Запчасти Komatsu WA900-3LC F-A ТРАНСМИССИЯ 1 И 2 МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

427-15-12331

CARRIER

SN: A50001--UP

1шт.

2

427-15-12430

GEAR

SN: A50001--UP

4шт.

3

427-15-19260

BEARING

SN: A50001--UP

4шт.

4

04233-13820

WASHER, THRUST

SN: A50001--UP

8шт.

|$4

427-15-12530

SHAFT ASSEMBLY

SN: A50001--UP

4шт.

5

NSS

SHAFT

SN: A50001--UP

1шт.

6

568-15-11380

PLUG

SN: A50001--UP

1шт.

7

04260-00635

BALL

SN: A50001--UP

4шт.

8

427-15-12610

GEAR, RING

SN: A50001--UP

1шт.

9

427-15-19530

RING, SNAP

SN: A50001--UP

1шт.

10

427-15-12380

COVER

SN: A50001--UP

1шт.

11

01252-31035

BOLT

SN: A50001--UP

4шт.

12

195-15-49240

RING, SEAL

SN: A50001--UP

1шт.

13

427-15-11130

HOUSING

SN: A50001--UP

1шт.

14

234-71-11310

PIN, DOWEL

SN: A50001--UP

4шт.

15

568-15-11370

PIN

SN: A50001--UP

6шт.

16

198-15-22710

DISC

SN: A50001--UP

9шт.

17

198-15-22720

PLATE

SN: A50001--UP

7шт.

18

195-15-12850

SPRING

SN: A50001--UP

24шт.

19

195-15-12880

SPRING

SN: A50001--UP

54шт.

20

198-15-22740

PISTON, 1ST

SN: A50001--UP

1шт.

21

154-15-22811

RING, SEAL

SN: A50001--UP

1шт.

22

198-15-29210

RING, SEAL

SN: A50001--UP

1шт.

23

427-15-11140

HOUSING, 1ST

SN: A50001--UP

1шт.

24

04020-01842

PIN, DOWEL

SN: A50001--UP

2шт.

25

427-15-12620

GEAR, RING

SN: A50001--UP

1шт.

26

427-15-12760

PISTON, 2ND

SN: A50001--UP

1шт.

27

195-15-29210

RING, SEAL

SN: A50001--UP

1шт.

28

427-15-19210

RING, SEAL

SN: A50001--UP

1шт.

|$29

427-15-11501

HOUSING COMPLETE

SN: A50001--UP

1шт.

29

NSS

HOUSING, 2ND

SN: A50001--UP

1шт.

30

234-15-12790

SCREW

SN: A50001--UP

2шт.

31

562-15-11450

PLUG

SN: A50001--UP

2шт.

32

06000-06930

BEARING

SN: A50001--UP

1шт.

33

07018-12605

RING, SEAL

SN: A50001--UP

1шт.

34

562-15-11380

SLEEVE

SN: A50001--UP

17шт.
