Запчасти Komatsu WA900-3LC A-A7A СТАРТЕР MT (PRE-СИСТЕМА СМАЗКИ) ДВИГАТЕЛЬ

|$0

6216-84-6660

MOTOR, STARTING (67.5 DEG. SOLENOID)

1шт.

1

1310 734 H1

FRAME CE.

1шт.

2

1211 395 H1

BUSHING - FRAME CE

1шт.

3

1310 735 H1

ARMATURE

1шт.

4

1211 397 H1

FIELD COIL

6шт.

5

1211 269 H1

STUD - TERM

1шт.

6

VE 2 100

HOUSING - LEVER

1шт.

7

1211 283 H1

BUSHING - LEVER HOUSING

1шт.

8

1223 259 H1

DRIVE ASSEMBLY

1шт.

9

1228 448 H91

HOUSING - DRIVE

1шт.

10

1211 288 H1

BUSHING - DRIVE HOUSING

1шт.

11

1211 398 H1

SWITCH

1шт.

12

1211 399 H1

BRUSH

6шт.

13

1211 400 H1

SPRING - BRUSH

1шт.

14

1211 401 H91

BRUSH PLATE - ASM

3шт.

15

1211 290 H1

PLUNGER

1шт.

16

1211 291 H1

BOOT

1шт.

17

1210 073 H1

SPRING - PLUNGER

1шт.

18

1211 289 H1

LEVER - SHIFT

1шт.

19

1211 356 H1

WASHER - SPACE

1шт.

20

1211 286 H1

WASHER - BRAKE

1шт.

21

1310 736 H1

WASHER - THRUST CE

1шт.

22

1277 066 H1

LEAD & TERM

1шт.

23

120 239

LOCK WASHER - TERM STUD CE

1шт.

24

1310 737 H1

GEAR, DRIVE

1шт.

25

1310 738 H1

GEAR, IDLER

1шт.

26

NSS

NUT - FIELD TERM STUD (5/16 THK)

1шт.

27

1211 267 H1

NUT (& WASHER) - FIELD TERM STUD

2шт.

28

1249 322 H1

NUT-C.E. TERM STUD (3/4HEXx5/16 THK)

1шт.

29

1211 267 H1

NUT (& WASHER) - C.E. TERM STUD

1шт.

30

19 839 R1

NUT-PLUNGER ROD GUIDE ADJUSTING

1шт.

31

1245 108 H1

SCREW - POLE SHOE

12шт.

32

1211 292 H1

SCREW - BRUSH LEAD ATCH

1шт.

33

1211 292 H1

SCREW - FLD COLL LEAD TO BR HLDR AT

1шт.

34

1211 279 H1

SCREW (& LOCK WASHER) - BRUSH PLATE

1шт.

35

1245 107 H1

SCREW - CE FRAME ATCH

1шт.

36

1310 742 H1

SCREW - LEVER HOUSING ATCH

1шт.

37

1296 920 H1

SCREW - DRIVE HSG ATCH (5/16-18x1 1/2)

1шт.

38

1251 333 H1

SCREW - DRIVE HOUSING ATCH

1шт.

39

1302 329 H1

SCREW (& LOCK WASHER) - SWITCH ATCH

1шт.

40

1211 265 H1

WASHER - INSUL - FLD TERM STUD

2шт.

41

1211 266 H1

WASHER - PLAIN - FLD TERM STUD

2шт.

42

1211 280 H1

WASHER - INSUL - CE TERM STUD (7/8 OD)

2шт.

43

1211 266 H1

WASHER - PLAIN - CE TERM STUD

1шт.

44

1210 070 H1

WASHER - PLUNGER SPRING RETAINER

1шт.

45

1310 739 H1

LID, PUMP

1шт.

46

1310 740 H1

GASKET, PUMP LID

1шт.

47

1302 332 H1

CONNECTOR - TERM TO SWITCH

1шт.

48

1211 151 H1

GASKET - CE INSPECTION PLUG

2шт.

49

1310 741 H1

BOLTS, LID PUMP

4шт.

50

1211 151 H1

GASKET - LEVER INSPECTION PLUG

1шт.

51

VE 2 078

INSULATOR - FLD COLL - CE

1шт.

52

1211 271 H1

INSULATOR - FLD COLL - DE (TRIANGLE)

6шт.

53

1211 234 H1

INSULATION - WASHER - PKG FLD

1шт.

54

VE 2 095

INSULATOR (.015 GLASS CLOTH) BRUSH

1шт.

55

1302 331 H1

O-RING - CE

1шт.

56

347 360 R1

O-RING - BETWEEN LEVER & DRIVE

1шт.

57

355 967 R1

O-RING - SHIFT LEVER (1/2 INCH DIA)

1шт.

58

352 219 R1

O-RING - SHIFT LEVER SHAFT (3/8 INCH)

2шт.

59

1210 066 H1

PLUG - BRUSH INSPECTION - CE

1шт.

60

1210 066 H1

PLUG - LEVER HOUSING INSPECTION

1шт.

61

1211 277 H1

PLUG - OIL RESERVOIR - LEVER

1шт.

62

1211 277 H1

PLUG - OIL RESERVOIR - DE

2шт.

63

1228 455 H1

PLUG - DRIVE MOUNTING HOLES

1шт.

64

SF 0 515

POLE SHOE

1шт.

65

1210 074 H1

RETAINER - PLUNGER (13/32 INCH I.D.)

1шт.

66

1210 072 H1

RETAINER - PLUNGER (1 13/64 I.D.)

1шт.

67

1211 285 H1

SEAL - OIL - LEVER HOUSING

1шт.

68

1211 152 H1

SHAFT - SHIFT LEVER

1шт.

69

213 262 R1

SNAP RING - PLUNGER ASM

1шт.

70

213 262 R1

SNAP RING - SHIFT LEVER SHAFT

1шт.

71

1302 333 H1

WICK - FELT - LEVER HOUSING

1шт.

72

1302 333 H1

WICK - FELT - DE

1шт.
