Артикул
Название
Примечание
Количество
|$1
6734-71-1290
INJECTION PUMP A.
SN: 26219100-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-02A3 TO A401P-06A3.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105404-5470
GOVERNOR ASS'Y
SN: 26219100-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401P-04A3 AND A401P-05A3.
-1шт.
1
DK154620-0200
HOUSING
SN: 26219100-UP
1шт.
2
DK154007-2900
PLUG
SN: 26219100-UP
1шт.
3
DK154620-3200
GASKET
SN: 26219100-UP
1шт.
4
DK154620-1400
COVER
SN: 26219100-UP
1шт.
5
DK020006-1640
BOLT
SN: 26219100-UP
4шт.
6
DK154620-4600
BOLT
SN: 26219100-UP
1шт.
7
DK154620-5600
WASHER
SN: 26219100-UP
1шт.
8
DK154620-7900
ADAPTER
SN: 26219100-UP
1шт.
9
DK154375-9020
PLATE
SN: 26219100-UP
1шт.
10
DK029010-6810
BOLT
SN: 26219100-UP
5шт.
11
DK020106-1840
BOLT
SN: 26219100-UP
1шт.
12
DK154010-0100
SCREW
SN: 26219100-UP
1шт.
17
DK155404-5120
LIMITER
SN: 26219100-UP
1шт.
18
DK026518-2240
GASKET
SN: 26219100-UP
1шт.
19
DK154621-2120
FLYWEIGHT ASS'Y
SN: 26219100-UP
1шт.
21
DK029231-2030
NUT
SN: 26219100-UP
1шт.
22
DK154123-0120
SLEEVE
SN: 26219100-UP
1шт.
|$30
DK029311-0180
SHIM, 0.30MM
SN: 26219100-UP
-2шт.
|$32
DK139410-0000
SHIM, 0.50MM
SN: 26219100-UP
-2шт.
|$33
DK029311-0210
SHIM, 1.00MM
SN: 26219100-UP
-2шт.
|$34
DK139410-0100
SHIM, 1.50MM
SN: 26219100-UP
-2шт.
|$36
DK139410-3100
SHIM, 3.00MM
SN: 26219100-UP
-2шт.
|$37
DK139410-3200
SHIM, 4.00MM
SN: 26219100-UP
-2шт.
24
DK154154-4000
SPRING
SN: 26219100-UP
1шт.
25
DK154177-1020
CAPSULE
SN: 26219100-UP
1шт.
26
DK029201-6010
NUT
SN: 26219100-UP
1шт.
27
DK154211-4420
GUIDE LEVER ASS'Y
SN: 26219100-UP
1шт.
28
DK154620-2520
LINK
SN: 26219100-UP
1шт.
29
DK016010-0540
RING,SNAP
SN: 26219100-UP
1шт.
30
DK154236-1500
LEVER
SN: 26219100-UP
1шт.
31
DK154326-8520
LEVER ASS'Y
SN: 26219100-UP
1шт.
32
DK154390-0000
GASKET
SN: 26219100-UP
1шт.
33
DK154620-8700
PLUG
SN: 26219100-UP
1шт.
34
DK154620-3100
GASKET
SN: 26219100-UP
1шт.
35
DK154620-8800
PIN
SN: 26219100-UP
1шт.
36
DK154620-8900
PLATE
SN: 26219100-UP
1шт.
37
DK010038-1840
BOLT
SN: 26219100-UP
1шт.
38
DK154620-1300
FLANGE
SN: 26219100-UP
1шт.
39
DK154620-4700
BOLT
SN: 26219100-UP
1шт.
41
DK014010-8140
WASHER
SN: 26219100-UP
2шт.
42
DK154620-9000
O-RING
SN: 26219100-UP
1шт.
Выбрано товаров: 55
