Запчасти Komatsu WA900-3LC E-A ДОПОЛН. РАБОЧ. ОСВЕЩЕНИЕ ПЕРЕДН. ОСВЕЩЕНИЕ И СУППОРТ ЭЛЕКТРИКА

1

427-06-23132

BRACKET

SN: A50001--UP

1шт.

2

427-06-23141

BRACKET

SN: A50001--UP

1шт.

3

427-06-23150

PLATE

SN: A50001--UP

2шт.

4

01435-01020

BOLT

SN: A50001--UP

8шт.

5

421-06-23310

LAMP ASSEMBLY, FRONT

SN: A50001--UP

2шт.

|$5

421-06-23340

LENS

SN: A50001--UP

1шт.

|$6

421-06-23330

BULB, 70W

SN: A50001--UP

1шт.

|$7

01582-11411

NUT

SN: A50001--UP

1шт.

|$8

01602-21442

WASHER, LOCK

SN: A50001--UP

1шт.

|$9

01643-31445

WASHER

SN: A50001--UP

2шт.

6

41G-06-13201

LAMP ASSEMBLY, TURN SIGNAL

SN: A50001--UP

2шт.

|$11

41G-06-13210

LENS, FRONT

SN: A50001--UP

1шт.

|$12

41G-06-13220

LENS, REAR

SN: A50001--UP

1шт.

|$13

41G-06-13230

BULB, 5W

SN: A50001--UP

1шт.

|$14

08105-12420

BULB, 25W

SN: A50001--UP

1шт.

|$15

01220-40425

SCREW

SN: A50001--UP

4шт.

7

01435-01250

BOLT

SN: A50001--UP

8шт.

8

419-43-17920

WASHER

SN: A50001--UP

16шт.

9

415-64-13130

CUSHION

SN: A50001--UP

8шт.

10

417-54-13470

SPACER

SN: A50001--UP

8шт.

11

419-43-17930

CUSHION

SN: A50001--UP

8шт.

12

427-06-23112

SUPPORT, LEFT

SN: A50001--UP

1шт.

13

427-06-23122

SUPPORT, RIGHT

SN: A50001--UP

1шт.

14

01435-01240

BOLT

SN: A50001--UP

8шт.

15

08037-05016

GROMMET

SN: A50001--UP

2шт.

16

427-06-22170

HARNESS, FRONT LAMP WIRING

SN: A50001--UP

2шт.
