Запчасти Komatsu H20-1-F ГЕНЕРАТОР ДВИГАТЕЛЬ

1

23100-50K10

ALTERNATOR ASS'Y,(35A)

SN: K40001X-UP

1шт.

|$1

23100-50K15

ALTERNATOR ASS'Y,(50A)

SN: K40001X-UP

1шт.

|$2

23100-L2910

ALTERNATOR ASS'Y,(20A)

SN: K40001X-UP

1шт.

2

23102-47N10

STATOR ASS'Y

SN: K40001X-UP

1шт.

|$4

23102-50K15

STATOR ASS'Y,(50A)

SN: K40001X-UP

1шт.

|$5

23102-L2910

STATOR ASS'Y,(20A)

SN: K40001X-UP

1шт.

3

23108-47N10

ROTOR ASS'Y

SN: K40001X-UP

1шт.

|$7

23108-50K15

ROTOR ASS'Y,(50A)

SN: K40001X-UP

1шт.

|$8

23108-L2910

ROTOR ASS'Y,(20A)

SN: K40001X-UP

1шт.

4

23120-30R10

BEARING,BALL

SN: K40001X-UP

1шт.

5

23127-50K11

COVER ASS'Y,REAR

SN: K40001X-UP

1шт.

|$11

23127-50K15

COVER ASS'Y,(50A)

SN: K40001X-UP

1шт.

6

23124-50K11

RECTIFIER ASS'Y

SN: K40001X-UP

1шт.

|$13

23124-50K15

RECTIFIER ASS'Y,(50A)

SN: K40001X-UP

1шт.

7

23156-0B000

NUT

SN: K40001X-UP

1шт.

8

23215-50K11

REGULATOR ASS'Y

SN: K40001X-UP

1шт.

9

23142-0B000

BRUSH

SN: K40001X-UP

2шт.

10

23118-47N10

COVER ASS'Y,FRONT

SN: K40001X-UP

1шт.

11

23120-22J20

BEARING,BALL

SN: K40001X-UP

1шт.

12

23115-47N10

SCREW

SN: K40001X-UP

1шт.

13

23131-20P10

BOLT

SN: K40001X-UP

1шт.

14

23150-47N10

PULLEY ASS'Y

SN: K40001X-UP

1шт.

15

23153-70T12

NUT ASS'Y

SN: K40001X-UP

1шт.
