Запчасти Komatsu 6D125-1XX-B ТОПЛ. НАСОС (НАСОС) (/) (ДЛЯ ОГРАНИЧЕНИЯ ПО ВЫБРОСУ ЕВРОП.) (ДЛЯ СТРАН ЕС ОГРАНИЧЕНИЯ ПО ВЫХЛОПУ ЕС) (ВНУТР. ЧАСТИ)(№98-) ТОПЛИВН. СИСТЕМА

|$1

6736-73-1130

INJECTION PUMP ASS'Y

SN: 26319384-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02A7 TO A401P-06A7.

-1шт.

|$4

DK103062-9340

PUMP ASS'Y

SN: 26319384-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02A7 AND A401P-03A7.

-1шт.

1

DK131034-1401

PLUG

SN: 26319384-UP

6шт.

2

DK131154-6520

STUD

SN: 26319384-UP

6шт.

3

DK131110-7720

VALVE,DELIVERY

SN: 26319384-UP

6шт.

4

DK131112-5600

SPRING

SN: 26319384-UP

6шт.

5

DK131115-1600

GASKET

SN: 26319384-UP

6шт.

6

DK131116-8420

HOLDER

SN: 26319384-UP

6шт.

7

DK131117-3100

STOPPER

SN: 26319384-UP

6шт.

8

DK131122-0520

PLATE ASS'Y

SN: 26319384-UP

3шт.

9

DK139717-0100

NUT

SN: 26319384-UP

6шт.

10

DK131200-2820

TAPPET ASS'Y

SN: 26319384-UP

6шт.

11

DK131203-0800

PIN

SN: 26319384-UP

1шт.

12

DK131204-1000

ROLLER

SN: 26319384-UP

1шт.

13

DK131205-0500

BUSHING

SN: 26319384-UP

1шт.

14

DK131206-0200

GUIDE

SN: 26319384-UP

1шт.

15

DK029311-0580

SHIM, 0.2MM

SN: 26319384-UP

-2шт.

|$21

DK029311-0590

SHIM, 0.25MM

SN: 26319384-UP

-2шт.

|$22

DK029311-0020

SHIM, 0.30MM

SN: 26319384-UP

-2шт.

|$23

DK029311-0600

SHIM, 0.35MM

SN: 26319384-UP

-2шт.

|$24

DK029311-0030

SHIM, 0.40MM

SN: 26319384-UP

-2шт.

|$25

DK029311-0610

SHIM, 0.45MM

SN: 26319384-UP

-2шт.

|$26

DK029311-0040

SHIM, 0.50MM

SN: 26319384-UP

-2шт.

|$27

DK029311-0270

SHIM, 0.55MM

SN: 26319384-UP

-2шт.

|$28

DK029311-0050

SHIM, 0.6MM

SN: 26319384-UP

-2шт.

|$29

DK029311-0280

SHIM, 0.65MM

SN: 26319384-UP

-2шт.

|$30

DK029311-0060

SHIM, 0.7MM

SN: 26319384-UP

-2шт.

|$31

DK029311-0290

SHIM, 0.75MM

SN: 26319384-UP

-2шт.

|$32

DK029311-0070

SHIM, 0.8MM

SN: 26319384-UP

-2шт.

|$33

DK029311-0310

SHIM, 0.85MM

SN: 26319384-UP

-2шт.

|$34

DK029311-0080

SHIM, 0.9MM

SN: 26319384-UP

-2шт.

|$35

DK029311-0320

SHIM, 0.95MM

SN: 26319384-UP

-2шт.

|$36

DK029311-0090

SHIM, 1.0MM

SN: 26319384-UP

-2шт.

|$37

DK029311-0330

SHIM, 1.05MM

SN: 26319384-UP

-2шт.

|$38

DK029311-0110

SHIM, 1.1MM

SN: 26319384-UP

-2шт.

|$39

DK029311-0340

SHIM, 1.15MM

SN: 26319384-UP

-2шт.

|$40

DK029311-0120

SHIM, 1.2MM

SN: 26319384-UP

-2шт.

|$41

DK029311-0350

SHIM, 1.25MM

SN: 26319384-UP

-2шт.

|$42

DK029311-0130

SHIM, 1.3MM

SN: 26319384-UP

-2шт.

|$43

DK029311-0620

SHIM, 1.35MM

SN: 26319384-UP

-2шт.

|$44

DK029311-0140

SHIM, 1.4MM

SN: 26319384-UP

-2шт.

|$45

DK029311-0630

SHIM, 1.45MM

SN: 26319384-UP

-2шт.

|$46

DK029311-0490

SHIM, 1.5MM

SN: 26319384-UP

-2шт.

|$47

DK029311-0710

SHIM, 1.55MM

SN: 26319384-UP

-2шт.

|$48

DK029311-0500

SHIM, 1.6MM

SN: 26319384-UP

-2шт.

16

DK131215-2500

SPRING

SN: 26319384-UP

6шт.

17

DK131216-0100

SEAT,SPRING

SN: 26319384-UP

6шт.

18

DK131217-0200

SEAT,SPRING

SN: 26319384-UP

6шт.

19

DK131256-0900

RACK,CONTROL

SN: 26319384-UP

1шт.

20

DK131226-0300

SCREW

SN: 26319384-UP

1шт.

21

DK131240-0100

PINION

SN: 26319384-UP

6шт.

22

DK131241-0100

SLEEVE,CONTROL

SN: 26319384-UP

6шт.

23

DK131242-0100

SCREW

SN: 26319384-UP

6шт.

|$1

6736-73-1130

INJECTION PUMP ASS'Y

|$4

DK103062-9340

PUMP ASS'Y

1

DK131034-1401

PLUG

2

DK131154-6520

STUD

3

DK131110-7720

VALVE,DELIVERY

4

DK131112-5600

SPRING

5

DK131115-1600

GASKET

6

DK131116-8420

HOLDER

7

DK131117-3100

STOPPER

8

DK131122-0520

PLATE ASS'Y

9

DK139717-0100

NUT

10

DK131200-2820

TAPPET ASS'Y

11

DK131203-0800

PIN

12

DK131204-1000

ROLLER

13

DK131205-0500

BUSHING

14

DK131206-0200

GUIDE

15

DK029311-0580

SHIM, 0.2MM

|$21

DK029311-0590

SHIM, 0.25MM

|$22

DK029311-0020

SHIM, 0.30MM

|$23

DK029311-0600

SHIM, 0.35MM

|$24

DK029311-0030

SHIM, 0.40MM

|$25

DK029311-0610

SHIM, 0.45MM

|$26

DK029311-0040

SHIM, 0.50MM

|$27

DK029311-0270

SHIM, 0.55MM

|$28

DK029311-0050

SHIM, 0.6MM

|$29

DK029311-0280

SHIM, 0.65MM

|$30

DK029311-0060

SHIM, 0.7MM

|$31

DK029311-0290

SHIM, 0.75MM

|$32

DK029311-0070

SHIM, 0.8MM

|$33

DK029311-0310

SHIM, 0.85MM

|$34

DK029311-0080

SHIM, 0.9MM

|$35

DK029311-0320

SHIM, 0.95MM

|$36

DK029311-0090

SHIM, 1.0MM

|$37

DK029311-0330

SHIM, 1.05MM

|$38

DK029311-0110

SHIM, 1.1MM

|$39

DK029311-0340

SHIM, 1.15MM

|$40

DK029311-0120

SHIM, 1.2MM

|$41

DK029311-0350

SHIM, 1.25MM

|$42

DK029311-0130

SHIM, 1.3MM

|$43

DK029311-0620

SHIM, 1.35MM

|$44

DK029311-0140

SHIM, 1.4MM

|$45

DK029311-0630

SHIM, 1.45MM

|$46

DK029311-0490

SHIM, 1.5MM

|$47

DK029311-0710

SHIM, 1.55MM

|$48

DK029311-0500

SHIM, 1.6MM

16

DK131215-2500

SPRING

17

DK131216-0100

SEAT,SPRING

18

DK131217-0200

SEAT,SPRING

19

DK131256-0900

RACK,CONTROL

20

DK131226-0300

SCREW

21

DK131240-0100

PINION

22

DK131241-0100

SLEEVE,CONTROL

23

DK131242-0100

SCREW
