Запчасти Komatsu WA900-3LC J7-A АВТОМАТИЧ. СМАЗ. LUBE НАСОС ASSEMBLY ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

|$0

XA 3 336

PUMP, LUBE

SN: A50001--UP

1шт.

1

BF 5 470

SCREW, FLAT HEAD

SN: A50001--UP

2шт.

2

XA 2 145

WEIGHT, COUNTER

SN: A50001--UP

2шт.

3

BF 5 473

RING, RETAINING

SN: A50001--UP

2шт.

4

BF 5 511

RING, RETAINING

SN: A50001--UP

2шт.

5

BF 5 476

BEARING, BALL

SN: A50001--UP

1шт.

6

BF 5 475

CRANK, ECCENTRIC

SN: A50001--UP

1шт.

7

BF 5 474

CRANKROD

SN: A50001--UP

1шт.

8

BF 5 477

PIN, OUTLET

SN: A50001--UP

1шт.

9

NSS

O-RING

SN: A50001--UP

1шт.

10

BF 5 478

TUBE, PLUNGER

SN: A50001--UP

1шт.

11

BF 5 479

SCREW, BUTTON HEAD

SN: A50001--UP

2шт.

12

XA 2 789

LOCKWASHER

SN: A50001--UP

2шт.

13

BF 5 480

BUSHING, WRIST PIN

SN: A50001--UP

2шт.

14

BF 5 481

ANCHOR, WRIST PIN

SN: A50001--UP

1шт.

15

BF 5 521

WASHER, BACKUP

SN: A50001--UP

1шт.

16

NSS

SEAL, CUP

SN: A50001--UP

1шт.

17

BF 5 482

ROD, PLUNGER

SN: A50001--UP

1шт.

18

BF 5 483

SPRING

SN: A50001--UP

1шт.

19

LA 0 906

BALL, STEEL

SN: A50001--UP

1шт.

20

XA 2 017

PLUNGER

SN: A50001--UP

1шт.

21

BF 5 485

TUBE, RECIPRICATING

SN: A50001--UP

1шт.

22

NSS

SEAL, CUP

SN: A50001--UP

1шт.

23

NSS

O-RING

SN: A50001--UP

1шт.

24

BF 5 486

CYLINDER

SN: A50001--UP

1шт.

25

BF 5 487

CAGE, BALL

SN: A50001--UP

1шт.

26

BF 3 823

BALL, STEEL

SN: A50001--UP

1шт.

27

NSS

O-RING

SN: A50001--UP

1шт.

28

BF 5 488

SEAT, CHECK

SN: A50001--UP

1шт.

29

BF 5 506

RING, RETAINING

SN: A50001--UP

1шт.

30

BF 5 505

PLUG, SHOVEL

SN: A50001--UP

1шт.

31

BF 5 504

TUBE, HOUSING

SN: A50001--UP

1шт.

32

NSS

O-RING

SN: A50001--UP

1шт.

33

NSS

WASHER, BACKUP

SN: A50001--UP

1шт.

34

NSS

O-RING

SN: A50001--UP

1шт.

35

BF 5 503

BEARING, BRONZE

SN: A50001--UP

1шт.

36

NSS

GASKET

SN: A50001--UP

1шт.

37

BF 5 499

SCREW, SOCKET HEAD

SN: A50001--UP

2шт.

38

XA 2 147

WASHER

SN: A50001--UP

2шт.

39

BF 5 498

MOTOR, HYDRAULIC

SN: A50001--UP

1шт.

40

NSS

O-RING

SN: A50001--UP

2шт.

41

BF 5 496

VALVE, PRESSURE REDUCING

SN: A50001--UP

1шт.

42

XA 2 018

MANIFOLD

SN: A50001--UP

1шт.

43

PB 9 784

CONNECTOR

SN: A50001--UP

1шт.

44

BF 5 494

VALVE, SOLENOID

SN: A50001--UP

1шт.

45

BF 5 493

CARTRIDGE, VALVE

SN: A50001--UP

1шт.

46

BF 5 492

SCREW, SOCKET HEAD

SN: A50001--UP

4шт.

47

BF 5 491

GAUGE, PRESSURE

SN: A50001--UP

1шт.

48

BF 5 489

SCREW, SELF TAPPING

SN: A50001--UP

6шт.

49

NSS

GASKET

SN: A50001--UP

6шт.

50

BF 5 490

COVER, HOUSING

SN: A50001--UP

1шт.

51

NSS

GASKET, COVER

SN: A50001--UP

1шт.

52

BF 5 510

FITTING, ORIFICE

SN: A50001--UP

1шт.

53

BF 5 497

VALVE, FLOW CONTROL

SN: A50001--UP

1шт.

54

BF 5 500

PLUG, PIPE

SN: A50001--UP

1шт.

55

BF 5 501

HOUSING, PUMP

SN: A50001--UP

1шт.

56

NSS

RING, BACKUP

SN: A50001--UP

2шт.

57

NSS

O-RING

SN: A50001--UP

2шт.

58

NSS

O-RING

SN: A50001--UP

2шт.

59

BF 5 502

NUT

SN: A50001--UP

2шт.

60

XA 2 148

STRAINER, INLET

SN: A50001--UP

1шт.

|$61

61

-1шт.

|$62

F2 - OPTIONAL COMPONENT. NOT INCLUDED IN LUBE PUMP ASSEMBLY.

63

-1шт.

|$63

F2 - OPTIONAL COMPONENT. NOT INCLUDED IN LUBE PUMP ASSEMBLY.

63

-1шт.
