Запчасти Komatsu H20-1-F ПОРШЕНЬ И КОЛЕНВАЛ ДВИГАТЕЛЬ

1

12010-50K00

PISTON SET,STANDARD

SN: K40001X-UP

4шт.

|$1

12010-50K70

PISTON SET,0.5MM (OS)

SN: K40001X-UP

4шт.

|$2

12010-50K71

PISTON SET,1.0MM (OS)

SN: K40001X-UP

4шт.

|$3

12010-50K72

PISTON SET,1.5MM (OS)

SN: K40001X-UP

4шт.

2

12033-50K00

RING SET,STANDARD

SN: K40001X-UP

4шт.

|$5

12035-50K00

RING SET,0.5MM (OS)

SN: K40001X-UP

4шт.

|$6

12036-50K00

RING SET,1.0MM (OS)

SN: K40001X-UP

4шт.

|$7

12037-50K00

RING SET,1.5MM (OS)

SN: K40001X-UP

4шт.

3

12100-50K00

ROD ASS'Y,CONNECTING

SN: K40001X-UP

4шт.

4

12109-D0210

BOLT

SN: K40001X-UP

8шт.

5

12112-H1000

NUT

SN: K40001X-UP

8шт.

6

12111-FY500

BUSHING,STANDARD

SN: K36846Y-UP

8шт.

|$12

12111-D2800

BUSHING,STANDARD

SN: K40001X-K 36845Y

8шт.

|$13

12117-FY500

BUSHING,0.08MM (US)

SN: K36846Y-UP

8шт.

|$14

12112-D2800

BUSHING,0.08MM (US)

SN: K40001X-K 36845Y

8шт.

|$15

12118-FY500

BUSHING,0.12MM (US)

SN: K36846Y-UP

8шт.

|$16

12113-D2800

BUSHING,0.12MM (US)

SN: K40001X-K 36845Y

8шт.

|$17

12119-FY500

BUSHING,0.25MM (US)

SN: K36846Y-UP

8шт.

|$18

12114-D2800

BUSHING,0.25MM (US)

SN: K40001X-K 36845Y

8шт.

7

12201-50K00

CRANKSHAFT ASS'Y

SN: K40001X-UP

8шт.

8

13021-03G00

SPROCKET

SN: K40001X-UP

1шт.

9

NJ00926-51600

KEY

SN: K40001X-UP

2шт.

10

12303-50K00

PULLEY,CRANKSHAFT

SN: K40001X-UP

1шт.

|$23

12303-50K06

PULLEY,CRANKSHAFT (WITH A/C)

SN: K40001X-UP

1шт.

11

12307-50K00

WEDGE,CRANK PULLEY

SN: K40001X-K66038X

1шт.

12

12351-50K10

SPROCKET

SN: K66039X-UP

1шт.

|$26

12351-50K00

SPROCKET

SN: K40001X-K66038X

1шт.

13

12309-29S00

BOLT

SN: K40001X-UP

1шт.

14

12308-50K00

WASHER

SN: K40001X-UP

1шт.

15

12353-50K10

SPROCKET

SN: K66039X-UP

1шт.

|$30

12353-50K00

SPROCKET

SN: K40001X-K66038X

1шт.

16

12352-00H00

CHAIN

SN: K40001X-UP

1шт.

17

12354-50K00

BEARING

SN: K40001X-UP

2шт.

18

12207-FY500

BEARING SET,STANDARD

SN: K36846Y-UP

1шт.

|$34

12207-50K00

BEARING SET,STANDARD

SN: K40001X-K 36845Y

1шт.

|$35

12208-FY500

BEARING SET,0.02MM (US)

SN: K36846Y-UP

1шт.

|$36

12208-50K00

BEARING SET,0.02MM (US)

SN: K40001X-K 36845Y

1шт.

|$37

12209-FY500

BEARING SET,0.25MM (US)

SN: K36846Y-UP

1шт.

|$38

12209-50K00

BEARING SET,0.25MM (US)

SN: K40001X-K 36845Y

1шт.

|$39

12210-FY500

BEARING SET,0.5MM (US)

SN: K34846Y-UP

1шт.

|$40

12210-50K00

BEARING SET,0.5MM (US)

SN: K40001X-K 36845Y

1шт.

|$41

12211-FY500

BEARING SET,0.75MM (US)

SN: K34846Y-UP

1шт.

|$42

12211-50K00

BEARING SET,0.75MM (US)

SN: K40001X-K 36845Y

1шт.

|$43

12212-FY500

BEARING SET,1.0MM (US)

SN: K36846Y-UP

1шт.

|$44

12212-50K00

BEARING SET,1.0MM (US)

SN: K40001X-K 36845Y

1шт.

19

12310-K9302

FLYWHEEL ASS'Y,(DRY CLUTCH AND T/C SPEC.)

SN: K40001X-UP

1шт.

|$46

12310-K9301

FLYWHEEL ASS'Y,(WET CLUTCH SPEC.)

SN: K40001X-UP

1шт.

20

12312-50K00

GEAR,RING

SN: K40001X-UP

1шт.

21

21170-K9300

BEARING,PILOT

SN: K63538X-UP

1шт.

|$49

0

BEARING,PILOT

SN: K40001X-K63537X

1шт.

22

12315-58S00

BOLT

SN: K40001X-UP

6шт.

23

12313-10600

PIN

SN: K40001X-UP

2шт.

24

23399-79610

O-RING,(WET CLUTCH SPEC.)

SN: K40001X-UP

1шт.

25

12331-50K01

FLYWHEEL,(TORQUE CONVERTER SPEC.)

SN: K21790Y-UP

1шт.

26

12330-A1000

SPACER,(TORQUE CONVERTER SPEC.)

SN: K21790Y-UP

1шт.

27

12330-VJ200

SPACER,(TORQUE CONVERTER SPEC.)

SN: K36846Y-UP

1шт.

|$56

12330-E3000

SPACER,(TORQUE CONVERTER SPEC.)

SN: K21790Y-K 36845Y

1шт.

28

12315-21001

BOLT,(TORQUE CONVERTER SPEC.)

SN: K21790Y-UP

6шт.
