Запчасти Komatsu 4LB1-1-F ГЕНЕРАТОР ДВИГАТЕЛЬ

|$0

8-97048-968-1

GENERATOR ASS'Y

SN: L100001-UP

1шт.

1

8-97075-965-0

FRAME ASS'Y,END

SN: L100001-UP

1шт.

2

8-94455-154-0

PLATE,RETAINER

SN: L100001-UP

1шт.

3

8-97072-839-0

SCREW

SN: L100001-UP

4шт.

4

8-97072-838-0

BEARING,BALL

SN: L100001-UP

1шт.

5

8-94455-156-0

STUD

SN: L100001-UP

2шт.

6

8-97072-841-0

FRAME,END

SN: L100001-UP

1шт.

7

8-97072-842-0

HOLDER ASS'Y,RECTIFIER

SN: L100001-UP

1шт.

8

8-94159-781-0

HOLDER ASS'Y,BRUSH

SN: L100001-UP

1шт.

9

8-94123-056-0

BRUSH

SN: L100001-UP

2шт.

10

8-94123-057-0

SPRING

SN: L100001-UP

2шт.

11

8-94455-160-0

REGULATOR ASS'Y

SN: L100001-UP

1шт.

12

8-97072-843-0

COVER,END

SN: L100001-UP

1шт.

13

8-97072-835-0

NUT

SN: L100001-UP

1шт.

14

8-94455-166-0

BUSHING

SN: L100001-UP

1шт.

15

8-94455-164-0

BOLT

SN: L100001-UP

2шт.

16

8-94123-061-0

SCREW,(WITH WASHER)

SN: L100001-UP

2шт.

17

8-94123-064-0

NUT

SN: L100001-UP

2шт.

18

8-94206-186-0

NUT

SN: L100001-UP

1шт.

19

8-97072-840-0

ROTOR ASS'Y

SN: L100001-UP

1шт.

20

8-94135-753-0

BEARING,BALL

SN: L100001-UP

1шт.

21

8-94123-051-0

COVER,BEARING

SN: L100001-UP

1шт.

22

8-97072-834-0

PULLEY

SN: L100001-UP

1шт.

23

8-97072-836-0

COLLAR

SN: L100001-UP

1шт.

24

8-94455-163-0

BOLT

SN: L100001-UP

3шт.

25

8-94455-162-0

SCREW

SN: L100001-UP

1шт.

26

8-94455-161-0

SCREW

SN: L100001-UP

6шт.
