Запчасти Komatsu 6D125-1XX-B ФОРСУНКА(№98-) ТОПЛИВН. СИСТЕМА

|$1

6736-13-3080

KIT,NOZZLE HOLDER

SN: 26319384-UP

6шт.

1

6736-13-3100

INJECTOR

SN: 26319384-UP

1шт.

2

6738-11-3130

NOZZLE

SN: 26319384-UP

1шт.

3

6736-11-3420

SEAL

SN: 26319384-UP

1шт.

4

6734-11-3610

SHIM, 1.00MM

SN: 26319384-UP

1шт.

|$6

6734-11-3620

SHIM, 1.04MM

SN: 26319384-UP

1шт.

|$7

6734-11-3630

SHIM, 1.08MM

SN: 26319384-UP

1шт.

|$8

6734-11-3640

SHIM, 1.10MM

SN: 26319384-UP

1шт.

|$9

6734-11-3650

SHIM, 1.14MM

SN: 26319384-UP

1шт.

|$10

6734-11-3660

SHIM, 1.18MM

SN: 26319384-UP

1шт.

|$11

6734-11-3670

SHIM, 1.20MM

SN: 26319384-UP

1шт.

|$12

6734-11-3680

SHIM, 1.24MM

SN: 26319384-UP

1шт.

|$13

6734-11-3690

SHIM, 1.28MM

SN: 26319384-UP

1шт.

|$14

6734-11-3710

SHIM, 1.30MM

SN: 26319384-UP

1шт.

|$15

6734-11-3720

SHIM, 1.34MM

SN: 26319384-UP

1шт.

|$16

6734-11-3730

SHIM, 1.38MM

SN: 26319384-UP

1шт.

|$17

6734-11-3740

SHIM, 1.40MM

SN: 26319384-UP

1шт.

|$18

6734-11-3750

SHIM, 1.44MM

SN: 26319384-UP

1шт.

|$19

6734-11-3760

SHIM, 1.48MM

SN: 26319384-UP

1шт.

|$20

6734-11-3770

SHIM, 1.50MM

SN: 26319384-UP

1шт.

|$21

6734-11-3780

SHIM, 1.54MM

SN: 26319384-UP

1шт.

|$22

6734-11-3790

SHIM, 1.58MM

SN: 26319384-UP

1шт.

|$23

6734-11-3810

SHIM, 1.60MM

SN: 26319384-UP

1шт.

|$24

6734-11-3820

SHIM, 1.64MM

SN: 26319384-UP

1шт.

|$25

6734-11-3830

SHIM, 1.68MM

SN: 26319384-UP

1шт.

|$26

6734-11-3840

SHIM, 1.70MM

SN: 26319384-UP

1шт.

|$27

6734-11-3850

SHIM, 1.74MM

SN: 26319384-UP

1шт.

|$28

6734-11-3860

SHIM, 1.78MM

SN: 26319384-UP

1шт.

|$29

6734-11-3870

SHIM, 1.80MM

SN: 26319384-UP

1шт.

|$30

6734-11-3880

SHIM, 1.84MM

SN: 26319384-UP

1шт.

|$31

6734-11-3890

SHIM, 1.88MM

SN: 26319384-UP

1шт.

|$32

6734-11-3910

SHIM, 1.90MM

SN: 26319384-UP

1шт.

|$33

6734-11-3920

SHIM, 1.94MM

SN: 26319384-UP

1шт.

|$34

6734-11-3930

SHIM, 1.98MM

SN: 26319384-UP

1шт.

5

6732-71-6260

GASKET (K1)

SN: 26319384-UP

12шт.

6

6732-11-3850

SEAL (K1)

SN: 26319384-UP

6шт.

|$1

6736-13-3080

KIT,NOZZLE HOLDER

1

6736-13-3100

INJECTOR

2

6738-11-3130

NOZZLE

3

6736-11-3420

SEAL

4

6734-11-3610

SHIM, 1.00MM

|$6

6734-11-3620

SHIM, 1.04MM

|$7

6734-11-3630

SHIM, 1.08MM

|$8

6734-11-3640

SHIM, 1.10MM

|$9

6734-11-3650

SHIM, 1.14MM

|$10

6734-11-3660

SHIM, 1.18MM

|$11

6734-11-3670

SHIM, 1.20MM

|$12

6734-11-3680

SHIM, 1.24MM

|$13

6734-11-3690

SHIM, 1.28MM

|$14

6734-11-3710

SHIM, 1.30MM

|$15

6734-11-3720

SHIM, 1.34MM

|$16

6734-11-3730

SHIM, 1.38MM

|$17

6734-11-3740

SHIM, 1.40MM

|$18

6734-11-3750

SHIM, 1.44MM

|$19

6734-11-3760

SHIM, 1.48MM

|$20

6734-11-3770

SHIM, 1.50MM

|$21

6734-11-3780

SHIM, 1.54MM

|$22

6734-11-3790

SHIM, 1.58MM

|$23

6734-11-3810

SHIM, 1.60MM

|$24

6734-11-3820

SHIM, 1.64MM

|$25

6734-11-3830

SHIM, 1.68MM

|$26

6734-11-3840

SHIM, 1.70MM

|$27

6734-11-3850

SHIM, 1.74MM

|$28

6734-11-3860

SHIM, 1.78MM

|$29

6734-11-3870

SHIM, 1.80MM

|$30

6734-11-3880

SHIM, 1.84MM

|$31

6734-11-3890

SHIM, 1.88MM

|$32

6734-11-3910

SHIM, 1.90MM

|$33

6734-11-3920

SHIM, 1.94MM

|$34

6734-11-3930

SHIM, 1.98MM

5

6732-71-6260

GASKET (K1)

6

6732-11-3850

SEAL (K1)
