Запчасти Komatsu WA900-3LC H-A 2-Х СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (/) ГИДРАВЛИКА

|$0

709-12-13602

VALVE ASSEMBLY

SN: A50013--UP

2шт.

|$1

709-12-13601

VALVE ASSEMBLY

SN: A50011-A50012-UP

2шт.

|$2

709-12-13600

VALVE ASSEMBLY

SN: A50001-A50010-UP

2шт.

1

NSS

BODY, VALVE

SN: A50001--UP

1шт.

2

700-94-11260

PLUG

SN: A50001--UP

1шт.

3

07000-12018

O-RING

SN: A50001--UP

1шт.

4

07001-02018

RING, BACK-UP

SN: A50001--UP

1шт.

5

07002-13634

O-RING

SN: A50001--UP

1шт.

6

700-22-11370

PLUG

SN: A50001--UP

1шт.

7

07002-12434

O-RING

SN: A50001--UP

1шт.

8

NSS

SPOOL

SN: A50001--UP

1шт.

9

NSS

SPOOL

SN: A50001--UP

1шт.

10

709-14-11530

RETAINER

SN: A50001--UP

3шт.

11

709-12-12790

RETAINER

SN: A50001--UP

1шт.

12

709-14-11550

SPRING

SN: A50001--UP

4шт.

13

709-12-12270

SPRING

SN: A50001--UP

3шт.

14

709-12-12280

SPRING

SN: A50001--UP

1шт.

15

709-14-11520

CASE

SN: A50001--UP

3шт.

16

709-12-12780

CASE

SN: A50001--UP

1шт.

17

07000-12065

O-RING

SN: A50001--UP

4шт.

18

01252-61035

BOLT

SN: A50001--UP

8шт.

19

709-12-12810

PLUG

SN: A50001--UP

1шт.

20

07002-14234

O-RING

SN: A50001--UP

1шт.

21

709-12-11590

VALVE

SN: A50001--UP

1шт.

22

709-12-11520

SEAL

SN: A50001--UP

1шт.

23

709-12-11530

SPRING

SN: A50001--UP

1шт.

24

709-12-11570

FLANGE

SN: A50001--UP

1шт.

25

07000-13048

O-RING

SN: A50001--UP

1шт.

26

01010-61460

BOLT

SN: A50001--UP

2шт.

27

01643-31445

WASHER

SN: A50001--UP

2шт.

28

709-12-11611

PLATE

SN: A50001--UP

1шт.

29

07000-12060

O-RING

SN: A50001--UP

1шт.

30

01010-61425

BOLT

SN: A50001--UP

2шт.

31

709-12-11411

VALVE

SN: A50001--UP

2шт.

32

709-12-11430

SPRING

SN: A50001--UP

2шт.

33

709-12-12440

PLATE

SN: A50001--UP

2шт.

34

07000-13048

O-RING

SN: A50001--UP

2шт.

35

01010-81250

BOLT

SN: A50001--UP

8шт.

36

01602-21236

WASHER, SPRING

SN: A50001--UP

8шт.

37

VALVE ASSEMBLY (SEE FIG. H0120-04A0 )

SN: A50001--UP

-1шт.

38

VALVE ASSEMBLY (SEE FIG. H0120-04A0 )

SN: A50001--UP

-1шт.

39

SUCTION VALVE ASSEMBLY (SEE FIG. H0120-04A0 )

SN: A50001--UP

-1шт.

40

-1шт.

40

VALVE ASSEMBLY (SEE FIG. H0120-04A0 )

SN: A50001--UP

-1шт.
