1шт.

60

16141-52H11

ROD,CONNECTING

SN: S05644-UP

1шт.

61

16160-52H01

SPRING,THROTTLE

SN: S05644-UP

1шт.

62

16455-52H02

GASKET SET

SN: S05644-UP

1шт.

63

16465-03J05

SCREW,(WITH WASHER) (K-A)

SN: S05644-UP

1шт.

64

16475-K8410

SCREW,(WITH WASHER) (K-B)

SN: S05644-UP

1шт.

65

16258-K8410

BRACKET

SN: S05644-UP

1шт.

66

16182-K8410

DASHPOT ASS'Y

SN: S05644-UP

1шт.

67

16173-K8410

LEVER

SN: S05644-UP

1шт.

68

16132-K8410

NUT

SN: S05644-UP

1шт.
