Запчасти Komatsu WA900-3LC K-A OPERATOR СИДЕНЬЕ OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

427-57-A1210

SEAT, OPERATOR

SN: A50001-A50028-UP

1шт.

|$10

OR

1

-1шт.

1

427-57-A1211

SEAT, OPERATOR

SN: A50029--UP

1шт.

2

426-S33-2170

BRACKET, LEFT

SN: A50001--UP

1шт.

3

426-S33-2180

BRACKET, RIGHT

SN: A50001--UP

1шт.

4

01435-00820

BOLT

SN: A50001--UP

6шт.

5

01580-10806

NUT

SN: A50001--UP

6шт.

6

01643-30823

WASHER

SN: A50001--UP

12шт.

7

08055-00282

CONNECTOR

SN: A50029--UP

1шт.

8

08017-30704

CONDUIT

SN: A50029--UP

1шт.

|$11

F1 - IF OPERATOR SEAT AND BACK CUSHION ARE IN GOOD CONDITION AND ONLY THE SUS PENSION NEEDS TO BE REPLACED, THEN REPLACE DAMAGED SUSPENSION WITH SUSPEN SION ASSEMBLY (427-57-A1260)

10

-1шт.
