Запчасти Komatsu WA900-3LC H-A НАСОС РУЛЕВ. УПРАВЛ-Я ПЕРЕДН. НАСОС SUBASSEMBLY (заводской номер A-A ) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H1601-01A0 )

SN: A50001-A50022-UP

-1шт.

|$1

708-45-11104

PUMP SUBASSEMBLY

SN: A50001-A50022-UP

1шт.

|$2

708-25-00350

CASE ASSEMBLY, FRONT

SN: A50001-A50022-UP

1шт.

1

NSS

CASE, FRONT

SN: A50001-A50022-UP

1шт.

2

NSS

PLUG

SN: A50001-A50022-UP

8шт.

3

708-25-62310

CRADLE, FRONT

SN: A50001-A50022-UP

1шт.

4

708-25-23411

CAM, CAM

SN: A50001-A50022-UP

1шт.

5

708-25-12330

JOINT

SN: A50001-A50022-UP

1шт.

6

07000-22015

O-RING

SN: A50001-A50022-UP

1шт.

7

708-25-62360

O-RING

SN: A50001-A50022-UP

1шт.

8

708-25-12350

BOLT

SN: A50001-A50022-UP

12шт.

9

708-25-12360

PLATE

SN: A50001-A50022-UP

2шт.

10

04020-00820

PIN, DOWEL

SN: A50001-A50022-UP

4шт.

11

01010-30816

BOLT

SN: A50001-A50022-UP

4шт.

12

708-25-52710

SHAFT, FRONT

SN: A50001-A50022-UP

1шт.

13

708-2L-22150

BEARING

SN: A50001-A50022-UP

1шт.

14

708-25-05010

WASHER, KIT

SN: A50001-A50022-UP

1шт.

|$17

NSS

WASHER, 2.0 MM

SN: A50001-A50022-UP

1шт.

|$18

NSS

WASHER, 2.1 MM

SN: A50001-A50022-UP

1шт.

|$19

NSS

WASHER, 2.2 MM

SN: A50001-A50022-UP

1шт.

15

708-25-12790

RING, SNAP

SN: A50001-A50022-UP

1шт.

16

708-25-12811

HOUSING

SN: A50001-A50022-UP

1шт.

17

708-25-52860

SEAL, OIL

SN: A50001-A50022-UP

1шт.

18

708-25-05130

SHIM, KIT

SN: A50001-A50022-UP

1шт.

|$24

NSS

SHIM, 0.10 MM

SN: A50001-A50022-UP

1шт.

|$25

NSS

SHIM, 0.20 MM

SN: A50001-A50022-UP

2шт.

19

07000-32080

O-RING

SN: A50001-A50022-UP

1шт.

20

01010-30820

BOLT

SN: A50001-A50022-UP

4шт.

21

01643-30823

WASHER

SN: A50001-A50022-UP

4шт.

|$29

708-25-00401

CYLINDER BLOCK ASSEMBLY, CYLINDER

SN: A50001-A50022-UP

1шт.

22

708-25-13151

BLOCK, CYLINDER

SN: A50001-A50022-UP

1шт.

23

708-25-13611

PLATE, VALVE

SN: A50001-A50022-UP

1шт.

24

708-25-13120

WASHER

SN: A50001-A50022-UP

1шт.

25

708-25-13130

SPRING

SN: A50001-A50022-UP

1шт.

26

708-25-13140

RING, SNAP

SN: A50001-A50022-UP

1шт.

27

708-25-13422

RETAINER, SHOE

SN: A50001-A50022-UP

1шт.

28

708-25-05061

SPACER KIT

SN: A50001-A50022-UP

1шт.

|$37

NSS

SPACER, 11.540 MM

SN: A50001-A50022-UP

2шт.

|$38

NSS

SPACER, 11.560 MM

SN: A50001-A50022-UP

2шт.

|$39

NSS

SPACER, 11.575 MM

SN: A50001-A50022-UP

2шт.

29

708-25-13441

RETAINER

SN: A50001-A50022-UP

2шт.

30

708-25-13470

SCREW

SN: A50001-A50022-UP

4шт.

31

01643-30623

WASHER

SN: A50001-A50022-UP

4шт.

32

708-25-13314

PISTON SUBASSEMBLY

SN: A50001-A50022-UP

9шт.

33

708-25-64110

PISTON

SN: A50001-A50022-UP

1шт.

34

708-25-14121

SLIDER

SN: A50001-A50022-UP

1шт.

35

708-45-14380

COLLAR

SN: A50001-A50022-UP

1шт.

36

708-45-14390

COLLAR

SN: A50001-A50022-UP

1шт.

37

708-25-14140

CAP

SN: A50001-A50022-UP

1шт.

38

708-25-14150

CAP

SN: A50001-A50022-UP

1шт.

39

708-25-05050

SHIM, KIT

SN: A50001-A50022-UP

2шт.

|$51

NSS

SHIM, 0.1 MM

SN: A50001-A50022-UP

2шт.

|$52

NSS

SHIM, 0.2 MM

SN: A50001-A50022-UP

2шт.

|$53

NSS

SHIM, 0.5 MM

SN: A50001-A50022-UP

3шт.

40

NSS

SHIM, 0.1 MM

SN: A50001-A50022-UP

4шт.

41

07000-32065

O-RING

SN: A50001-A50022-UP

2шт.

42

01016-31035

BOLT

SN: A50001-A50022-UP

8шт.

43

01643-31032

WASHER

SN: A50001-A50022-UP

8шт.

44

07044-12412

PLUG

SN: A50001-A50022-UP

2шт.

45

07002-32434

O-RING

SN: A50001-A50022-UP

2шт.

46

708-25-13630

RING

SN: A50001-A50022-UP

1шт.
