Запчасти Komatsu 6D125-1XX-B СТАРТЕР (.KW) (ВНУТР. ЧАСТИ) ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu 6D125-1XX-B - СТАРТЕР (.KW) (ВНУТР. ЧАСТИ) ТОПЛИВН. СИСТЕМА
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

Артикул

Название

Примечание

Количество

|$1

600-863-4131

STARTING MOTOR ASS'Y,(4.5KW)

SN: 26318973-UP

1шт.

1

ND028100-2882

YOKE ASS'Y

SN: 26318973-UP

1шт.

2

ND028062-0130

RUBBER CAP

SN: 26318973-UP

1шт.

3

ND028099-3570

STARTER KIT

SN: 26318973-UP

2шт.

4

ND028200-1590

ARMATURE ASS'Y

SN: 26318973-UP

1шт.

5

ND949100-1930

BEARING,BALL

SN: 26318973-UP

1шт.

6

ND949100-1750

BEARING,BALL

SN: 26318973-UP

1шт.

|$9

ND028300-6551

CLUTCH ASS'Y

SN: 26318973-UP

1шт.

7

ND028099-3270

STARTER KIT

SN: 26318973-UP

1шт.

8

ND028300-6751

CLUTCH ASS'Y

SN: 26318973-UP

1шт.

9

ND949100-4501

BEARING,BALL, FRONT

SN: 26318973-UP

1шт.

10

ND949100-1920

BEARING,BALL, REAR

SN: 26318973-UP

1шт.

11

ND949170-4040

SPRING

SN: 26318973-UP

1шт.

12

ND028381-0071

SHAFT

SN: 26318973-UP

1шт.

13

ND228401-0633

HOUSING ASS'Y

SN: 26318973-UP

1шт.

14

ND153400-8540

MAGNETIC SWITCH A.

SN: 26318973-UP

1шт.

15

ND128099-5830

STARTER KIT

SN: 26318973-UP

1шт.

16

ND028099-3160

STARTER KIT

SN: 26318973-UP

1шт.

17

ND053660-0443

PLUNGER

SN: 26318973-UP

1шт.

18

ND053404-0240

GASKET

SN: 26318973-UP

1шт.

19

ND053505-0290

COVER

SN: 26318973-UP

1шт.

20

ND053480-7560

BOLT ASS'Y

SN: 26318973-UP

1шт.

21

ND028065-0250

BUSHING

SN: 26318973-UP

1шт.

22

ND028510-5390

BRUSH HOLDER ASS'Y

SN: 26318973-UP

1шт.

23

ND949173-0571

SPRING

SN: 26318973-UP

4шт.

24

ND028501-8091

FRAME

SN: 26318973-UP

1шт.

25

ND128961-0010

BALL

SN: 26318973-UP

1шт.

26

ND949170-4070

SPRING

SN: 26318973-UP

1шт.

27

ND028371-1500

PINION

SN: 26318973-UP

1шт.

28

ND028306-0070

ROLLER

SN: 26318973-UP

5шт.

29

ND028063-0030

RETAINER

SN: 26318973-UP

1шт.

30

ND028327-0171

RETAINER

SN: 26318973-UP

1шт.

31

ND128950-0520

BOLT

SN: 26318973-UP

2шт.

32

ND949020-0600

WASHER,FELT

SN: 26318973-UP

1шт.

33

ND90801-10050

O-RING

SN: 26318973-UP

3шт.

34

ND949007-6530

SCREW

SN: 26318973-UP

2шт.

35

ND90170-10061

NUT

SN: 26318973-UP

1шт.

36

ND949056-4480

NUT

SN: 26318973-UP

1шт.

37

ND90258-10001

WASHER

SN: 26318973-UP

1шт.

38

ND949006-4720

SCREW

SN: 26318973-UP

3шт.

39

ND90200-06241

WASHER

SN: 26318973-UP

3шт.

40

ND028062-5790

COVER

SN: 26318973-UP

1шт.

41

ND949007-6850

SCREW

SN: 26318973-UP

1шт.

42

ND028901-5190

SEAL

SN: 26318973-UP

1шт.

|$1

600-863-4131

STARTING MOTOR ASS'Y,(4.5KW)

1

ND028100-2882

YOKE ASS'Y

2

ND028062-0130

RUBBER CAP

3

ND028099-3570

STARTER KIT

4

ND028200-1590

ARMATURE ASS'Y

5

ND949100-1930

BEARING,BALL

6

ND949100-1750

BEARING,BALL

|$9

ND028300-6551

CLUTCH ASS'Y

7

ND028099-3270

STARTER KIT

8

ND028300-6751

CLUTCH ASS'Y

9

ND949100-4501

BEARING,BALL, FRONT

10

ND949100-1920

BEARING,BALL, REAR

11

ND949170-4040

SPRING

12

ND028381-0071

SHAFT

13

ND228401-0633

HOUSING ASS'Y

14

ND153400-8540

MAGNETIC SWITCH A.

15

ND128099-5830

STARTER KIT

16

ND028099-3160

STARTER KIT

17

ND053660-0443

PLUNGER

18

ND053404-0240

GASKET

19

ND053505-0290

COVER

20

ND053480-7560

BOLT ASS'Y

21

ND028065-0250

BUSHING

22

ND028510-5390

BRUSH HOLDER ASS'Y

23

ND949173-0571

SPRING

24

ND028501-8091

FRAME

25

ND128961-0010

BALL

26

ND949170-4070

SPRING

27

ND028371-1500

PINION

28

ND028306-0070

ROLLER

29

ND028063-0030

RETAINER

30

ND028327-0171

RETAINER

31

ND128950-0520

BOLT

32

ND949020-0600

WASHER,FELT

33

ND90801-10050

O-RING

34

ND949007-6530

SCREW

35

ND90170-10061

NUT

36

ND949056-4480

NUT

37

ND90258-10001

WASHER

38

ND949006-4720

SCREW

39

ND90200-06241

WASHER

40

ND028062-5790

COVER

41

ND949007-6850

SCREW

42

ND028901-5190

SEAL
