Артикул
Название
Примечание
Количество
|$3
427-15-11004
TRANSMISSION ASS'Y
SN: 50029-UP
1шт.
|$4
427-15-11003
TRANSMISSION ASS'Y
SN: 50002-50028
1шт.
|$5
427-15-00013
TRANSMISSION ASS'Y
SN: 50001-50001
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4320-51A0 TO F4320-65A0.
-1шт.
|$7
427-15-00201
CONTROL VALVE A.
SN: 50001-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4320-59A0 TO F4320-64A0.
-1шт.
|$9
427-15-00300
VALVE ASS'Y
SN: 50001-UP
1шт.
|$$8
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4320-59A0 TO F4320-63A0.
-1шт.
1
427-15-15220
BODY
SN: 50001-UP
1шт.
5
427-15-15231
VALVE
SN: 50001-UP
2шт.
8
427-15-16470
SHIM, 0.5MM (K4)
SN: 50001-UP
14шт.
10
427-15-16110
SPRING
SN: 50001-UP
1шт.
11
427-15-16120
SPRING
SN: 50001-UP
1шт.
12
427-15-15820
PLUG
SN: 50001-UP
1шт.
13
427-15-16140
SPRING
SN: 50001-UP
1шт.
14
427-15-15850
PLUG
SN: 50001-UP
1шт.
16
427-15-15810
PLATE
SN: 50001-UP
2шт.
20
427-15-15140
SEAT
SN: 50001-UP
1шт.
21
427-15-15921
GASKET (K4)
SN: 50001-UP
1шт.
24
01252-41025
BOLT
SN: 50001-UP
3шт.
Выбрано товаров: 33
