Запчасти Komatsu WR11-3 ТРАНСМИССИЯ (2 И 3 МУФТА) ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

416-15-21080

TRANSMISSION ASS'Y

SN: 53001-UP

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-62A0.

-1шт.

|1

416-15-13200

CLUTCH ASS'Y,2ND AND 3RD

SN: 53001-UP

1шт.

|1

416-15-13112

SHAFT ASS'Y

SN: 53001-UP

1шт.

1

0

SHAFT,2ND AND 3RD

SN: 53001-UP

1шт.

2

0

HOUSING

SN: 53001-UP

1шт.

3

419-15-13191

PISTON,2ND AND 3RD

SN: 53001-UP

2шт.

4

7720-50-2590

DISC

SN: 53001-UP

8шт.

5

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

10шт.

6

419-15-12133

SPRING,WAVE

SN: 53001-UP

8шт.

7

419-15-12281

PLATE,END

SN: 53001-UP

2шт.

8

419-15-12140

RING,SNAP

SN: 53001-UP

2шт.

9

419-15-12580

RING,SEAL (K1)

SN: 53001-UP

2шт.

10

419-15-12210

RING,SEAL (K1)

SN: 53001-UP

2шт.

11

419-15-12680

WASHER,THRUST

SN: 53001-UP

6шт.

12

419-15-12670

BEARING,THRUST

SN: 53001-UP

3шт.

13

419-15-12240

WASHER,THRUST

SN: 53001-UP

2шт.

14

419-15-12250

BEARING,THRUST

SN: 53001-UP

1шт.

15

714-23-19430

BEARING,NEEDLE

SN: (54114)-UP

1шт.

|15

419-15-13151

BEARING,NEEDLE

SN: 53001-(54113)

1шт.

16

419-15-12271

BEARING

SN: (54114)-UP

2шт.

|16

419-15-12270

BEARING

SN: 53001-(54113)

2шт.

17

417-15-13222

GEAR¤ 39 TEETH,2ND

SN: 53001-UP

1шт.

18

417-15-13231

GEAR¤ 21 TEETH,3RD

SN: 53001-UP

1шт.

19

416-15-13240

GEAR

SN: 53001-UP

1шт.

20

419-15-12330

SPACER

SN: 53001-UP

1шт.

21

06030-06312

BEARING,BALL

SN: 53001-UP

1шт.

22

06030-06210

BEARING

SN: 53001-UP

1шт.

23

419-15-12121

RING,SEAL (K1)

SN: 53001-UP

3шт.
