Артикул
Название
Примечание
Количество
|$3
427-15-11004
TRANSMISSION ASS'Y
SN: 50029-UP
1шт.
|$4
427-15-11003
TRANSMISSION ASS'Y
SN: 50002-50028
1шт.
|$5
427-15-00013
TRANSMISSION ASS'Y
SN: 50001-50001
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4320-51A0 TO F4320-65A0.
-1шт.
|$7
427-15-00201
CONTROL VALVE A.
SN: 50001-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4320-59A0 TO F4320-64A0.
-1шт.
|$9
427-15-00300
VALVE ASS'Y
SN: 50001-UP
1шт.
|$$8
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4320-59A0 TO F4320-63A0.
-1шт.
1
195-15-35230
VALVE
SN: 50001-UP
1шт.
6
237-14-12940
SPRING
SN: 50001-UP
1шт.
7
195-15-35280
STOPPER
SN: 50001-UP
2шт.
9
195-15-35240
VALVE
SN: 50001-UP
2шт.
13
566-15-45580
SPRING
SN: 50001-UP
1шт.
14
195-15-36210
SPRING
SN: 50001-UP
1шт.
16
427-15-15310
VALVE
SN: 50001-UP
1шт.
17
195-15-34160
SPRING
SN: 50001-UP
1шт.
19
560-43-14330
SHIM, 0.5MM (K4)
SN: 50002-UP
10шт.
19
560-43-14330
SHIM, 0.5MM (K4)
SN: 50001-50001
5шт.
21
195-15-35521
VALVE
SN: 50001-UP
1шт.
22
195-15-35530
VALVE
SN: 50001-UP
1шт.
23
287-15-15380
VALVE
SN: 50001-UP
1шт.
25
195-15-35560
PISTON
SN: 50001-UP
1шт.
26
195-15-36160
SPRING
SN: 50001-UP
1шт.
27
195-15-36170
SPRING
SN: 50001-UP
1шт.
28
195-15-35291
STOPPER
SN: 50001-UP
1шт.
29
427-15-15631
VALVE
SN: 50001-UP
1шт.
30
125-15-11230
PLUG
SN: 50001-UP
1шт.
Выбрано товаров: 39
